YCE60B21S TMLE120C16MP11 24.5 XAHD60H 1575 55.0 39.0 14.00 11.75
YCE60B21S TMLE120C20MP11 21.0 XAF/XAUC60G 1750 56.0 40.5 14.00 11.75
YCE60B21S TMLE120C20MP11 24.5 XAF/XAUD60G 1750 56.0 40.5 14.00 11.75
YCE60B21S TMLE120C20MP11 24.5 XAF/XAUD60H 1750 56.0 41.5 14.00 11.75
YCE60B21S TMLE120C20MP11 21.0 XAFC60H 1750 56.5 41.5 14.00 11.75
YCE60B21S TMLE120C20MP11 21.0 XAHC60G 1750 56.0 40.5 14.00 11.75
YCE60B21S TMLE120C20MP11 21.0 XAHC60H 1750 56.5 41.5 14.00 11.75
YCE60B21S TMLE120C20MP11 21.0 XAHD60G 1725 55.5 40.0 14.00 11.75
YCE60B21S TMLE120C20MP11 24.5 XAHD60H 1750 56.0 41.5 14.00 11.75
YCE60B21S TMLE130D20MP11 24.5 XAF/XAUD60G 1625 55.5 39.0 14.25 12.00
YCE60B21S TMLE130D20MP11 24.5 XAF/XAUD60H 1625 56.0 40.0 14.25 12.00
YCE60B21S TMLE130D20MP11 21.0 XAHD60G 1600 55.5 39.0 14.25 11.75
YCE60B21S TMLE130D20MP11 24.5 XAHD60H 1625 56.0 40.0 14.25 12.00
YCE60B21S TMLV080C16MP11C 21.0 CF/CM/CU60D 1700 55.5 41.5 14.00 11.70
YCE60B21S TMLV080C16MP11C 21.0 CF/CM64D 1650 56.5 40.0 14.00 11.75
YCE60B21S TMLV080C16MP12C 21.0 CF/CM/CU60D 1700 55.5 41.5 14.00 11.70
YCE60B21S TMLV100C16MP11C 21.0 CF/CM/CU60D 1700 55.5 41.5 14.00 11.70
YCE60B21S TMLV100C16MP11C 21.0 CF/CM64D 1650 56.5 40.0 14.00 11.75
YCE60B21S TMLV100C16MP12C 21.0 CF/CM/CU60D 1700 55.5 41.5 14.00 11.70
YCE60B21S TMLV100C20MP11C 21.0 CF/CM/CU60C 1625 55.0 41.0 14.00 11.75
YCE60B21S TMLV100C20MP11C 21.0 CF/CM/CU60D 1700 55.5 39.5 14.00 11.75
YCE60B21S TMLV100C20MP12C 21.0 CF/CM/CU60C 1625 55.0 41.0 14.00 11.75
YCE60B21S TMLV100C20MP12C 21.0 CF/CM/CU60D 1625 55.5 41.0 14.50 12.00
YCE60B21S TMLV100C20MP12C 21.0 CF/CM64D 1550 55.5 40.0 14.25 12.20
YCE60B21S TMLV120C20MP11C 21.0 CF/CM/CU60C 1625 55.0 41.0 14.00 11.75
YCE60B21S TMLV120C20MP11C 21.0 CF/CM/CU60D 1700 55.5 39.5 14.00 11.75
YCE60B21S TMLV120C20MP12C 21.0 CF/CM/CU60C 1625 55.0 41.0 14.00 11.75
YCE60B21S TMLV120C20MP12C 21.0 CF/CM/CU60D 1625 55.5 41.0 14.50 12.00
YCE60B21S TMLV120C20MP12C 21.0 CF/CM64D 1550 55.5 40.0 14.25 12.20
YCE60B21S TMLV120C20MP12C 21.0 XAF/XAUC60G 1550 55.0 38.5 14.25 12.00
YCE60B21S TMLV120C20MP12C 24.5 XAF/XAUD60G 1550 55.5 38.5 14.25 12.00
YCE60B21S TMLV120C20MP12C 24.5 XAF/XAUD60H 1550 55.5 39.0 14.25 12.00
YCE60B21S TMLV120C20MP12C 21.0 XAFC60H 1550 55.5 39.0 14.25 12.00
YCE60B21S TMLV120C20MP12C 21.0 XAHC60G 1550 55.0 38.5 14.25 12.00
YCE60B21S TMLV120C20MP12C 21.0 XAHC60H 1550 55.5 39.5 14.25 12.00
YCE60B21S TMLV120C20MP12C 21.0 XAHD60G 1550 55.0 38.5 14.25 11.75
YCE60B21S TMLV120C20MP12C 24.5 XAHD60H 1550 55.0 39.0 14.25 12.00
YCE60B21S TMLX080C16MP11 21.0 CF/CM/CU60D 1550 54.0 39.0 14.00 11.70
YCE60B21S TMLX080C16MP11 21.0 CF/CM64D 1525 54.5 39.0 14.00 11.70
YCE60B21S TMLX100C16MP11 21.0 CF/CM/CU60D 1550 54.0 39.0 14.00 11.70
YCE60B21S TMLX100C16MP11 21.0 CF/CM64D 1525 54.5 39.0 14.00 11.70
YCE60B21S TMLX100C20MP11 21.0 CF/CM/CU60C 1550 54.5 39.5 14.25 12.00
YCE60B21S TMLX100C20MP11 21.0 CF/CM/CU60D 1600 55.0 40.5 14.25 12.00
YCE60B21S TMLX100C20MP11 21.0 CF/CM64D 1550 55.5 39.5 14.50 12.25
YCE60B21S TMLX120C20MP11 21.0 CF/CM/CU60C 1550 54.5 39.5 14.25 12.00
YCE60B21S TMLX120C20MP11 21.0 CF/CM/CU60D 1600 55.0 40.5 14.25 12.00
YCE60B21S TMLX120C20MP11 21.0 CF/CM64D 1550 55.5 39.5 14.50 12.25
YCE60B21S TP9C080C16MP12C 21.0 CF/CM/CU60C 1650 55.5 40.0 14.00 11.75
YCE60B21S TP9C080C16MP12C 21.0 CF/CM64D 1650 57.0 40.5 14.25 12.00
YCE60B21S TP9C100C16MP12C 21.0 CF/CM/CU60C 1600 54.5 40.0 14.00 11.75
YCE60B21S TP9C100C16MP12C 21.0 CF/CM/CU60D 1600 55.0 40.5 14.00 11.75
YCE60B21S TP9C100C16MP12C 21.0 CF/CM64D 1600 56.0 40.5 14.25 12.00
YCE60B21S TP9C100C16MP13C 21.0 CF/CM/CU60C 1600 54.5 40.0 14.00 11.75
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
