York HMCG2 Series User Manual

Air handler capacity
Table 5: Air handler capacity
Outdoor unit model Air handler model Air handler
width (in.)
Indoor coil
model
Stage Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
High 750 24.00 17.40 11.50
Intermediate 550 17.30 12.80 16.95
HMCG22B241S JHETB18BBAS2N1 17.5 —
Low 550 14.40 11.70
18.00
29.15
High 750 23.80 17.10 11.50
Intermediate 500 17.00 9.00 16.90
HMCG22B241S JHVTB24CBAC2N1 17.5 —
Low 500 13.90 9.60
17.50
28.75
High 750 23.80 17.10 11.50
Intermediate 550 17.20 9.50 17.10
HMCG22B241S JHETB24CBAS2N1 17.5 —
Low 550 14.00 10.20
18.00
29.20
High 775 23.40 16.80 11.00
Intermediate 500 16.40 8.60 16.20
HMCG22B241S JHVTB18BBAC2N1 17.5 —
Low 500 13.90 9.40
17.00
28.40
High 1225 36.00 27.40 10.00
Intermediate 850 25.00 19.60 16.35
HMCG22B361S JHETB36DBCS2N1 17.5 —
Low 850 19.50 17.30
17.00
27.55
High 1200 36.00 26.20 11.00
Intermediate 800 24.40 13.90 16.70
HMCG22B361S JHVTB36DBCC2N1 17.5 —
Low 800 19.30 14.20
18.00
30.00
High 1200 36.00 26.20 10.50
Intermediate 625 23.60 13.20 16.65
HMCG22B361S JHVTC36DBCC2N1 21.0 —
Low 625 19.00 12.40
17.50
31.10
High 1575 48.00 34.80 10.00
Intermediate 825 31.20 21.40 15.05
HMCG22B481S JHETC48GBCS2N1 21.0 —
Low 825 24.40 18.20
16.50
27.05
High 1500 47.50 32.80 9.80
Intermediate 850 31.00 14.60 15.05
HMCG22B481S JHVTD48GBCC2N1 24.5 —
Low 850 24.40 15.80
16.00
27.05
High 1575 48.00 33.40 9.90
Intermediate 900 32.20 15.90 15.85
HMCG22B481S JHETC60HBCS2N1 24.5 —
Low 900 25.00 16.90
17.00
29.65
High 1525 47.50 33.00 9.80
Intermediate 800 30.60 14.00 14.85
HMCG22B481S JHVTC48GBCC2N1 21.0 —
Low 800 24.20 15.30
15.50
26.80
High 1525 48.00 33.00 9.80
Intermediate 950 32.60 16.50 15.75
HMCG22B481S JHVTC60HBCC2N1 21.0 —
Low 950 25.00 17.30
16.50
28.75
High 1450 47.50 32.40 9.80
Intermediate 750 30.80 14.00 15.40
HMCG22B481S JHVTC42FBCC2N1 21.0 —
Low 750 24.40 15.10
16.50
28.60
High 1500 48.00 32.80 10.00
Intermediate 950 32.60 16.50 15.90
HMCG22B481S JHVTD60HBCC2N1 24.5 —
Low 950 25.20 17.50
17.00
29.40
High 1375 47.50 32.20 9.80
Intermediate 900 31.40 15.30 15.10
HMCG22B481S JHETD48GBCS2N1 21.0 —
Low 900 24.60 16.30
16.00
27.05
High 1575 48.00 33.40 9.90
Intermediate 900 32.20 15.90 15.85
HMCG22B481S JHETD60HBCS2N1 24.5 —
Low 900 25.00 16.90
17.00
29.70
High 1800 56.00 40.00 10.00
Intermediate 1275 36.80 28.40 17.05
HMCG22B601S JHETD60JBCS2N1 24.5 —
Low 1275 28.40 24.60
18.50
31.55
High 1750 54.00 39.50 10.00
Intermediate 1125 35.60 19.50 16.85
HMCG22B601S JHETD60HBCS2N1 24.5 —
Low 1125 27.80 20.20
18.00
31.90
High 1575 53.00 37.80 9.80
Intermediate 1100 35.40 19.20 16.70
HMCG22B601S JHETC60HBCS2N1 24.5 —
Low 1100 27.60 19.90
17.50
31.45
High 1725 55.00 41.50 10.00
Intermediate 1025 35.20 20.40 16.95
HMCG22B601S JHVTD60JBCC2N1 24.5 —
Low 1025 26.60 19.60
18.00
32.35
YORK Technical Guide: HMCG2 Series - 16 SEER2 Horizontal Discharge Modulating Air Conditioner12
