York LX series Technical Guide

5581700-YTG-F-1021
144 Johnson Controls Ducted Systems
TL9E080C16UH11 XAHC36D 1.01 0.96 0.95
TL9E100C20UH11 CF/CM/CU36C 1.01 1.16 0.97
TL9E100C20UH11 CF/CM/CU42C 1.01 1.15 0.95
TL9E100C20UH11 CF/CM30C 1.01 1.15 0.97
TL9E100C20UH11 CF/CM36D 1.01 1.19 0.97
TL9E100C20UH11 CF/CM42D 1.01 1.16 0.97
TL9E100C20UH11 XAFC30C 1.01 1.10 0.97
TL9E100C20UH11 XAFC36D 1.01 1.07 0.97
TL9E100C20UH11 XAHC30C 1.01 1.08 0.97
TL9E100C20UH11 XAHC36D 1.01 1.07 0.97
TM8E040A12MP11 CF/CM/CU30B 1.01 1.05 0.97
TM8E040A12MP11 CF/CM/CU36B 0.99 0.96 0.95
TM8E040A12MP11 CF/CM36A 0.99 1.00 0.95
TM8E040A12MP11 CF42B 0.99 0.97 0.95
TM8E040A12MP11 XAF/XAUB30C 1.00 0.98 0.96
TM8E040A12MP11 XAF/XAUB36D 0.99 0.96 0.95
TM8E040A12MP11 XAFA30D 0.94 0.93 0.92
TM8E040A12MP11 XAHB30C 1.00 0.97 0.96
TM8E040A12MP11 XAHB36D 0.99 0.94 0.95
TM8E060A12MP11 CF/CM/CU30B 0.99 1.02 0.95
TM8E060A12MP11 CF/CM/CU36B 0.99 0.96 0.95
TM8E060A12MP11 CF/CM36A 0.99 1.00 0.95
TM8E060A12MP11 CF42B 1.01 1.01 0.97
TM8E060A12MP11 XAF/XAUB30C 0.99 0.94 0.95
TM8E060A12MP11 XAF/XAUB36D 0.99 0.96 0.95
TM8E060A12MP11 XAFA30D 0.94 0.93 0.92
TM8E060A12MP11 XAHB30C 0.99 0.97 0.95
TM8E060A12MP11 XAHB36D 0.99 0.94 0.95
TM8E080B12MP11 CF/CM/CU30B 1.01 1.06 0.97
TM8E080B12MP11 CF/CM/CU36B 1.01 1.04 0.97
TM8E080B12MP11 CF/CM/CU36C 1.01 1.05 0.97
TM8E080B12MP11 CF/CM/CU42C 1.01 1.06 0.97
TM8E080B12MP11 CF/CM30C 1.01 1.06 0.97
TM8E080B12MP11 CF42B 1.01 1.05 0.97
TM8E080B12MP11 XAF/XAUB30C 1.01 1.00 0.97
TM8E080B12MP11 XAF/XAUB36D 1.01 0.97 0.97
TM8E080B12MP11 XAFC30C 1.00 1.00 0.96
TM8E080B12MP11 XAFC36D 1.01 0.97 0.97
TM8E080B12MP11 XAHB30C 1.01 0.98 0.97
TM8E080B12MP11 XAHB36D 1.00 0.96 0.96
TM8E080B12MP11 XAHC30C 1.00 0.98 0.96
TM8E080B12MP11 XAHC36D 1.01 0.97 0.97
TM8E080C16MP11 CF/CM/CU36C 1.01 1.00 0.95
TM8E080C16MP11 CF/CM/CU42C 1.01 1.07 0.95
TM8E080C16MP11 CF/CM30C 1.01 1.07 0.97
TM8E080C16MP11 CF/CM36D 1.01 1.07 0.97
TM8E080C16MP11 CF/CM42D 1.01 1.07 0.97
TM8E080C16MP11 XAFC30C 1.01 1.01 0.97
TM8E080C16MP11 XAFC36D 1.01 0.98 0.95
TM8E080C16MP11 XAHC30C 1.01 1.00 0.97
TM8E080C16MP11 XAHC36D 1.01 0.98 0.95
TM8E080C20MP11 XAFC36D 1.01 1.13 0.97
TM8E080C20MP11 XAHC30C 1.01 1.14 0.97
TM8E080C20MP11 XAHC36D 1.01 1.12 0.97
TM8E100B12MP11 CF/CM/CU30B 1.00 1.01 0.96
