York Champion Series - Cooling Capacities - 1-1;2 Ton (BHA018)

66297-YIM-C-0205
Unitary Products Group 5
MODEL
BHH
POWER SUP
-
PLY
VOLTAGE
LIMITATIONS
1
COMPRESSOR
OUTDOOR
FAN
MOTOR,
FLA
SUPPLY
AIR
BLOWER
MOTOR,
FLA
MINIMUM
CIRCUIT
AMPACITY
MAX.
FUSE
SIZE,
AMPS
2
MAX.
HACR
BREAKER
SIZE,
AMPS
UNIT
POWER
FACTOR
TRANSFORMER
SIZE (VA)
MIN. MAX. RLA LRA
018 208/230-1-60 187 253 7.1 48.0 1.1 2.6 12.5 15 15 0.96 40
024 208/230-1-60 187 253 9.3 57.0 1.1 2.6 15.3 20 20 0.96 40
030
208/230-1-60 187 253 15.0 72.5 1.1 2.6 22.5 30 30 0.96 40
208/230-3-60 187 253 10.0 63.0 1.1 2.6 16.2 25 25 0.96 75
460-3-60 414 504 5.0 31.0 0.6 1.4 8.3 15 15 0.96 75
036
208/230-1-60 187 253 17.2 94.0 1.1 3.5 26.1 35 35 0.96 40
208/230-3-60 187 253 11.4 78.0 1.1 3.5 18.9 25 25 0.96 75
460-3-60 414 504 5.7 40.0 0.6 1.8 9.5 15 15 0.96 75
575-3-60 518 630 4.7 32.0 0.4 1.5 7.8 15 15 0.96 75
042
208/230-1-60 187 253 20.0 104.0 1.1 3.5 29.6 40 40 0.96 40
208/230-3-60 187 253 13.9 88.0 1.1 3.5 22.0 30 30 0.96 75
460-3-60 414 504 6.4 44.0 0.6 1.8 10.4 15 15 0.96 75
575-3-60 518 630 5.4 34.0 0.4 1.5 8.7 15 15 0.96 75
048
208/230-1-60 187 253 23.4 126.0 1.5 4.0 34.7 45 45 0.96 40
208/230-3-60 187 253 13.0 93.0 1.5 4.0 21.8 30 30 0.96 75
460-3-60 414 504 6.4 46.5 0.8 2.0 10.8 15 15 0.96 75
575-3-60 518 630 5.1 37.2 0.6 1.6 8.6 15 15 0.96 75
060
208/230-1-60 187 253 28.8 148.0 1.5 5.6 43.1 60 60 0.96 40
208/230-3-60 187 253 17.2 123.0 1.5 5.6 28.7 40 40 0.96 75
460-3-60 414 504 8.2 62.0 0.8 5.6 16.7 20 20 0.96 75
575-3-60 518 630 7.0 50.0 0.6 2.8 12.2 15 15 0.96 75
1 = Rated in accordance with ARI Standard 110, utilization range “A”. 2 = Dual element, time delay type.
TABLE 4 - ELECTRICAL DATA (BASIC UNIT)
ELECTRIC HEAT
CORRECTION
FACTORS
NOMINAL VOLTAGE VOLTAGE
KW CAP. MULTI-
PLIER
240
208
230
.75
.92
480 460 .92
600 575 .92
