York AFFINITY BHZ - Roof Curb Details

718419-YTG-D-0613
82 Johnson Controls Unitary Products
BHZ/BHQ/BHX Unit Accessory Dimensions
Roof Curb
1
1
RECOMMENDED
DUCT SIZE
17-1/8" x 21-1/2"
RECOMMENDED
DUCT SIZE
17-1/2" x 16-3/4"
OPENING FOR
RETURN AIR DUCT
OPENING FOR
SUPPLY AIR DUCT
42-2/3
40-3/4
17-5/8
17-1/4
43-1/4
22
45-1/8
3-1/2
14
1. 8” Roof Curb also available.
