York HMCG2 Series User Manual

Nomenclature
Table 1: Horizontal discharge AC and HP
Configuration H H = Horizontal discharge
1 = 1 stage
2 = 2 stage
3 = 3 stage
M = Modulating
Stages M
V = Variable capacity
C = Air conditionerProduct type C
H = Heat pump
GEfficiency series
2
G2 = 16 SEER2
2 = 208/230-1-60
3 = 208/230-3-60
Voltage 2
4 = 460-3-60
B = R-410ARefrigerant B
D = R-454B
24 = 2 ton
36 = 3 ton
48 = 4 ton
Capacity 24
60 = 5 ton
1 = 1st generationGeneration 1
2 = 2nd generation
C =Communicating
B = Wireless (communicating)
S = Standard (conventional)
Control strategy S
W = Wireless (conventional)
A = Style AStyle A
B = Style B
Physical and electrical data
Table 2: Physical and electrical data
Outdoor unit model HMCG22B241S HMCG22B361S HMCG22B481S HMCG22B601S
Unit supply voltage 208/230 V, 1 phase, 60 Hz
Normal voltage range (V) 198 to 253
Minimum circuit ampacity (A) 15 23 35 35
Maximum overcurrent device
(A)
25 35 50 50
Minimum overcurrent device
(A)
15 25 35 35
7YORK Technical Guide: HMCG2 Series - 16 SEER2 Horizontal Discharge Modulating Air Conditioner
Johnson Controls Ducted Systems
