YORK INTERNATIONAL 43
FORM 160.49-O1
MON. 10:00 AM Power Micro Board 8.29VDC 7.84 Auto restart plug To restart, press Power Failure
Failure undervoltage VDC is removed on compressor switch
circuit on 5V Micro Board to STOP-RESET
unregulated Position and then to
supply START position
MON. 10:00 AM Oil Pressure High Oil Press. 100
PSID
(689.5 59 Will start at 59 PSID This Shutdown is provided
Transducer Transducer
kPa D)
(During1st PSID, (406.8 kPa D) when to check on Oil Pressure
Error 7 min. of Compr. 406.8 compr. switch is placed Transducers for failure in
Oper.) 60 PSID kPa D to STOP/RESET and the high state. Replace
(413.7 kPa D) then START Oil Press. Transducer in
(After first 7 min. oil sump or compressor
of Compr. Oper.)
Vane Motor Autostart Vane Motor Restart automatically Vanes are set improperly,
Switch Open Switch after Vane Motor arm reset vane linkage check
linkage is set pro- vane positions using
perly. Press STOP/ the SERVICE key switch
RESET and then and proper keys on the
START switch MicroComputer Control
Center
MON. 10:00 AM Starter Motor Current > Press compressor Check motor starter
Malfunction 15% for 10 swc. STOP/RESET operation. Motor current
Detected with Control Cen- switch and then value greater than 15%
ter not calling for FLA
motor to run
MON. 10:00 AM Program Autostart Micro Board Watchdog timer circuit
Initiated has reset software pro-
Reset gram – Chiller will
automatically restart.
Replace RTC RTC-IC chip Reprogram the Con- Weak battery
IC chip trol Center Setponts Replace RTC-IC chip
Reprogram & proceed with U16
Setpoints Normal Start-up
MON. 10:00 AM Low Oil Autostart Oil Temp. 71.0°F 55°F Press STOP/ Oil Temp. Thermistor
Temperature Thermistor (21.7°C) (12.8°C) RESET switch & disconnected from
(RT3) then START Analog Input Board.
switch Reconnect or replace
open sensor.
MON. 10:00 AM Faulty Dis- Discharge Temp. 30.0°F 29.9°F Press STOP/ Faulty Discharge Temp.
charge Temp. Thermistor (–1.1°C) (–1.2°C) START switch & Thermistor (RT2) or dis-
Sensor (RT2) discon- then START connected from Analog
nected or faulty switch Input Board. Connect or
operating temp. replace open sensor.
= 32°F
MON. 10.00 AM Low Line SSS Logic See legend on wiring Chiller will automa- Low AC Line Voltage
Voltage (SSS Board diagram tically restart when
Units only) all phases of line vol-
tage increase to the
minimum required
