York LX series Technical Guide

5581700-YTG-F-1021
136 Johnson Controls Ducted Systems
TM9E040A10MP12 XAF/XAUA24B 0.97 0.93 0.94
TM9E040A10MP12 XAF/XAUB30C 1.00 0.97 0.94
TM9E040A10MP12 XAFB24B 0.98 0.98 0.94
TM9E040A10MP12 XAHB24B 0.98 0.98 0.94
TM9E040A10MP12 XAHB30C 1.00 0.98 0.94
TM9E060A10MP12 CF/CM/CU24A 1.01 1.04 0.95
TM9E060A10MP12 CF/CM/CU24B 1.01 1.06 0.95
TM9E060A10MP12 CF/CM/CU30A 1.01 1.04 0.93
TM9E060A10MP12 CF/CM/CU30B 1.01 1.05 0.93
TM9E060A10MP12 CF/CM/CU36B 1.01 1.06 0.93
TM9E060A10MP12 CF/CM36A 1.01 1.05 0.93
TM9E060A10MP12 CF42B 1.01 1.05 0.93
TM9E060A10MP12 XAF/XAUA24B 1.00 0.98 0.94
TM9E060A10MP12 XAF/XAUB30C 1.01 1.03 0.93
TM9E060A10MP12 XAFB24B 1.00 1.00 0.94
TM9E060A10MP12 XAHB24B 1.00 0.98 0.94
TM9E060A10MP12 XAHB30C 1.01 1.01 0.93
TM9E060B12MP11 CF/CM/CU24B 1.01 1.04 0.93
TM9E060B12MP11 CF/CM/CU30B 1.01 1.05 0.93
TM9E060B12MP11 CF/CM/CU36B 1.01 1.05 0.93
TM9E060B12MP11 CF/CM/CU36C 1.01 1.05 0.93
TM9E060B12MP11 CF/CM/CU42C 1.01 1.05 0.93
TM9E060B12MP11 CF/CM24C 1.01 1.04 0.93
TM9E060B12MP11 CF/CM30C 1.01 1.05 0.93
TM9E060B12MP11 CF42B 1.01 1.04 0.93
TM9E060B12MP12 CF/CM/CU24B 1.01 1.09 0.93
TM9E060B12MP12 CF/CM/CU30B 1.01 1.07 0.93
TM9E060B12MP12 CF/CM/CU36B 1.01 1.09 0.93
TM9E060B12MP12 CF/CM/CU36C 1.01 1.09 0.93
TM9E060B12MP12 CF/CM/CU42C 1.01 1.07 0.93
TM9E060B12MP12 CF/CM24C 1.01 1.09 0.93
TM9E060B12MP12 CF/CM30C 1.01 1.07 0.93
TM9E060B12MP12 CF42B 1.01 1.05 0.93
TM9E060B12MP12 XAF/XAUB30C 1.01 1.04 0.91
TM9E060B12MP12 XAFB24B 1.01 1.01 0.95
TM9E060B12MP12 XAFC30C 1.01 1.04 0.93
TM9E060B12MP12 XAHB24B 1.01 1.01 0.95
TM9E060B12MP12 XAHB30C 1.01 1.04 0.91
TM9E060B12MP12 XAHC30C 1.01 1.04 0.93
TM9E080B12MP11 CF/CM/CU24B 1.01 1.06 0.93
TM9E080B12MP11 CF/CM/CU30B 1.01 1.05 0.93
TM9E080B12MP11 CF/CM/CU36B 1.01 1.05 0.93
TM9E080B12MP11 CF/CM/CU36C 1.01 1.05 0.93
TM9E080B12MP11 CF/CM/CU42C 1.01 1.05 0.93
TM9E080B12MP11 CF/CM24C 1.01 1.06 0.93
TM9E080B12MP11 CF/CM30C 1.01 1.05 0.93
TM9E080B12MP11 CF42B 1.01 1.04 0.93
TM9E080B12MP12 CF/CM/CU24B 1.01 1.11 0.93
TM9E080B12MP12 CF/CM/CU30B 1.01 1.12 0.93
TM9E080B12MP12 CF/CM/CU36B 1.01 1.12 0.93
TM9E080B12MP12 CF/CM/CU36C 1.01 1.11 0.93
TM9E080B12MP12 CF/CM/CU42C 1.01 1.11 0.93
TM9E080B12MP12 CF/CM24C 1.01 1.11 0.93
TM9E080B12MP12 CF/CM30C 1.01 1.10 0.93
TM9E080B12MP12 CF42B 1.01 1.10 0.93
TM9E080B12MP12 XAF/XAUB30C 1.01 1.09 0.91
TM9E080B12MP12 XAFB24B 1.01 1.05 0.93
