York AFFINITY BHZ - Page 44

718419-YTG-D-0613
44 Johnson Controls Unitary Products
BHX024-060
Model
(Tons)
Air Over Evaporator
Coil
Capacity
1
& kW
2
1. These Capacities are net capacities - the indoor motor heat has been added.
2. These power inputs are total power inputs - the indoor motor watts have been added.
Outdoor Temperature (°F @ 72% RH)
CFM DB (°F
) -10 0 10 20 30 40 50 60
BHX024
(2.0)
650
55
MBH 5.52 6.55 7.81 9.35 11.24 13.55 16.38 19.85
KW 0.89 0.90 0.91 0.92 0.93 0.94 0.96 0.97
70
MBH 4.58 5.61 6.87 8.41 10.30 12.61 15.44 18.91
KW 1.07 1.08 1.09 1.10 1.11 1.13 1.14 1.15
80
MBH 3.55 4.58 5.84 7.38 9.27 11.58 14.41 17.88
KW 1.22 1.23 1.24 1.25 1.26 1.27 1.29 1.30
800
55
MBH 11.33 12.80 14.53 16.54 18.91 21.67 24.91 28.71
KW 1.03 1.07 1.13 1.19 1.25 1.31 1.37 1.43
70
MBH 8.60 10.07 11.79 13.81 16.17 18.94 22.18 25.97
KW 1.25 1.28 1.34 1.40 1.47 1.53 1.59 1.65
80
MBH 7.49 8.96 10.68 12.70 15.06 17.83 21.07 24.87
KW 1.44 1.48 1.54 1.60 1.66 1.72 1.78 1.84
BHX036
(3.0)
900
55
MBH 10.90 12.40 14.14 16.14 18.46 21.15 24.25 27.84
KW 1.44 1.48 1.53 1.57 1.62 1.67 1.72 1.77
70
MBH 9.57 11.07 12.80 14.81 17.13 19.81 22.92 26.51
KW 1.73 1.77 1.82 1.86 1.91 1.96 2.01 2.06
80
MBH 8.77 10.27 12.01 14.01 16.33 19.01 22.12 25.71
KW 2.05 2.10 2.14 2.19 2.23 2.28 2.33 2.38
1100
55
MBH 13.92 16.10 18.68 21.75 25.38 29.69 34.80 40.85
KW 1.68 1.77 1.86 1.96 2.06 2.16 2.27 2.39
70
MBH 11.75 13.93 16.51 19.58 23.21 27.52 32.63 38.68
KW 2.16 2.25 2.34 2.44 2.54 2.64 2.75 2.87
80
MBH 7.25 9.43 12.02 15.08 18.72 23.02 28.13 34.19
KW 2.08 2.17 2.27 2.36 2.46 2.57 2.68 2.79
BHX048
(4.0)
1200
55
MBH 13.84 15.99 18.53 21.51 25.01 29.13 33.96 39.65
KW 1.39 1.56 1.74 1.91 2.08 2.26 2.43 2.60
70
MBH 12.34 14.50 17.04 20.02 23.52 27.63 32.47 38.15
KW 1.88 2.06 2.23 2.40 2.58 2.75 2.92 3.09
80
MBH 11.41 13.57 16.11 19.09 22.59 26.71 31.54 37.22
KW 2.36 2.53 2.71 2.88 3.05 3.23 3.40 3.57
1600
55
MBH 15.52 18.56 22.22 26.61 31.88 38.22 45.83 54.96
KW 1.84 2.05 2.27 2.51 2.77 3.06 3.37 3.70
70
MBH 15.13 18.17 21.83 26.22 31.49 37.83 45.44 54.57
KW 2.43 2.63 2.86 3.10 3.36 3.64 3.95 4.28
80
MBH 14.45 17.49 21.15 25.54 30.81 37.15 44.76 53.89
KW 3.09 3.30 3.52 3.76 4.02 4.30 4.61 4.95
BHX060
(5.0)
1200
55
MBH 13.78 16.37 19.51 23.30 27.90 33.46 40.20 48.36
KW 1.59 1.77 1.97 2.18 2.41 2.65 2.91 3.20
70
MBH 12.28 14.87 18.00 21.80 26.39 31.96 38.69 46.85
KW 2.32 2.50 2.70 2.91 3.14 3.38 3.64 3.93
80
MBH 11.43 14.02 17.16 20.95 25.55 31.11 37.85 46.01
KW 2.98 3.16 3.35 3.56 3.79 4.03 4.30 4.58
1700
55
MBH 22.93 26.78 31.33 36.69 43.03 50.51 59.34 69.77
KW 1.37 1.70 2.07 2.49 2.97 3.51 4.12 4.81
70
MBH 21.30 25.15 29.70 35.06 41.40 48.88 57.71 68.14
KW 2.49 2.82 3.19 3.61 4.09 4.63 5.24 5.93
80
MBH 19.88 23.73 28.27 33.64 39.98 47.46 56.29 66.72
KW 3.43 3.76 4.13 4.55 5.03 5.57 6.18 6.87
