York Champion Series - Page 11

Unitary Products Group 11
66297-YIM-C-0205
TABLE 18 - COOLING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 2,000 CFM (B1HH060)
OUTDOOR
TEMPERATURE,
°F
INDOOR WB TEMPERATURE, °F
55 57 59 61 63 65 67 69 71 73 75
65 — — — 5.4 6.8 8.3 9.8 15.5 21.2 27.0 32.7
70 ————6.37.89.214.9 20.6 26.2 31.9
75 ————5.87.28.614.2 19.9 25.5 31.1
80 ————5.36.78.013.6 19.2 24.8 30.3
85 —————6.17.412.9 18.5 24.0 29.6
90 ——————5.810.5 15.3 20.0 24.8
95 ———————8.212.1 16.1 20.0
100 ———————6.810.0 13.1 16.3
105 ———————5.57.810.2 12.5
110 ————————5.77.28.8
115 ——————————5.0
INDOOR DB
TEMPERATURE,
°F
HEATING SUPERHEAT AT COMPRESSOR SUCTION, °F
-100 102030405060
55 — — 2.9 3.1 3.7 5.3 9.4 20.0
70 ——————6.617.3
80 ———————10.2
TABLE 19 - HEATING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 2,000 CFM (B1HH060)
