Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COIL MULTIPLIERS - 1.5 TON
Air Handler Coil T.C. S.C. kW
— CF/CM/CU18A 1.00 1.00 1.00
— CF/CM/CU18B 1.00 1.12 1.00
— CF/CM/CU24A 1.02 1.09 1.02
— CF/CM/CU24B 1.02 1.09 1.02
— CF/CM/CU30A 1.04 1.07 1.01
— CF/CM/CU30B 1.04 1.07 1.01
— CF/CM/CU36B 1.04 1.05 1.02
— CF/CM/CU36C 1.04 1.05 1.02
— CF/CM24C 1.02 1.09 1.02
— CF/CM30C 1.04 1.07 1.01
— CF/CM36D 1.04 1.05 1.02
— XAF/XAUA24B 1.02 1.07 1.02
— XAFB24B 1.02 1.07 1.02
— XAHA24B 1.02 1.07 1.02
— XAHB24B 1.02 1.07 1.02
AE18BX21 — 1.05 1.09 0.95
AE24BX21 — 1.05 1.07 0.95
AE30BX21 — 1.05 1.05 0.95
AE36CX21 — 1.05 1.06 0.95
AP18BX21 — 1.03 1.12 1.01
AP24BX21 — 1.04 1.14 1.01
AVC18BX21 — 1.05 1.09 0.95
AVC24BX21 — 1.05 1.07 0.95
AVC30BX21 — 1.05 1.09 0.95
ME08BN21 CF/CM18B 1.04 1.07 0.94
ME08BN21 CF/CM24B 1.04 1.06 0.94
ME08BN21 CF/CM30B 1.05 1.05 0.95
ME08BN21 CF/CM36B 1.05 1.02 0.95
ME12BN21 CF/CM18B 1.05 1.11 0.95
ME12BN21 CF/CM24B 1.05 1.12 0.95
ME12BN21 CF/CM30B 1.05 1.09 0.95
ME12BN21 CF/CM36B 1.05 1.09 0.95
ME12CN21 CF/CM24C 1.05 1.06 0.95
ME12CN21 CF/CM30C 1.05 1.05 0.95
ME12CN21 CF/CM36C 1.05 1.04 0.95
MVC08BN21 CF/CM18B 1.05 1.09 0.95
MVC08BN21 CF/CM24B 1.05 1.10 0.95
MVC08BN21 CF/CM30B 1.05 1.07 0.95
MVC08BN21 CF/CM36B 1.05 1.07 0.95
MVC12CN21 CF/CM24C 1.05 1.10 0.95
MVC12CN21 CF/CM30C 1.05 1.08 0.95
MVC12CN21 CF/CM36C 1.05 1.06 0.95
FURNACE MULTIPLIERS - 1.5 TON
Furnaces
Coil
T.C. S.C. kW
TL8E060A12UH11 CF/CM/CU18A 1.04 1.16 0.96
TL8E060A12UH11 CF/CM/CU18B 1.04 1.19 0.94
TL8E060A12UH11 CF/CM/CU24A 1.04 1.15 0.94
TL8E060A12UH11 CF/CM/CU24B 1.04 1.25 0.94
TL8E060A12UH11 CF/CM/CU30A 1.04 1.15 0.94
TL8E060A12UH11 CF/CM/CU30B 1.05 1.23 0.95
TL8E060A12UH11 CF/CM/CU36B 1.05 1.22 0.95
TL8E060A12UH11 CF/CM36A 1.05 1.20 0.95
TL8E060A12UH11 XAF/XAUA24B 1.04 1.07 0.96
TL8E060A12UH11 XAFB24B 1.04 1.13 0.96
TL8E060A12UH11 XAHA24B 1.04 1.07 0.96
TL8E060A12UH11 XAHB24B 1.04 1.09 0.96
TL9E060B12UH11 CF/CM/CU18B 1.03 1.19 0.95
TL9E060B12UH11 CF/CM/CU24B 1.04 1.20 0.94
TL9E060B12UH11 CF/CM/CU30B 1.05 1.20 0.95
TL9E060B12UH11 CF/CM/CU36B 1.05 1.19 0.95
TL9E060B12UH11 CF/CM/CU36C 1.05 1.22 0.95
TL9E060B12UH11 CF/CM24C 1.04 1.20 0.94
TL9E060B12UH11 CF/CM30C 1.05 1.23 0.95
TL9E060B12UH11 XAFB24B 1.04 1.09 0.96
TL9E060B12UH11 XAHB24B 1.04 1.09 0.96
TM8E040A12MP11 CF/CM/CU18A 1.04 1.19 0.94
TM8E040A12MP11 CF/CM/CU18B 1.04 1.21 0.96
TM8E040A12MP11 CF/CM/CU24A 1.04 1.20 0.94
TM8E040A12MP11 CF/CM/CU24B 1.04 1.24 0.94
TM8E040A12MP11 CF/CM/CU30A 1.04 1.17 0.94
TM8E040A12MP11 CF/CM/CU30B 1.04 1.20 0.94
TM8E040A12MP11 CF/CM/CU36B 1.05 1.22 0.95
TM8E040A12MP11 CF/CM36A 1.05 1.25 0.95
TM8E040A12MP11 XAF/XAUA24B 1.04 1.09 0.96
TM8E040A12MP11 XAFB24B 1.04 1.13 0.96
TM8E040A12MP11 XAHA24B 1.04 1.09 0.96
TM8E040A12MP11 XAHB24B 1.04 1.11 0.96
TM8E060A12MP11 CF/CM/CU30A 1.04 1.24 0.94
TM8E060A12MP11 CF/CM36A 1.05 1.25 0.95
TM8E060A12MP11 XAF/XAUA24B 1.05 1.17 0.92
TM8E060A12MP11 XAHA24B 1.05 1.17 0.92
TM8E080B12MP11 CF/CM/CU30B 1.04 1.24 0.94
TM8E080B12MP11 CF/CM/CU36B 1.05 1.25 0.95
TM8E080B12MP11 CF/CM24B 1.05 1.11 0.92
TM8E080B12MP11 XAFB24B 1.05 1.17 0.92
TM8E080B12MP11 XAHB24B 1.05 1.15 0.92
TM8E100B12MP11 CF/CM/CU18B 1.03 1.24 0.93
TM8E100B12MP11 CF/CM/CU30B 1.04 1.24 0.94
TM8E100B12MP11 CF/CM/CU36B 1.05 1.25 0.95
TM8E100B12MP11 CF/CM/CU36C 1.05 1.24 0.95
TM8E100B12MP11 CF/CM24B 1.05 1.11 0.91
TM8E100B12MP11 CF/CM30C 1.04 1.24 0.94
TM8E100B12MP11 XAFB24B 1.05 1.15 0.91
TM8E100B12MP11 XAHB24B 1.05 1.15 0.91
TM8V060A12MP11C CF/CM/CU18A 1.05 1.18 0.95
TM8V060A12MP11C CF/CM/CU18B 1.05 1.18 0.95
