York LX series Technical Guide

5581700-YTG-F-1021
128 Johnson Controls Ducted Systems
TM8V060A12MP11C CF/CM/CU24A 1.05 1.20 0.95
TM8V060A12MP11C CF/CM/CU24B 1.05 1.19 0.95
TM8V060A12MP11C CF/CM/CU30A 1.05 1.18 0.95
TM8V060A12MP11C CF/CM/CU30B 1.05 1.18 0.95
TM8V060A12MP11C CF/CM/CU36B 1.05 1.20 0.95
TM8V060A12MP11C CF/CM36A 1.05 1.20 0.95
TM8V060A12MP12C CF/CM/CU18A 1.05 1.18 0.95
TM8V060A12MP12C CF/CM/CU18B 1.05 1.18 0.95
TM8V060A12MP12C CF/CM/CU24A 1.05 1.20 0.95
TM8V060A12MP12C CF/CM/CU24B 1.05 1.19 0.95
TM8V060A12MP12C CF/CM/CU30A 1.05 1.18 0.95
TM8V060A12MP12C CF/CM/CU30B 1.05 1.18 0.95
TM8V060A12MP12C CF/CM/CU36B 1.05 1.20 0.95
TM8V060A12MP12C CF/CM36A 1.05 1.20 0.95
TM8V060A12MP12C XAF/XAUA24B 1.05 1.09 0.91
TM8V060A12MP12C XAFB24B 1.05 1.15 0.97
TM8V060A12MP12C XAHA24B 1.05 1.09 0.91
TM8V060A12MP12C XAHB24B 1.05 1.09 0.97
TM8V080B12MP11C CF/CM/CU18B 1.04 1.17 0.94
TM8V080B12MP11C CF/CM/CU24B 1.05 1.20 0.95
TM8V080B12MP11C CF/CM/CU30B 1.05 1.18 0.95
TM8V080B12MP11C CF/CM/CU36B 1.05 1.20 0.95
TM8V080B12MP11C CF/CM/CU36C 1.05 1.22 0.95
TM8V080B12MP11C CF/CM24C 1.05 1.20 0.95
TM8V080B12MP11C CF/CM30C 1.05 1.21 0.95
TM8V080B12MP12C CF/CM/CU18B 1.04 1.17 0.94
TM8V080B12MP12C CF/CM/CU24B 1.05 1.20 0.95
TM8V080B12MP12C CF/CM/CU30B 1.05 1.18 0.95
TM8V080B12MP12C CF/CM/CU36B 1.05 1.20 0.95
TM8V080B12MP12C CF/CM/CU36C 1.05 1.22 0.95
TM8V080B12MP12C CF/CM24C 1.05 1.20 0.95
TM8V080B12MP12C CF/CM30C 1.05 1.21 0.95
TM8V080B12MP12C XAFB24B 1.05 1.09 0.97
TM8V080B12MP12C XAHB24B 1.05 1.09 0.97
TM8X060A12MP11 CF/CM/CU18A 1.05 1.18 0.95
TM8X060A12MP11 CF/CM/CU18B 1.05 1.20 0.95
TM8X060A12MP11 CF/CM/CU24A 1.05 1.20 0.95
TM8X060A12MP11 CF/CM/CU24B 1.05 1.21 0.95
TM8X060A12MP11 CF/CM/CU30A 1.05 1.18 0.95
TM8X060A12MP11 CF/CM/CU30B 1.05 1.20 0.95
TM8X060A12MP11 CF/CM/CU36B 1.05 1.19 0.95
TM8X060A12MP11 CF/CM36A 1.05 1.20 0.95
TM8X080B12MP11 CF/CM/CU18B 1.05 1.23 0.95
TM8X080B12MP11 CF/CM/CU24B 1.05 1.24 0.95
TM8X080B12MP11 CF/CM/CU30B 1.05 1.21 0.95
TM8X080B12MP11 CF/CM/CU36B 1.05 1.22 0.95
TM8X080B12MP11 CF/CM24C 1.05 1.24 0.95
TM8X080B12MP11 CF/CM30C 1.05 1.21 0.95
TM8Y060A12MP11 CF/CM/CU18A 1.05 1.18 0.95
TM8Y060A12MP11 CF/CM/CU18B 1.05 1.20 0.95
TM8Y060A12MP11 CF/CM/CU24A 1.05 1.20 0.95
TM8Y060A12MP11 CF/CM/CU24B 1.05 1.21 0.95
TM8Y060A12MP11 CF/CM/CU30A 1.05 1.18 0.95
TM8Y060A12MP11 CF/CM/CU30B 1.05 1.20 0.95
TM8Y060A12MP11 CF/CM/CU36B 1.05 1.19 0.95
