York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 13
YCE18B22S TL9E060B12UH11 17.5 XAHB24B 625 17.8 13.4 15.75 13.00
YCE18B22S TM8E040A12MP11 14.5 CF/CM/CU18A 650 17.7 14.6 16.00 13.25
YCE18B22S TM8E040A12MP11 14.5 CF/CM/CU18B 675 17.7 14.9 15.75 13.00
YCE18B22S TM8E040A12MP11 14.5 CF/CM/CU24A 650 17.7 14.7 16.00 13.25
YCE18B22S TM8E040A12MP11 14.5 CF/CM/CU24B 700 17.7 15.3 16.00 13.25
YCE18B22S TM8E040A12MP11 14.5 CF/CM/CU30A 625 17.8 14.4 16.00 13.25
YCE18B22S TM8E040A12MP11 14.5 CF/CM/CU30B 675 17.8 14.7 16.00 13.25
YCE18B22S TM8E040A12MP11 14.5 CF/CM/CU36B 700 18.0 15.0 16.00 13.25
YCE18B22S TM8E040A12MP11 14.5 CF/CM36A 725 18.0 15.4 16.00 13.25
YCE18B22S TM8E040A12MP11 14.5 XAF/XAUA24B 625 17.7 13.4 16.00 13.00
YCE18B22S TM8E040A12MP11 17.5 XAFB24B 675 17.7 13.9 16.00 13.00
YCE18B22S TM8E040A12MP11 14.5 XAHA24B 625 17.7 13.4 16.00 13.00
YCE18B22S TM8E040A12MP11 17.5 XAHB24B 650 17.7 13.7 16.00 13.00
YCE18B22S TM8E060A12MP11 14.5 CF/CM/CU30A 725 17.8 15.2 16.00 13.25
YCE18B22S TM8E060A12MP11 14.5 CF/CM36A 725 18.0 15.4 16.00 13.25
YCE18B22S TM8E060A12MP11 14.5 XAF/XAUA24B 725 18.0 14.4 16.00 13.00
YCE18B22S TM8E060A12MP11 14.5 XAHA24B 725 18.0 14.4 16.00 13.00
YCE18B22S TM8E080B12MP11 17.5 CF/CM/CU30B 725 17.8 15.2 16.00 13.25
YCE18B22S TM8E080B12MP11 17.5 CF/CM/CU36B 725 18.0 15.4 16.00 13.25
YCE18B22S TM8E080B12MP11 17.5 CF/CM24B 725 18.0 13.7 16.00 13.00
YCE18B22S TM8E080B12MP11 17.5 XAFB24B 725 18.0 14.4 16.00 13.00
YCE18B22S TM8E080B12MP11 17.5 XAHB24B 700 18.0 14.2 16.00 13.00
YCE18B22S TM8E100B12MP11 17.5 CF/CM/CU18B 700 17.6 15.2 16.00 13.25
YCE18B22S TM8E100B12MP11 17.5 CF/CM/CU30B 725 17.8 15.2 16.00 13.25
YCE18B22S TM8E100B12MP11 17.5 CF/CM/CU36B 725 18.0 15.4 16.00 13.25
YCE18B22S TM8E100B12MP11 17.5 CF/CM/CU36C 725 18.0 15.3 16.00 13.25
YCE18B22S TM8E100B12MP11 17.5 CF/CM24B 725 18.0 13.7 16.00 13.00
YCE18B22S TM8E100B12MP11 17.5 CF/CM30C 725 17.8 15.2 16.00 13.25
YCE18B22S TM8E100B12MP11 17.5 XAFB24B 700 18.0 14.1 16.00 13.00
YCE18B22S TM8E100B12MP11 17.5 XAHB24B 700 18.0 14.1 16.00 13.00
YCE18B22S TM8V060A12MP11C 14.5 CF/CM/CU18A 625 17.9 14.5 15.75 13.25
YCE18B22S TM8V060A12MP11C 14.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TM8V060A12MP11C 14.5 CF/CM/CU24A 625 18.0 14.7 16.00 13.25
YCE18B22S TM8V060A12MP11C 14.5 CF/CM/CU24B 625 18.0 14.6 16.00 13.25
YCE18B22S TM8V060A12MP11C 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TM8V060A12MP11C 14.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TM8V060A12MP11C 14.5 CF/CM/CU36B 625 18.0 14.8 16.00 13.25
YCE18B22S TM8V060A12MP11C 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM/CU18A 625 17.9 14.5 15.75 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM/CU24A 625 18.0 14.7 16.00 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM/CU24B 625 18.0 14.6 16.00 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM/CU36B 625 18.0 14.8 16.00 13.25
YCE18B22S TM8V060A12MP12C 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TM8V060A12MP12C 14.5 XAF/XAUA24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM8V060A12MP12C 17.5 XAFB24B 700 18.0 14.2 16.00 13.00
YCE18B22S TM8V060A12MP12C 14.5 XAHA24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM8V060A12MP12C 17.5 XAHB24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM8V080B12MP11C 17.5 CF/CM/CU18B 625 17.8 14.4 15.50 13.25
YCE18B22S TM8V080B12MP11C 17.5 CF/CM/CU24B 625 18.0 14.7 15.75 13.25
YCE18B22S TM8V080B12MP11C 17.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TM8V080B12MP11C 17.5 CF/CM/CU36B 625 18.0 14.7 16.00 13.25
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
