York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 135
TM8V080C16MP12C CF/CM30C 1.01 1.14 0.93
TM8V080C16MP12C CF/CM36D 1.01 1.16 0.93
TM8V080C16MP12C CF/CM42D 1.01 1.14 0.93
TM8V080C16MP12C XAFC30C 1.01 1.14 0.92
TM8V080C16MP12C XAHC30C 1.01 1.14 0.92
TM8V100C16MP11C CF/CM/CU36C 1.01 1.16 0.93
TM8V100C16MP11C CF/CM/CU42C 1.01 1.14 0.93
TM8V100C16MP11C CF/CM24C 1.01 1.16 0.93
TM8V100C16MP11C CF/CM30C 1.01 1.14 0.93
TM8V100C16MP11C CF/CM36D 1.01 1.16 0.93
TM8V100C16MP11C CF/CM42D 1.01 1.14 0.93
TM8V100C16MP12C CF/CM/CU36C 1.01 1.16 0.93
TM8V100C16MP12C CF/CM/CU42C 1.01 1.14 0.93
TM8V100C16MP12C CF/CM24C 1.01 1.16 0.93
TM8V100C16MP12C CF/CM30C 1.01 1.14 0.93
TM8V100C16MP12C CF/CM36D 1.01 1.16 0.93
TM8V100C16MP12C CF/CM42D 1.01 1.14 0.93
TM8V100C16MP12C XAFC30C 1.01 1.14 0.92
TM8V100C16MP12C XAHC30C 1.01 1.14 0.92
TM8X060A12MP11 CF/CM/CU24A 1.00 1.01 0.92
TM8X060A12MP11 CF/CM/CU24B 1.01 1.03 0.93
TM8X060A12MP11 CF/CM/CU30A 1.01 1.01 0.93
TM8X060A12MP11 CF/CM/CU30B 1.01 1.02 0.93
TM8X060A12MP11 CF/CM/CU36B 1.01 1.04 0.93
TM8X060A12MP11 CF/CM36A 1.01 1.06 0.93
TM8X060A12MP11 CF42B 1.01 1.10 0.93
TM8X080B12MP11 CF/CM/CU24B 1.01 1.10 0.93
TM8X080B12MP11 CF/CM/CU30B 1.01 1.09 0.93
TM8X080B12MP11 CF/CM/CU36B 1.01 1.11 0.93
TM8X080B12MP11 CF/CM/CU36C 1.01 1.12 0.93
TM8X080B12MP11 CF/CM/CU42C 1.01 1.12 0.93
TM8X080B12MP11 CF/CM24C 1.01 1.10 0.93
TM8X080B12MP11 CF/CM30C 1.01 1.09 0.93
TM8X080B12MP11 CF42B 1.01 1.04 0.93
TM8X080C16MP11 CF/CM/CU36C 1.01 1.05 0.93
TM8X080C16MP11 CF/CM/CU42C 1.01 1.05 0.93
TM8X080C16MP11 CF/CM24C 1.01 1.06 0.93
TM8X080C16MP11 CF/CM30C 1.01 1.05 0.93
TM8X080C16MP11 CF/CM36D 1.01 1.08 0.93
TM8X080C16MP11 CF/CM42D 1.01 1.05 0.93
TM8X100C16MP11 CF/CM/CU36C 1.01 1.05 0.93
TM8X100C16MP11 CF/CM/CU42C 1.01 1.05 0.93
TM8X100C16MP11 CF/CM24C 1.01 1.06 0.93
TM8X100C16MP11 CF/CM30C 1.01 1.05 0.93
TM8X100C16MP11 CF/CM36D 1.01 1.08 0.93
TM8X100C16MP11 CF/CM42D 1.01 1.05 0.93
TM8Y060A12MP11 CF/CM/CU24A 1.00 1.01 0.92
TM8Y060A12MP11 CF/CM/CU24B 1.01 1.03 0.93
TM8Y060A12MP11 CF/CM/CU30A 1.01 1.01 0.93
TM8Y060A12MP11 CF/CM/CU30B 1.01 1.02 0.93
TM8Y060A12MP11 CF/CM/CU36B 1.01 1.04 0.93
TM8Y060A12MP11 CF/CM36A 1.01 1.06 0.93
TM8Y060A12MP11 CF42B 1.01 1.10 0.93
TM8Y060A12MP11 XAF/XAUA24B 1.01 1.04 0.95
TM8Y060A12MP11 XAF/XAUB30C 1.01 1.05 0.93
TM8Y060A12MP11 XAFB24B 0.98 0.96 0.91
TM8Y060A12MP11 XAHB24B 1.00 1.00 0.94