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM8E100B12MP11 CF/CM/CU36B 1.01 1.01 0.97
TM8E100B12MP11 CF/CM/CU36C 1.01 1.01 0.97
TM8E100B12MP11 CF/CM/CU42C 1.01 1.03 0.97
TM8E100B12MP11 CF/CM30C 1.00 1.01 0.96
TM8E100B12MP11 CF42B 1.01 1.01 0.97
TM8E100B12MP11 XAF/XAUB30C 1.00 0.95 0.96
TM8E100B12MP11 XAF/XAUB36D 0.99 0.93 0.95
TM8E100B12MP11 XAFC30C 0.99 0.95 0.95
TM8E100B12MP11 XAFC36D 0.99 0.93 0.95
TM8E100B12MP11 XAHB30C 1.00 0.94 0.96
TM8E100B12MP11 XAHB36D 1.00 0.96 0.96
TM8E100B12MP11 XAHC30C 1.00 1.00 0.96
TM8E100B12MP11 XAHC36D 0.99 0.93 0.95
TM8E100C16MP11 CF/CM/CU36C 1.01 1.06 0.95
TM8E100C16MP11 CF/CM/CU42C 1.01 1.07 0.95
TM8E100C16MP11 CF/CM30C 1.01 1.07 0.97
TM8E100C16MP11 CF/CM36D 1.01 1.07 0.97
TM8E100C16MP11 CF/CM42D 1.01 1.07 0.95
TM8E100C16MP11 XAFC30C 1.01 1.00 0.97
TM8E100C16MP11 XAFC36D 1.01 0.98 0.95
TM8E100C16MP11 XAHC30C 1.01 1.00 0.97
TM8E100C16MP11 XAHC36D 1.01 0.98 0.97
TM8E100C20MP11 XAFC36D 1.01 1.14 0.97
TM8E100C20MP11 XAHC30C 1.01 1.14 0.97
TM8E100C20MP11 XAHC36D 1.01 1.12 0.97
TM8E120C16MP11 CF/CM/CU36C 1.01 1.07 0.95
TM8E120C16MP11 CF/CM/CU42C 1.01 1.07 0.95
TM8E120C16MP11 CF/CM30C 1.01 1.07 0.97
TM8E120C16MP11 CF/CM36D 1.01 1.00 0.95
TM8E120C16MP11 CF/CM42D 1.01 1.07 0.95
TM8E120C16MP11 XAFC30C 1.01 1.01 0.97
TM8E120C16MP11 XAFC36D 1.01 0.99 0.95
TM8E120C16MP11 XAHC30C 1.01 1.00 0.97
TM8E120C16MP11 XAHC36D 1.01 0.98 0.97
TM8V060A12MP11C CF/CM/CU30A 1.00 1.04 0.96
TM8V060A12MP11C CF/CM/CU30B 1.01 1.04 0.95
TM8V060A12MP11C CF/CM/CU36B 1.01 1.04 0.93
TM8V060A12MP11C CF/CM36A 1.01 1.04 0.95
TM8V060A12MP11C CF42B 1.01 1.04 0.93
TM8V060A12MP12C CF/CM/CU30A 1.00 1.04 0.96
TM8V060A12MP12C CF/CM/CU30B 1.01 1.04 0.95
TM8V060A12MP12C CF/CM/CU36B 1.01 1.04 0.93
TM8V060A12MP12C CF/CM36A 0.99 0.99 0.95
TM8V060A12MP12C CF42B 1.01 1.04 0.93
TM8V060A12MP12C XAF/XAUB30C 0.99 0.94 0.95
TM8V060A12MP12C XAF/XAUB36D 0.99 0.93 0.95
TM8V060A12MP12C XAFA30D 0.94 0.93 0.92
TM8V060A12MP12C XAHB30C 0.99 0.94 0.95
TM8V060A12MP12C XAHB36D 0.99 0.93 0.95
TM8V080B12MP11C CF/CM/CU30B 0.99 1.00 0.93
TM8V080B12MP11C CF/CM/CU36B 1.01 1.01 0.95
TM8V080B12MP11C CF/CM/CU36C 1.01 1.01 0.95
TM8V080B12MP11C CF/CM/CU42C 1.01 1.01 0.93
TM8V080B12MP11C CF/CM30C 1.00 1.01 0.94
TM8V080B12MP11C CF42B 1.01 1.01 0.95
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
