York HMCG2 Series User Manual

Furnace capacity - 3 ton
Table 7: Furnace capacity - 3 ton
Outdoor unit
model
Furnace model Furnace
width (in.)
Indoor coil model Stage Rated CFM Net cool
(MBH)
Sens cool
(MBH)
SEER2 EER2
High 1150 35.40 25.20 10.00
Intermediate 650 23.60 13.40 16.00
HMCG22B361S TM9Y100C16MP11 21.0 XAFC30C
Low 650 18.90 12.70
16.50
28.25
High 1150 35.60 25.40 10.00
Intermediate 700 23.80 13.50 16.10
HMCG22B361S TM9Y080B12MP11 21.0 XAF/XAFC36D
Low 700 19.00 13.20
17.00
28.35
High 1000 35.60 24.20 10.50
Intermediate 750 24.00 13.70 15.95
HMCG22B361S TM9Y060B12MP11 21.0 XAF/XAFC36D
Low 750 19.00 13.70
17.00
27.65
High 1175 35.60 25.60 10.00
Intermediate 700 23.80 13.50 16.10
HMCG22B361S TM9V100C20MP12C 24.5 XAF/XAFD48F
Low 700 19.00 13.20
17.00
28.45
High 1175 35.60 25.60 10.00
Intermediate 700 23.80 13.50 16.10
HMCG22B361S TP9C100C20MP13C 24.5 XAF/XAFD48F
Low 700 19.00 13.20
17.00
28.45
High 1175 35.60 25.60 10.00
Intermediate 700 23.80 13.50 16.10
HMCG22B361S YP9C100C20MP13C 24.5 XAF/XAFD48F
Low 700 19.00 13.20
17.00
28.45
High 1225 35.80 26.20 10.00
Intermediate 800 24.20 13.90 15.90
HMCG22B361S TM9V080C16MP12C 24.5 XAF/XAFD48F
Low 800 19.10 14.30
16.50
27.15
High 1225 35.80 26.20 10.00
Intermediate 800 24.20 13.90 15.90
HMCG22B361S TP9C080C16MP13C 24.5 XAF/XAFD48F
Low 800 19.10 14.30
16.50
27.15
High 1225 35.80 26.20 10.00
Intermediate 800 24.20 13.90 15.90
HMCG22B361S YP9C080C16MP13C 24.5 XAF/XAFD48F
Low 800 19.10 14.30
16.50
27.15
High 1050 35.80 24.80 10.50
Intermediate 750 24.00 13.70 16.05
HMCG22B361S TM9V080B12MP12C 21.0 XAFC30C
Low 750 19.10 13.80
17.00
27.95
High 1050 35.80 24.80 10.50
Intermediate 750 24.00 13.70 16.05
HMCG22B361S TP9C080B12MP13C 21.0 XAFC30C
Low 750 19.10 13.80
17.00
27.95
High 1050 35.80 24.80 10.50
Intermediate 750 24.00 13.70 16.05
HMCG22B361S YP9C080B12MP13C 21.0 XAFC30C
Low 750 19.10 13.80
17.00
27.95
High 1100 35.80 25.20 10.50
Intermediate 725 24.00 13.50 16.25
HMCG22B361S TM9V060B12MP12C 21.0 XAFC30C
Low 725 19.10 13.50
17.00
28.75
High 1100 35.80 25.20 10.50
Intermediate 725 24.00 13.50 16.25
HMCG22B361S TP9C060B12MP13C 21.0 XAFC30C
Low 725 19.10 13.50
17.00
28.75
High 1100 35.80 25.20 10.50
Intermediate 725 24.00 13.50 16.25
HMCG22B361S YP9C060B12MP13C 21.0 XAFC30C
Low 725 19.10 13.50
17.00
28.75
High 1075 36.00 25.20 10.50
Intermediate 925 24.60 14.20 15.85
HMCG22B361S TM9V040A10MP12C 17.5 XAF/XAFB36E
Low 925 19.30 15.60
16.50
26.30
High 1050 35.80 24.80 10.50
Intermediate 800 24.20 13.80 16.05
HMCG22B361S TM9E100C16MP12 21.0 XAF/XAFC36D
Low 800 19.20 14.30
17.00
27.60
High 1125 34.20 25.00 9.80
Intermediate 725 23.60 13.00 15.65
HMCG22B361S TM9E080B12MP12 21.0 XAF/XAFC36D
Low 725 18.90 13.90
16.50
27.45
High 1175 34.40 25.60 10.00
Intermediate 725 23.60 12.90 15.95
HMCG22B361S TM9E060B12MP12 21.0 XAF/XAFC36D
Low 725 18.90 13.80
17.00
28.40
High 1075 34.40 24.80 10.00
Intermediate 750 23.60 13.20 15.85
HMCG22B361S TM9E060A10MP12 17.5 XAF/XAUB30C
Low 750 18.90 14.10
16.50
27.95