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM8Y060A12MP11 XAHB30C 1.01 1.03 0.93
TM8Y080B12MP11 CF/CM/CU24B 1.01 1.10 0.93
TM8Y080B12MP11 CF/CM/CU30B 1.01 1.09 0.93
TM8Y080B12MP11 CF/CM/CU36B 1.01 1.11 0.93
TM8Y080B12MP11 CF/CM/CU36C 1.01 1.12 0.93
TM8Y080B12MP11 CF/CM/CU42C 1.01 1.12 0.93
TM8Y080B12MP11 CF/CM24C 1.01 1.10 0.93
TM8Y080B12MP11 CF/CM30C 1.01 1.09 0.93
TM8Y080B12MP11 CF42B 1.01 1.04 0.93
TM8Y080B12MP11 XAF/XAUB30C 1.01 1.08 0.91
TM8Y080B12MP11 XAFB24B 1.01 1.08 0.93
TM8Y080B12MP11 XAFC30C 1.01 1.08 0.93
TM8Y080B12MP11 XAHB24B 1.01 1.08 0.93
TM8Y080B12MP11 XAHB30C 1.01 1.11 0.92
TM8Y080B12MP11 XAHC30C 1.01 1.11 0.93
TM8Y080C16MP11 CF/CM/CU36C 1.01 1.05 0.93
TM8Y080C16MP11 CF/CM/CU42C 1.01 1.05 0.93
TM8Y080C16MP11 CF/CM24C 1.01 1.06 0.93
TM8Y080C16MP11 CF/CM30C 1.01 1.05 0.93
TM8Y080C16MP11 CF/CM36D 1.01 1.08 0.93
TM8Y080C16MP11 CF/CM42D 1.01 1.05 0.93
TM8Y080C16MP11 XAFC30C 1.01 1.04 0.89
TM8Y080C16MP11 XAHC30C 1.01 1.04 0.89
TM8Y100C16MP11 CF/CM/CU36C 1.01 1.05 0.93
TM8Y100C16MP11 CF/CM/CU42C 1.01 1.05 0.93
TM8Y100C16MP11 CF/CM24C 1.01 1.06 0.93
TM8Y100C16MP11 CF/CM30C 1.01 1.05 0.93
TM8Y100C16MP11 CF/CM36D 1.01 1.08 0.93
TM8Y100C16MP11 CF/CM42D 1.01 1.05 0.93
TM8Y100C16MP11 XAFC30C 1.01 1.04 0.89
TM8Y100C16MP11 XAHC30C 1.01 1.04 0.89
TM9E026A08MP12 CF/CM/CU24A 1.01 1.05 0.97
TM9E026A08MP12 CF/CM/CU24B 0.98 0.98 0.94
TM9E026A08MP12 CF/CM/CU30A 1.01 1.06 0.95
TM9E026A08MP12 CF/CM/CU30B 1.01 1.08 0.95
TM9E026A08MP12 CF/CM/CU36B 1.01 1.08 0.95
TM9E026A08MP12 CF/CM36A 1.01 1.06 0.95
TM9E026A08MP12 CF42B 1.01 1.01 0.93
TM9E026A08MP12 XAF/XAUA24B 0.99 0.98 0.95
TM9E026A08MP12 XAF/XAUB30C 1.01 1.02 0.95
TM9E026A08MP12 XAFB24B 0.98 0.98 0.94
TM9E026A08MP12 XAHB24B 0.98 0.98 0.94
TM9E026A08MP12 XAHB30C 1.01 1.01 0.95
TM9E040A10MP11 CF/CM/CU24A 1.00 1.04 0.96
TM9E040A10MP11 CF/CM/CU24B 1.01 1.06 0.97
TM9E040A10MP11 CF/CM/CU30A 1.01 1.04 0.97
TM9E040A10MP11 CF/CM/CU30B 1.01 1.06 0.95
TM9E040A10MP11 CF/CM/CU36B 1.01 1.05 0.95
TM9E040A10MP11 CF/CM36A 1.01 1.04 0.97
TM9E040A10MP11 CF42B 1.01 1.04 0.95
TM9E040A10MP12 CF/CM/CU24A 0.98 0.98 0.94
TM9E040A10MP12 CF/CM/CU24B 0.99 1.00 0.95
TM9E040A10MP12 CF/CM/CU30A 1.01 1.00 0.95
TM9E040A10MP12 CF/CM/CU30B 1.01 1.01 0.95
TM9E040A10MP12 CF/CM/CU36B 1.01 1.05 0.93
TM9E040A10MP12 CF/CM36A 1.01 1.05 0.95
TM9E040A10MP12 CF42B 1.01 1.02 0.93
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
