York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 117
YCE60B21S TM9V120D20MP12C 24.5 XAHD60H 1575 55.5 39.5 14.25 11.75
YCE60B21S TM9Y100C20MP11 21.0 CF/CM/CU60C 1525 54.0 39.0 14.00 11.70
YCE60B21S TM9Y100C20MP11 21.0 CF/CM/CU60D 1550 54.5 39.5 14.00 11.75
YCE60B21S TM9Y100C20MP11 21.0 CF/CM64D 1550 55.0 40.0 14.00 11.75
YCE60B21S TM9Y100C20MP11 24.5 XAF/XAUD60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TM9Y100C20MP11 21.0 XAFC60H 1550 55.5 39.0 14.00 11.75
YCE60B21S TM9Y100C20MP11 21.0 XAHC60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TM9Y100C20MP11 21.0 XAHC60H 1550 55.5 39.0 14.00 11.75
YCE60B21S TM9Y120D20MP11 24.5 CF/CM/CU60D 1600 55.0 40.5 14.25 12.00
YCE60B21S TM9Y120D20MP11 24.5 CF/CM64D 1575 55.5 40.5 14.25 11.75
YCE60B21S TM9Y120D20MP11 24.5 XAF/XAUD60G 1575 55.5 39.0 14.00 11.75
YCE60B21S TM9Y120D20MP11 24.5 XAF/XAUD60H 1575 55.5 39.5 14.25 12.00
YCE60B21S TM9Y120D20MP11 21.0 XAHD60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TM9Y120D20MP11 24.5 XAHD60H 1575 55.5 39.5 14.25 12.00
YCE60B21S TMLE080C16MP11 21.0 XAF/XAUC60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE080C16MP11 24.5 XAF/XAUD60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE080C16MP11 24.5 XAF/XAUD60H 1575 55.0 39.0 14.00 11.75
YCE60B21S TMLE080C16MP11 21.0 XAFC60H 1575 55.5 39.5 14.00 11.75
YCE60B21S TMLE080C16MP11 21.0 XAHC60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE080C16MP11 21.0 XAHC60H 1575 55.5 39.5 14.00 11.75
YCE60B21S TMLE080C16MP11 21.0 XAHD60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TMLE080C16MP11 24.5 XAHD60H 1575 55.0 39.0 14.00 11.75
YCE60B21S TMLE080C20MP11 21.0 XAF/XAUC60G 1550 55.5 38.5 14.25 12.00
YCE60B21S TMLE080C20MP11 24.5 XAF/XAUD60G 1550 55.5 38.5 14.25 12.00
YCE60B21S TMLE080C20MP11 24.5 XAF/XAUD60H 1550 55.5 39.0 14.25 12.00
YCE60B21S TMLE080C20MP11 21.0 XAFC60H 1550 56.0 39.5 14.25 12.00
YCE60B21S TMLE080C20MP11 21.0 XAHC60G 1550 55.5 38.5 14.25 12.00
YCE60B21S TMLE080C20MP11 21.0 XAHC60H 1550 56.0 39.5 14.25 12.00
YCE60B21S TMLE080C20MP11 21.0 XAHD60G 1725 55.5 40.0 14.00 11.75
YCE60B21S TMLE080C20MP11 24.5 XAHD60H 1550 55.5 39.0 14.25 12.00
YCE60B21S TMLE100C16MP11 21.0 XAF/XAUC60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE100C16MP11 24.5 XAF/XAUD60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE100C16MP11 24.5 XAF/XAUD60H 1575 55.0 39.0 14.00 11.75
YCE60B21S TMLE100C16MP11 21.0 XAFC60H 1575 55.5 39.5 14.00 11.75
YCE60B21S TMLE100C16MP11 21.0 XAHC60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE100C16MP11 21.0 XAHC60H 1575 55.5 39.5 14.00 11.75
YCE60B21S TMLE100C16MP11 21.0 XAHD60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TMLE100C16MP11 24.5 XAHD60H 1575 55.0 39.0 14.00 11.75
YCE60B21S TMLE100C20MP11 21.0 XAF/XAUC60G 1725 55.5 40.0 14.00 11.75
YCE60B21S TMLE100C20MP11 24.5 XAF/XAUD60G 1750 56.0 40.5 14.00 11.75
YCE60B21S TMLE100C20MP11 24.5 XAF/XAUD60H 1725 55.5 41.0 14.00 11.75
YCE60B21S TMLE100C20MP11 21.0 XAFC60H 1725 56.0 41.0 14.00 11.75
YCE60B21S TMLE100C20MP11 21.0 XAHC60G 1725 55.5 40.0 14.00 11.75
YCE60B21S TMLE100C20MP11 21.0 XAHC60H 1725 56.0 41.0 14.00 11.75
YCE60B21S TMLE100C20MP11 21.0 XAHD60G 1725 55.5 40.0 14.00 11.75
YCE60B21S TMLE100C20MP11 24.5 XAHD60H 1725 55.5 41.0 14.00 11.75
YCE60B21S TMLE120C16MP11 21.0 XAF/XAUC60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE120C16MP11 24.5 XAF/XAUD60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE120C16MP11 24.5 XAF/XAUD60H 1575 55.0 39.0 14.00 11.75
YCE60B21S TMLE120C16MP11 21.0 XAFC60H 1575 55.5 39.5 14.00 11.75
YCE60B21S TMLE120C16MP11 21.0 XAHC60G 1575 55.0 38.5 14.00 11.75
YCE60B21S TMLE120C16MP11 21.0 XAHC60H 1575 55.5 39.5 14.00 11.75
YCE60B21S TMLE120C16MP11 21.0 XAHD60G 1575 55.0 38.5 14.00 11.75
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
