York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 143
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COIL MULTIPLIERS - 2.5 TON
Air Handler Coil T.C. S.C. kW
— CF/CM/CU30B 1.00 1.00 1.00
— CF/CM/CU36B 1.00 1.08 1.00
— CF/CM/CU36C 1.00 1.08 1.00
— CF/CM/CU42C 1.01 1.07 1.01
— CF/CM30C 1.00 1.09 1.00
— CF/CM36A 1.00 1.04 1.00
— CF/CM36D 1.00 1.08 1.00
— CF/CM42D 1.01 1.07 1.01
— XAF/XAUB30C 1.00 1.05 1.00
— XAF/XAUB36D 1.00 1.04 1.00
— XAFA30D 0.94 0.96 0.96
— XAFC30C 1.00 1.05 1.00
— XAFC36D 1.00 1.04 1.00
— XAHB30C 1.00 1.05 1.00
— XAHB36D 1.00 0.99 1.00
— XAHC30C 1.00 1.05 1.00
— XAHC36D 1.00 1.04 1.00
AE30BX21 — 1.01 1.02 0.93
AE36BX21 — 1.01 0.99 0.91
AE36CX21 — 1.01 1.06 0.91
AP30BX21 — 1.00 1.00 1.00
AP36CX21 — 1.01 1.12 1.01
AVC30BX21 — 1.00 1.01 0.92
AVC36BX21 — 1.01 1.00 0.91
AVC36CX21 — 1.01 1.03 0.91
ME08BN21 CF/CM30B 1.01 1.04 0.91
ME08BN21 CF/CM36B 1.01 1.03 0.91
ME08BN21 CF42B 1.01 1.02 0.91
ME12BN21 CF/CM30B 1.01 1.01 0.91
ME12BN21 CF/CM36B 1.01 1.00 0.91
ME12BN21 CF42B 1.01 1.02 0.91
ME12CN21 CF/CM30C 1.01 1.08 0.91
ME12CN21 CF/CM36C 1.01 0.99 0.91
ME12CN21 CF/CM42C 1.01 1.08 0.91
ME14DN21 CF/CM36D 1.01 1.09 0.91
ME14DN21 CF/CM42D 1.01 1.08 0.91
ME16CN21 CF/CM30C 1.01 1.04 0.91
ME16CN21 CF/CM36C 1.01 1.03 0.91
ME16CN21 CF/CM42C 1.01 1.03 0.91
MVC08BN21 CF/CM30B 1.00 1.01 0.92
MVC08BN21 CF/CM36B 1.01 0.99 0.91
MVC08BN21 CF42B 1.01 1.02 0.91
MVC12BN21 CF/CM30B 1.01 1.03 0.91
MVC12BN21 CF/CM36B 1.01 1.02 0.91
MVC12BN21 CF42B 1.01 1.02 0.91
MVC12CN21 CF/CM30C 1.01 1.08 0.91
MVC12CN21 CF/CM36C 1.01 1.10 0.91
MVC12CN21 CF/CM42C 1.01 1.06 0.91
MVC14DN21 CF/CM36D 1.01 1.10 0.91
MVC14DN21 CF/CM42D 1.01 1.07 0.91
MVC16CN21 CF/CM30C 1.01 1.13 0.91
MVC16CN21 CF/CM36C 1.01 1.04 0.91
MVC16CN21 CF/CM42C 1.01 1.12 0.91
FURNACE MULTIPLIERS - 2.5 TON
Furnaces Coil T.C. S.C. kW
TL8E060A12UH11 CF/CM/CU30B 1.00 1.03 0.96
TL8E060A12UH11 CF/CM/CU36B 1.01 1.03 0.97
TL8E060A12UH11 CF/CM36A 0.99 1.00 0.95
TL8E060A12UH11 CF42B 1.01 1.03 0.97
TL8E060A12UH11 XAF/XAUB30C 1.00 0.97 0.96
TL8E060A12UH11 XAF/XAUB36D 1.00 0.94 0.96
TL8E060A12UH11 XAFA30D 0.94 0.93 0.92
TL8E060A12UH11 XAHB30C 0.99 0.95 0.95
TL8E060A12UH11 XAHB36D 0.99 0.93 0.95
TL8E080C16UH11 CF/CM/CU36C 1.01 1.07 0.95
TL8E080C16UH11 CF/CM/CU42C 1.01 1.07 0.95
TL8E080C16UH11 CF/CM30C 1.01 1.07 0.97
TL8E080C16UH11 CF/CM36D 1.01 1.07 0.97
TL8E080C16UH11 CF/CM42D 1.01 1.07 0.97
TL8E080C16UH11 XAFC30C 1.01 1.00 0.97
TL8E080C16UH11 XAFC36D 1.01 0.98 0.95
TL8E080C16UH11 XAHC30C 1.01 1.00 0.97
TL8E080C16UH11 XAHC36D 1.01 0.98 0.95
TL8E100C20UH11 CF/CM/CU36C 1.01 1.12 0.95
TL8E100C20UH11 CF/CM/CU42C 1.01 1.11 0.95
TL8E100C20UH11 CF/CM30C 1.01 1.12 0.95
TL8E100C20UH11 CF/CM36D 1.01 1.12 0.97
TL8E100C20UH11 CF/CM42D 1.01 1.11 0.95
TL8E100C20UH11 XAFC30C 1.01 1.07 0.95
TL8E100C20UH11 XAFC36D 1.01 1.04 0.95
TL8E100C20UH11 XAHC30C 1.01 1.05 0.95
TL8E100C20UH11 XAHC36D 1.01 1.03 0.95
TL9E060B12UH11 CF/CM/CU30B 1.00 1.03 0.96
TL9E060B12UH11 CF/CM/CU36B 1.01 1.03 0.97
TL9E060B12UH11 CF/CM/CU36C 1.01 1.04 0.97
TL9E060B12UH11 CF/CM/CU42C 1.01 1.05 0.97
TL9E060B12UH11 CF/CM30C 1.00 1.03 0.96
TL9E060B12UH11 CF42B 1.01 1.03 0.97
TL9E060B12UH11 XAF/XAUB30C 1.00 0.97 0.96
TL9E060B12UH11 XAF/XAUB36D 0.99 0.94 0.95
TL9E060B12UH11 XAFC30C 0.99 0.97 0.95
TL9E060B12UH11 XAFC36D 1.00 0.95 0.96
TL9E060B12UH11 XAHB30C 0.99 0.95 0.95
TL9E060B12UH11 XAHB36D 0.99 0.93 0.95
TL9E060B12UH11 XAHC30C 0.99 0.97 0.95
TL9E060B12UH11 XAHC36D 0.99 0.94 0.95
TL9E080C16UH11 CF/CM/CU36C 1.01 1.05 0.95
TL9E080C16UH11 CF/CM/CU42C 1.01 1.06 0.95
TL9E080C16UH11 CF/CM30C 1.01 1.06 0.97
TL9E080C16UH11 CF/CM36D 1.01 1.05 0.97
TL9E080C16UH11 CF/CM42D 1.01 1.06 0.97
TL9E080C16UH11 XAFC30C 1.01 0.98 0.97
TL9E080C16UH11 XAFC36D 1.01 0.96 0.95
TL9E080C16UH11 XAHC30C 1.01 0.98 0.97
COIL MULTIPLIERS - 2.5 TON

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
