York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 155
TL9E080C16UH11 CF/CM/CU48D 1.02 1.11 0.98
TL9E080C16UH11 CF/CM36D 1.01 1.11 0.97
TL9E080C16UH11 CF/CM42D 1.02 1.11 0.98
TL9E080C16UH11 XAF/XAUC42E 1.01 0.97 0.97
TL9E080C16UH11 XAFC36D 1.01 0.97 0.97
TL9E080C16UH11 XAFD42E 1.01 0.97 0.97
TL9E080C16UH11 XAHC36D 1.00 0.95 0.96
TL9E080C16UH11 XAHC42E 1.00 0.95 0.96
TL9E080C16UH11 XAHD42E 1.01 0.97 0.97
TL9E100C20UH11 CF/CM/CU36C 1.01 1.13 0.97
TL9E100C20UH11 CF/CM/CU42C 1.02 1.13 0.98
TL9E100C20UH11 CF/CM/CU48C 1.03 1.15 0.97
TL9E100C20UH11 CF/CM/CU48D 1.03 1.16 0.99
TL9E100C20UH11 CF/CM36D 1.02 1.15 0.98
TL9E100C20UH11 CF/CM42D 1.03 1.15 0.99
TL9E100C20UH11 XAF/XAUC42E 1.01 0.98 0.97
TL9E100C20UH11 XAFC36D 1.01 0.98 0.97
TL9E100C20UH11 XAFD42E 1.02 0.98 0.98
TL9E100C20UH11 XAHC36D 1.01 0.96 0.97
TL9E100C20UH11 XAHC42E 1.01 0.97 0.97
TL9E100C20UH11 XAHD42E 1.01 0.98 0.97
TM8E040A12MP11 CF/CM/CU36B 1.00 1.07 0.98
TM8E040A12MP11 CF42B 1.00 1.06 0.98
TM8E040A12MP11 XAF/XAUB36D 0.99 0.94 0.97
TM8E040A12MP11 XAFB36E 1.00 0.94 0.98
TM8E040A12MP11 XAHB36D 1.00 1.01 1.00
TM8E060A12MP11 CF/CM/CU36B 1.00 1.07 0.98
TM8E060A12MP11 CF42B 1.00 1.06 0.98
TM8E060A12MP11 XAF/XAUB36D 0.99 0.94 0.97
TM8E060A12MP11 XAFB36E 1.00 0.94 0.98
TM8E060A12MP11 XAHB36D 1.00 1.02 1.00
TM8E080B12MP11 CF/CM/CU36B 1.00 1.07 0.98
TM8E080B12MP11 CF/CM/CU36C 1.00 1.07 0.98
TM8E080B12MP11 CF/CM/CU42C 1.01 1.08 0.99
TM8E080B12MP11 CF/CM/CU48C 1.01 1.09 0.97
TM8E080B12MP11 CF42B 1.01 1.07 0.97
TM8E080B12MP11 XAF/XAUB36D 0.99 0.94 0.97
TM8E080B12MP11 XAF/XAUC42E 1.00 0.95 0.98
TM8E080B12MP11 XAFB36E 1.00 0.94 0.98
TM8E080B12MP11 XAFC36D 0.99 0.94 0.97
TM8E080B12MP11 XAHB36D 1.00 1.01 1.00
TM8E080B12MP11 XAHC36D 0.99 0.94 0.97
TM8E080B12MP11 XAHC42E 1.00 0.94 0.98
TM8E080C16MP11 CF/CM/CU36C 1.01 1.11 0.97
TM8E080C16MP11 CF/CM/CU42C 1.02 1.11 0.98
TM8E080C16MP11 CF/CM/CU48C 1.02 1.12 0.98
TM8E080C16MP11 CF/CM/CU48D 1.02 1.12 0.98
TM8E080C16MP11 CF/CM36D 1.01 1.13 0.97
TM8E080C16MP11 CF/CM42D 1.02 1.13 0.98
TM8E080C16MP11 XAF/XAUC42E 1.01 0.97 0.97
TM8E080C16MP11 XAFC36D 1.01 0.96 0.97
TM8E080C16MP11 XAFD42E 1.01 0.97 0.97
TM8E080C16MP11 XAHC36D 1.01 0.96 0.97
TM8E080C16MP11 XAHC42E 1.01 0.96 0.97
TM8E080C16MP11 XAHD42E 1.01 0.97 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM8E080C20MP11 CF/CM/CU36C 1.02 1.18 0.98