FURNACE MULTIPLIERS - 1.5 TON (Continued)
Furnaces
Coil
T.C. S.C. kW
TM8Y060A12MP11 CF/CM36A 1.05 1.20 0.95
TM8Y060A12MP11 XAF/XAUA24B 1.05 1.09 0.91
TM8Y060A12MP11 XAFB24B 1.05 1.11 0.97
TM8Y060A12MP11 XAHA24B 1.05 1.09 0.91
TM8Y060A12MP11 XAHB24B 1.05 1.09 0.97
TM8Y080B12MP11 CF/CM/CU18B 1.05 1.23 0.95
TM8Y080B12MP11 CF/CM/CU24B 1.05 1.24 0.95
TM8Y080B12MP11 CF/CM/CU30B 1.05 1.21 0.95
TM8Y080B12MP11 CF/CM/CU36B 1.05 1.22 0.95
TM8Y080B12MP11 CF/CM24C 1.05 1.24 0.95
TM8Y080B12MP11 CF/CM30C 1.05 1.21 0.95
TM8Y080B12MP11 XAFB24B 1.05 1.11 0.90
TM8Y080B12MP11 XAHB24B 1.05 1.11 0.91
TM9E026A08MP12 CF/CM/CU18A 1.02 1.11 0.98
TM9E026A08MP12 CF/CM/CU18B 1.03 1.15 0.99
TM9E026A08MP12 CF/CM/CU24A 1.03 1.11 0.97
TM9E026A08MP12 CF/CM/CU24B 1.03 1.15 0.97
TM9E026A08MP12 CF/CM/CU30A 1.04 1.14 0.96
TM9E026A08MP12 CF/CM/CU30B 1.04 1.16 0.96
TM9E026A08MP12 CF/CM/CU36B 1.05 1.16 0.97
TM9E026A08MP12 CF/CM36A 1.04 1.13 0.94
TM9E026A08MP12 XAF/XAUA24B 1.03 1.05 0.97
TM9E026A08MP12 XAFB24B 1.02 0.98 0.96
TM9E026A08MP12 XAHA24B 1.03 1.05 0.97
TM9E026A08MP12 XAHB24B 1.03 1.05 0.97
TM9E040A10MP11 CF/CM/CU18A 1.04 1.21 1.00
TM9E040A10MP11 CF/CM/CU18B 1.02 1.07 0.94
TM9E040A10MP11 CF/CM/CU24A 1.05 1.23 1.00
TM9E040A10MP11 CF/CM/CU24B 1.02 1.08 0.94
TM9E040A10MP11 CF/CM/CU30A 1.05 1.21 0.99
TM9E040A10MP11 CF/CM/CU30B 1.03 1.08 0.95
TM9E040A10MP11 CF/CM/CU36B 1.04 1.09 0.96
TM9E040A10MP11 CF/CM36A 1.05 1.21 0.99
TM9E040A10MP12 CF/CM/CU18A 1.03 1.15 0.99
TM9E040A10MP12 CF/CM/CU18B 1.03 1.15 0.99
TM9E040A10MP12 CF/CM/CU24A 1.03 1.14 0.97
TM9E040A10MP12 CF/CM/CU24B 1.03 1.17 0.97
TM9E040A10MP12 CF/CM/CU30A 1.04 1.15 0.96
TM9E040A10MP12 CF/CM/CU30B 1.04 1.18 0.96
TM9E040A10MP12 CF/CM/CU36B 1.05 1.20 0.95
TM9E040A10MP12 CF/CM36A 1.05 1.22 0.97
TM9E040A10MP12 XAF/XAUA24B 1.03 1.07 0.97
TM9E040A10MP12 XAFB24B 1.03 1.09 0.97
TM9E040A10MP12 XAHA24B 1.03 1.07 0.97
TM9E040A10MP12 XAHB24B 1.03 1.09 0.97
TM9E060A10MP12 CF/CM/CU18A 1.02 1.20 0.96
TM9E060A10MP12 CF/CM/CU18B 1.02 1.23 0.96
TM9E060A10MP12 CF/CM/CU24A 1.02 1.20 0.94
TM9E060A10MP12 CF/CM/CU24B 1.02 1.23 0.94
TM9E060A10MP12 CF/CM/CU30A 1.04 1.20 0.94
TM9E060A10MP12 CF/CM/CU30B 1.05 1.24 0.95
TM9E060A10MP12 CF/CM/CU36B 1.05 1.22 0.95
TM9E060A10MP12 CF/CM36A 1.05 1.22 0.95
TM9E060A10MP12 XAF/XAUA24B 1.02 1.13 0.94
TM9E060A10MP12 XAFB24B 1.02 1.15 0.94
FURNACE MULTIPLIERS - 1.5 TON (Continued)
Furnaces
Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
