York LX series Technical Guide

5581700-YTG-F-1021
14 Johnson Controls Ducted Systems
YCE18B22S TM8V080B12MP11C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TM8V080B12MP11C 17.5 CF/CM24C 625 18.0 14.7 16.00 13.25
YCE18B22S TM8V080B12MP11C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TM8V080B12MP12C 17.5 CF/CM/CU18B 625 17.8 14.4 15.50 13.25
YCE18B22S TM8V080B12MP12C 17.5 CF/CM/CU24B 625 18.0 14.7 15.75 13.25
YCE18B22S TM8V080B12MP12C 17.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TM8V080B12MP12C 17.5 CF/CM/CU36B 625 18.0 14.7 16.00 13.25
YCE18B22S TM8V080B12MP12C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TM8V080B12MP12C 17.5 CF/CM24C 625 18.0 14.7 16.00 13.25
YCE18B22S TM8V080B12MP12C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TM8V080B12MP12C 17.5 XAFB24B 625 18.0 13.4 15.75 13.00
YCE18B22S TM8V080B12MP12C 17.5 XAHB24B 625 18.0 13.4 15.75 13.00
YCE18B22S TM8X060A12MP11 14.5 CF/CM/CU18A 625 17.9 14.5 15.50 13.25
YCE18B22S TM8X060A12MP11 14.5 CF/CM/CU18B 650 17.9 14.8 15.75 13.25
YCE18B22S TM8X060A12MP11 14.5 CF/CM/CU24A 625 18.0 14.7 15.75 13.25
YCE18B22S TM8X060A12MP11 14.5 CF/CM/CU24B 650 18.0 14.9 16.00 13.25
YCE18B22S TM8X060A12MP11 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TM8X060A12MP11 14.5 CF/CM/CU30B 650 18.0 14.8 16.00 13.25
YCE18B22S TM8X060A12MP11 14.5 CF/CM/CU36B 650 18.0 14.6 16.00 13.25
YCE18B22S TM8X060A12MP11 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TM8X080B12MP11 17.5 CF/CM/CU18B 675 18.0 15.1 16.00 13.25
YCE18B22S TM8X080B12MP11 17.5 CF/CM/CU24B 675 18.0 15.2 16.00 13.25
YCE18B22S TM8X080B12MP11 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TM8X080B12MP11 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TM8X080B12MP11 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
YCE18B22S TM8X080B12MP11 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM/CU18A 625 17.9 14.5 15.50 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM/CU18B 650 17.9 14.8 15.75 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM/CU24A 625 18.0 14.7 15.75 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM/CU24B 650 18.0 14.9 16.00 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM/CU30B 650 18.0 14.8 16.00 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM/CU36B 650 18.0 14.6 16.00 13.25
YCE18B22S TM8Y060A12MP11 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TM8Y060A12MP11 14.5 XAF/XAUA24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM8Y060A12MP11 17.5 XAFB24B 650 18.0 13.7 16.00 13.00
YCE18B22S TM8Y060A12MP11 14.5 XAHA24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM8Y060A12MP11 17.5 XAHB24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM8Y080B12MP11 17.5 CF/CM/CU18B 675 18.0 15.1 16.00 13.25
YCE18B22S TM8Y080B12MP11 17.5 CF/CM/CU24B 675 18.0 15.2 16.00 13.25
YCE18B22S TM8Y080B12MP11 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TM8Y080B12MP11 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TM8Y080B12MP11 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
YCE18B22S TM8Y080B12MP11 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TM8Y080B12MP11 17.5 XAFB24B 650 18.0 13.7 16.00 13.00
YCE18B22S TM8Y080B12MP11 17.5 XAHB24B 650 18.0 13.7 16.00 13.00
YCE18B22S TM9E026A08MP12 14.5 CF/CM/CU18A 550 17.4 13.6 15.25 12.50
YCE18B22S TM9E026A08MP12 14.5 CF/CM/CU18B 600 17.6 14.2 15.25 12.50
YCE18B22S TM9E026A08MP12 14.5 CF/CM/CU24A 550 17.6 13.6 15.50 12.75
YCE18B22S TM9E026A08MP12 14.5 CF/CM/CU24B 600 17.6 14.2 15.50 12.75
YCE18B22S TM9E026A08MP12 14.5 CF/CM/CU30A 575 17.7 14.0 15.75 13.00
YCE18B22S TM9E026A08MP12 14.5 CF/CM/CU30B 600 17.8 14.3 15.75 13.00
YCE18B22S TM9E026A08MP12 14.5 CF/CM/CU36B 600 18.0 14.3 15.75 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