TM8E080C20MP11 CF/CM/CU42C 1.03 1.18 0.99
TM8E080C20MP11 CF/CM/CU48C 1.03 1.20 0.99
TM8E080C20MP11 CF/CM/CU48D 1.03 1.20 0.99
TM8E080C20MP11 CF/CM36D 1.02 1.20 0.98
TM8E080C20MP11 CF/CM42D 1.03 1.19 0.99
TM8E080C20MP11 XAF/XAUC42E 1.03 1.03 0.99
TM8E080C20MP11 XAFC36D 1.02 1.03 0.98
TM8E080C20MP11 XAFD42E 1.03 1.04 0.99
TM8E080C20MP11 XAHC36D 1.02 1.02 0.98
TM8E080C20MP11 XAHC42E 1.02 1.02 0.98
TM8E080C20MP11 XAHD42E 1.03 1.03 0.99
TM8E100B12MP11 CF/CM/CU36B 1.01 1.11 0.99
TM8E100B12MP11 CF/CM/CU36C 1.01 1.11 0.99
TM8E100B12MP11 CF/CM/CU42C 1.01 1.11 0.99
TM8E100B12MP11 CF/CM/CU48C 1.02 1.11 0.98
TM8E100B12MP11 CF42B 1.01 1.07 0.99
TM8E100B12MP11 XAF/XAUB36D 1.01 0.97 0.98
TM8E100B12MP11 XAF/XAUC42E 1.01 0.98 0.99
TM8E100B12MP11 XAFB36E 1.01 0.97 0.98
TM8E100B12MP11 XAFC36D 1.01 0.97 0.98
TM8E100B12MP11 XAHB36D 1.00 0.96 0.98
TM8E100B12MP11 XAHC36D 1.01 0.97 0.98
TM8E100B12MP11 XAHC42E 1.01 0.97 0.98
TM8E100C16MP11 CF/CM/CU36C 1.01 1.13 0.97
TM8E100C16MP11 CF/CM/CU42C 1.02 1.13 0.98
TM8E100C16MP11 CF/CM/CU48C 1.02 1.14 0.98
TM8E100C16MP11 CF/CM/CU48D 1.03 1.15 0.99
TM8E100C16MP11 CF/CM36D 1.01 1.13 0.97
TM8E100C16MP11 CF/CM42D 1.02 1.13 0.98
TM8E100C16MP11 XAF/XAUC42E 1.01 0.98 0.97
TM8E100C16MP11 XAFC36D 1.01 0.98 0.97
TM8E100C16MP11 XAFD42E 1.01 0.98 0.97
TM8E100C16MP11 XAHC36D 1.01 0.97 0.97
TM8E100C16MP11 XAHC42E 1.01 0.97 0.97
TM8E100C16MP11 XAHD42E 1.01 0.97 0.97
TM8E100C20MP11 CF/CM/CU36C 1.02 1.18 0.98
TM8E100C20MP11 CF/CM/CU42C 1.03 1.18 0.99
TM8E100C20MP11 CF/CM/CU48C 1.03 1.20 0.99
TM8E100C20MP11 CF/CM/CU48D 1.03 1.20 0.99
TM8E100C20MP11 CF/CM36D 1.02 1.20 0.98
TM8E100C20MP11 CF/CM42D 1.03 1.19 0.99
TM8E100C20MP11 XAF/XAUC42E 1.03 1.03 0.99
TM8E100C20MP11 XAFC36D 1.02 1.03 0.98
TM8E100C20MP11 XAFD42E 1.03 1.04 0.99
TM8E100C20MP11 XAHC36D 1.02 1.02 0.98
TM8E100C20MP11 XAHC42E 1.02 1.02 0.98
TM8E100C20MP11 XAHD42E 1.03 1.03 0.99
TM8E120C16MP11 CF/CM/CU36C 1.01 1.13 0.97
TM8E120C16MP11 CF/CM/CU42C 1.02 1.13 0.98
TM8E120C16MP11 CF/CM/CU48C 1.03 1.15 0.99
TM8E120C16MP11 CF/CM/CU48D 1.03 1.15 0.99
TM8E120C16MP11 CF/CM36D 1.01 1.13 0.97
TM8E120C16MP11 CF/CM42D 1.02 1.13 0.98
TM8E120C16MP11 XAF/XAUC42E 1.01 0.98 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
