York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 129
TM9E060A10MP12 XAHA24B 1.02 1.11 0.96
TM9E060A10MP12 XAHB24B 1.02 1.13 0.94
TM9E060B12MP11 CF/CM/CU18B 1.05 1.23 0.95
TM9E060B12MP11 CF/CM/CU24B 1.05 1.24 0.95
TM9E060B12MP11 CF/CM/CU30B 1.05 1.21 0.95
TM9E060B12MP11 CF/CM/CU36B 1.05 1.22 0.95
TM9E060B12MP11 CF/CM24C 1.05 1.24 0.95
TM9E060B12MP11 CF/CM30C 1.05 1.21 0.95
TM9E060B12MP12 XAFB24B 1.05 1.17 0.97
TM9E060B12MP12 XAHB24B 1.05 1.17 0.97
TM9E080C16MP11 CF/CM/CU36C 1.05 1.15 0.95
TM9E080C16MP11 CF/CM24C 1.05 1.17 0.95
TM9E080C16MP11 CF/CM30C 1.05 1.16 0.95
TM9E080C16MP11 CF/CM36D 1.05 1.15 0.95
TM9E100C16MP11 CF/CM/CU36C 1.05 1.19 0.95
TM9E100C16MP11 CF/CM24C 1.05 1.19 0.95
TM9E100C16MP11 CF/CM30C 1.05 1.19 0.95
TM9E100C16MP11 CF/CM36D 1.05 1.19 0.95
TM9V040A10MP12C CF/CM/CU18A 1.02 1.07 0.96
TM9V040A10MP12C CF/CM/CU18B 1.02 1.07 0.94
TM9V040A10MP12C CF/CM/CU24A 1.02 1.08 0.94
TM9V040A10MP12C CF/CM/CU24B 1.05 1.19 0.97
TM9V040A10MP12C CF/CM/CU30A 1.03 1.08 0.95
TM9V040A10MP12C CF/CM/CU30B 1.05 1.19 0.95
TM9V040A10MP12C CF/CM/CU36B 1.05 1.20 0.95
TM9V040A10MP12C CF/CM36A 1.05 1.20 0.97
TM9V040A10MP12C XAF/XAUA24B 1.02 1.00 0.96
TM9V040A10MP12C XAFB24B 1.03 1.01 0.97
TM9V040A10MP12C XAHA24B 1.02 1.00 0.96
TM9V040A10MP12C XAHB24B 1.03 1.01 0.97
TM9V060B12MP12C CF/CM/CU18B 1.04 1.16 0.96
TM9V060B12MP12C CF/CM/CU24B 1.05 1.16 0.95
TM9V060B12MP12C CF/CM/CU30B 1.05 1.16 0.95
TM9V060B12MP12C CF/CM/CU36B 1.05 1.15 0.95
TM9V060B12MP12C CF/CM/CU36C 1.05 1.15 0.95
TM9V060B12MP12C CF/CM24C 1.05 1.16 0.95
TM9V060B12MP12C CF/CM30C 1.05 1.16 0.95
TM9V060B12MP12C XAFB24B 1.05 1.07 0.97
TM9V060B12MP12C XAHB24B 1.05 1.07 0.97
TM9V080B12MP11C CF/CM/CU18B 1.05 1.18 0.95
TM9V080B12MP11C CF/CM/CU24B 1.05 1.24 0.95
TM9V080B12MP11C CF/CM/CU30B 1.05 1.21 0.95
TM9V080B12MP11C CF/CM/CU36B 1.05 1.22 0.95
TM9V080B12MP11C CF/CM/CU36C 1.05 1.22 0.95
TM9V080B12MP11C CF/CM24C 1.05 1.24 0.95
TM9V080B12MP11C CF/CM30C 1.05 1.21 0.95
TM9V080B12MP12C CF/CM/CU18B 1.05 1.18 0.95
TM9V080B12MP12C CF/CM/CU24B 1.05 1.24 0.95
TM9V080B12MP12C CF/CM/CU30B 1.05 1.21 0.95
TM9V080B12MP12C CF/CM/CU36B 1.05 1.22 0.95
TM9V080B12MP12C CF/CM/CU36C 1.05 1.22 0.95
TM9V080B12MP12C CF/CM24C 1.05 1.24 0.95
TM9V080B12MP12C CF/CM30C 1.05 1.21 0.95
TM9V080B12MP12C XAFB24B 1.05 1.09 0.90
TM9V080B12MP12C XAHB24B 1.05 1.09 0.91
FURNACE MULTIPLIERS - 1.5 TON (Continued)