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM9E080B12MP12 XAFC30C 1.01 1.09 0.93
TM9E080B12MP12 XAHB24B 1.01 1.04 0.93
TM9E080B12MP12 XAHB30C 1.01 1.08 0.92
TM9E080B12MP12 XAHC30C 1.01 1.08 0.93
TM9E080C16MP11 CF/CM/CU36C 1.01 1.02 0.93
TM9E080C16MP11 CF/CM/CU42C 1.01 1.00 0.93
TM9E080C16MP11 CF/CM24C 0.99 0.99 0.92
TM9E080C16MP11 CF/CM30C 1.01 1.00 0.93
TM9E080C16MP11 CF/CM36D 1.01 1.02 0.93
TM9E080C16MP11 CF/CM42D 1.01 1.00 0.93
TM9E080C16MP12 CF/CM/CU36C 1.01 1.09 0.93
TM9E080C16MP12 CF/CM/CU42C 1.01 1.07 0.93
TM9E080C16MP12 CF/CM24C 1.01 1.08 0.93
TM9E080C16MP12 CF/CM30C 1.01 1.07 0.93
TM9E080C16MP12 CF/CM36D 1.01 1.15 0.93
TM9E080C16MP12 CF/CM42D 1.01 1.17 0.93
TM9E080C16MP12 XAFC30C 1.01 1.04 0.90
TM9E080C16MP12 XAHC30C 1.01 1.14 0.92
TM9E100C16MP11 CF/CM/CU36C 1.01 1.03 0.93
TM9E100C16MP11 CF/CM/CU42C 1.01 1.02 0.93
TM9E100C16MP11 CF/CM24C 1.00 1.01 0.92
TM9E100C16MP11 CF/CM30C 1.01 1.01 0.93
TM9E100C16MP11 CF/CM36D 1.01 1.03 0.93
TM9E100C16MP11 CF/CM42D 1.01 1.02 0.93
TM9E100C16MP12 CF/CM/CU36C 1.01 1.11 0.93
TM9E100C16MP12 CF/CM/CU42C 1.01 1.11 0.93
TM9E100C16MP12 CF/CM24C 1.01 1.10 0.93
TM9E100C16MP12 CF/CM30C 1.01 1.11 0.93
TM9E100C16MP12 CF/CM36D 1.01 1.11 0.93
TM9E100C16MP12 CF/CM42D 1.01 1.11 0.93
TM9E100C16MP12 XAFC30C 1.01 1.05 0.90
TM9E100C16MP12 XAHC30C 1.01 1.05 0.90
TM9V040A10MP12C CF/CM/CU24A 0.99 0.99 0.95
TM9V040A10MP12C CF/CM/CU24B 0.99 1.00 0.93
TM9V040A10MP12C CF/CM/CU30A 1.01 1.15 1.01
TM9V040A10MP12C CF/CM/CU30B 1.01 1.01 0.93
TM9V040A10MP12C CF/CM/CU36B 1.01 1.03 0.93
TM9V040A10MP12C CF/CM36A 1.01 1.03 0.93
TM9V040A10MP12C CF42B 1.01 1.02 0.93
TM9V040A10MP12C XAF/XAUA24B 0.98 0.96 0.94
TM9V040A10MP12C XAF/XAUB30C 1.01 1.04 0.95
TM9V040A10MP12C XAFB24B 0.98 0.97 0.93
TM9V040A10MP12C XAHB24B 0.98 0.97 0.93
TM9V040A10MP12C XAHB30C 1.01 0.99 0.95
TM9V060B12MP12C CF/CM/CU24B 1.01 1.06 0.93
TM9V060B12MP12C CF/CM/CU30B 1.01 1.05 0.93
TM9V060B12MP12C CF/CM/CU36B 1.01 1.03 0.93
TM9V060B12MP12C CF/CM/CU36C 1.01 1.03 0.93
TM9V060B12MP12C CF/CM/CU42C 1.01 1.05 0.93
TM9V060B12MP12C CF/CM24C 1.01 1.06 0.93
TM9V060B12MP12C CF/CM30C 1.01 1.05 0.93
TM9V060B12MP12C CF42B 1.01 1.05 0.93
TM9V060B12MP12C XAF/XAUB30C 1.01 1.07 0.92
TM9V060B12MP12C XAFB24B 1.00 0.99 0.94
TM9V060B12MP12C XAFC30C 1.01 1.07 0.93
TM9V060B12MP12C XAHB24B 1.00 0.99 0.94
TM9V060B12MP12C XAHB30C 1.01 1.03 0.93
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
