York HMCG2 Series User Manual

Performance data - 4 ton
Cooling performance data - 4 ton
Table 18: Cooling performance data - 4 ton
ID CFM 1400 1600 1800
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air temperature
entering outdoor unit
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 TC 47.3 51.4 51.2 54.9 57.7 48.8 52.2 52.0 55.6 57.9 50.5 53.1 52.9 56.4 58.3
55 SC 47.3 42.8 37.0 36.4 29.0 48.8 45.0 38.4 37.6 29.4 50.5 47.4 40.0 38.9 29.9
55 kW 3.24 3.30 3.31 3.35 3.37 3.37 3.43 3.42 3.47 3.48 3.47 3.52 3.50 3.56 3.56
65 TC 46.5 50.0 49.9 53.9 57.6 47.9 50.8 50.7 54.6 58.0 49.4 51.7 51.5 55.5 58.6
65 SC 46.5 42.6 36.6 36.3 29.1 47.9 44.8 38.2 37.7 29.7 49.4 47.2 39.8 39.2 30.5
65 kW 3.55 3.63 3.63 3.69 3.75 3.70 3.76 3.75 3.82 3.87 3.80 3.85 3.84 3.91 3.95
75 TC 45.6 48.6 48.6 52.8 57.4 47.0 49.4 49.3 53.7 58.2 48.4 50.3 50.2 54.6 59.0
75 SC 45.6 42.5 36.3 36.2 29.1 47.0 44.6 37.9 37.7 30.1 48.4 46.9 39.6 39.5 31.1
75 kW 3.87 3.95 3.95 4.04 4.14 4.02 4.08 4.08 4.17 4.26 4.13 4.18 4.18 4.26 4.35
85 TC 43.6 46.6 46.1 50.7 55.3 45.1 47.3 47.0 51.5 56.0 46.8 48.2 48.1 52.4 56.8
85 SC 43.6 41.3 34.9 35.1 28.3 45.1 43.5 36.7 36.8 29.2 46.8 45.9 38.7 38.6 30.3
85 kW 4.25 4.33 4.33 4.44 4.56 4.41 4.47 4.47 4.57 4.69 4.52 4.57 4.57 4.67 4.78
95 TC 41.7 44.6 43.6 48.6 53.1 43.3 45.3 44.7 49.3 53.8 45.1 46.2 46.0 50.2 54.6
95 SC 41.7 40.1 33.4 34.1 27.4 43.3 42.4 35.5 35.9 28.4 45.1 44.9 37.7 37.8 29.5
95 kW 4.64 4.70 4.71 4.83 4.97 4.80 4.85 4.85 4.98 5.11 4.92 4.96 4.96 5.08 5.21
105 TC 36.2 38.1 36.6 40.6 44.1 37.3 38.7 37.5 41.1 44.6 38.5 39.4 38.5 41.8 45.2
105 SC 36.2 35.6 30.0 30.5 24.1 37.3 37.2 31.7 32.1 25.0 38.5 39.0 33.4 33.8 26.0
105 kW 4.26 4.30 4.24 4.34 4.40 4.39 4.44 4.38 4.47 4.53 4.48 4.54 4.49 4.56 4.62
115 TC 30.8 31.8 29.9 32.8 35.4 31.4 32.3 30.5 33.1 35.6 32.1 32.9 31.2 33.6 36.0
115 SC 30.8 31.2 26.7 26.9 20.8 31.4 32.2 27.9 28.3 21.7 32.1 32.9 29.3 29.8 22.6
115 kW 3.90 3.92 3.78 3.86 3.85 4.00 4.04 3.93 3.98 3.97 4.06 4.14 4.04 4.05 4.05
125 TC 25.5 25.5 23.1 25.0 26.7 25.5 25.9 23.4 25.1 26.7 25.7 26.3 23.9 25.4 26.8
125 SC 25.5 25.5 23.1 23.4 17.6 25.5 25.9 23.4 24.6 18.4 25.7 26.3 23.9 25.4 19.2
125 kW 3.53 3.53 3.32 3.38 3.29 3.60 3.65 3.47 3.48 3.41 3.64 3.73 3.58 3.54 3.48
Cool multiplier airhandler - 4 ton
Table 19: Cool multiplier air handler - 4 ton
Air handler model Indoor coil model Total capacity Sensible capacity kW
JHETC48GBCS2N1 — 1.00 1.00 1.00
JHETC60HBCS2N1 — 1.00 0.96 1.01
JHETD48GBCS2N1 — 0.99 0.93 1.01
JHETD60HBCS2N1 — 1.00 0.96 1.01
JHVTC42FBCC2N1 — 0.99 0.93 1.01
JHVTC48GBCC2N1 — 0.99 0.95 1.01
JHVTC60HBCC2N1 — 1.00 0.95 1.02
JHVTD48GBCC2N1 — 0.99 0.94 1.01
JHVTD60HBCC2N1 — 1.00 0.94 1.00
89YORK Technical Guide: HMCG2 Series - 16 SEER2 Horizontal Discharge Modulating Air Conditioner
Johnson Controls Ducted Systems