Furnaces
Coil
T.C. S.C. kW
TM9Y040A10MP11 CF/CM/CU18A 1.04 1.21 1.00
TM9Y040A10MP11 CF/CM/CU18B 1.02 1.07 0.94
TM9Y040A10MP11 CF/CM/CU24A 1.05 1.23 1.00
TM9Y040A10MP11 CF/CM/CU24B 1.02 1.08 0.94
TM9Y040A10MP11 CF/CM/CU30A 1.05 1.21 0.99
TM9Y040A10MP11 CF/CM/CU30B 1.03 1.08 0.95
TM9Y040A10MP11 CF/CM/CU36B 1.04 1.09 0.96
TM9Y040A10MP11 CF/CM36A 1.05 1.21 0.99
TM9Y040A10MP11 XAF/XAUA24B 1.02 0.98 0.96
TM9Y040A10MP11 XAFB24B 1.02 0.98 0.96
TM9Y040A10MP11 XAHA24B 1.02 0.98 0.96
TM9Y040A10MP11 XAHB24B 1.02 0.98 0.96
TM9Y060B12MP11 CF/CM/CU18B 1.05 1.23 0.95
TM9Y060B12MP11 CF/CM/CU24B 1.05 1.24 0.95
TM9Y060B12MP11 CF/CM/CU30B 1.05 1.21 0.95
TM9Y060B12MP11 CF/CM/CU36B 1.05 1.22 0.95
TM9Y060B12MP11 CF/CM24C 1.05 1.24 0.95
TM9Y060B12MP11 CF/CM30C 1.05 1.21 0.95
TM9Y060B12MP11 XAFB24B 1.05 1.13 0.97
TM9Y060B12MP11 XAHB24B 1.05 1.11 0.97
TM9Y080B12MP11 XAFB24B 1.05 1.15 0.91
TM9Y080B12MP11 XAHB24B 1.05 1.15 0.91
TM9Y080C16MP11 CF/CM/CU36C 1.05 1.15 0.95
TM9Y080C16MP11 CF/CM24C 1.05 1.17 0.95
TM9Y080C16MP11 CF/CM30C 1.05 1.16 0.95
TM9Y080C16MP11 CF/CM36D 1.05 1.15 0.95
TM9Y100C16MP11 CF/CM/CU36C 1.05 1.19 0.95
TM9Y100C16MP11 CF/CM24C 1.05 1.19 0.95
TM9Y100C16MP11 CF/CM30C 1.05 1.19 0.95
TM9Y100C16MP11 CF/CM36D 1.05 1.19 0.95
TMLE040A12MP11 XAF/XAUA24B 1.04 1.09 0.96
TMLE040A12MP11 XAFB24B 1.04 1.13 0.96
TMLE040A12MP11 XAHA24B 1.04 1.09 0.96
TMLE040A12MP11 XAHB24B 1.04 1.11 0.96
TMLE060A12MP11 XAF/XAUA24B 1.05 1.17 0.92
TMLE060A12MP11 XAHA24B 1.05 1.17 0.92
TMLE080B12MP11 CF/CM24B 1.05 1.11 0.92
TMLE080B12MP11 XAFB24B 1.05 1.17 0.92
TMLE080B12MP11 XAHB24B 1.05 1.15 0.92
TMLE100B12MP11 CF/CM24B 1.05 1.11 0.91
TMLE100B12MP11 XAFB24B 1.05 1.15 0.91
TMLE100B12MP11 XAHB24B 1.05 1.15 0.91
TMLV060A12MP11C CF/CM/CU18A 1.05 1.18 0.95
TMLV060A12MP11C CF/CM/CU18B 1.05 1.18 0.95
TMLV060A12MP11C CF/CM/CU24A 1.05 1.20 0.95
TMLV060A12MP11C CF/CM/CU24B 1.05 1.19 0.95
TMLV060A12MP11C CF/CM/CU30A 1.05 1.18 0.95
TMLV060A12MP11C CF/CM/CU30B 1.05 1.18 0.95
TMLV060A12MP11C CF/CM/CU36B 1.05 1.20 0.95
TMLV060A12MP11C CF/CM36A 1.05 1.20 0.95
TMLV060A12MP12C CF/CM/CU18A 1.05 1.18 0.95
TMLV060A12MP12C CF/CM/CU18B 1.05 1.18 0.95
TMLV060A12MP12C CF/CM/CU24A 1.05 1.20 0.95
TMLV060A12MP12C CF/CM/CU24B 1.05 1.19 0.95
TMLV060A12MP12C CF/CM/CU30A 1.05 1.18 0.95
FURNACE MULTIPLIERS - 1.5 TON (Continued)
Furnaces
Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
