York LX series Technical Guide

5581700-YTG-F-1021
156 Johnson Controls Ducted Systems
TM8E120C16MP11 XAFC36D 1.01 0.98 0.97
TM8E120C16MP11 XAFD42E 1.01 0.98 0.97
TM8E120C16MP11 XAHC36D 1.01 0.97 0.97
TM8E120C16MP11 XAHC42E 1.01 0.97 0.97
TM8E120C16MP11 XAHD42E 1.01 0.98 0.97
TM8E120C20MP11 CF/CM/CU36C 1.02 1.20 0.98
TM8E120C20MP11 CF/CM/CU42C 1.03 1.19 0.99
TM8E120C20MP11 CF/CM/CU48C 1.03 1.21 0.99
TM8E120C20MP11 CF/CM/CU48D 1.03 1.21 0.99
TM8E120C20MP11 CF/CM36D 1.00 1.12 1.00
TM8E120C20MP11 CF/CM42D 1.03 1.20 0.99
TM8E120C20MP11 XAF/XAUC42E 1.03 1.05 0.99
TM8E120C20MP11 XAFC36D 1.02 1.04 0.98
TM8E120C20MP11 XAFD42E 1.03 1.05 0.99
TM8E120C20MP11 XAHC36D 1.02 1.04 0.98
TM8E120C20MP11 XAHC42E 1.03 1.04 0.99
TM8E120C20MP11 XAHD42E 1.03 1.04 0.99
TM8E130D20MP11 CF/CM/CU48D 1.03 1.21 0.99
TM8E130D20MP11 CF/CM36D 1.00 1.12 0.98
TM8E130D20MP11 CF/CM42D 1.03 1.20 0.99
TM8E130D20MP11 XAFD42E 1.03 1.05 0.99
TM8E130D20MP11 XAHD42E 1.03 1.04 0.99
TM8V060A12MP11C CF/CM/CU36B 0.99 1.04 0.97
TM8V060A12MP11C CF/CM36A 0.98 1.03 0.98
TM8V060A12MP11C CF42B 0.99 1.03 0.97
TM8V060A12MP12C CF/CM/CU36B 0.99 1.04 0.97
TM8V060A12MP12C CF/CM36A 0.98 1.03 0.98
TM8V060A12MP12C CF42B 0.99 1.03 0.97
TM8V060A12MP12C XAF/XAUB36D 0.99 0.96 0.97
TM8V060A12MP12C XAFB36E 0.99 0.97 0.97
TM8V060A12MP12C XAHB36D 0.99 0.97 0.99
TM8V080B12MP11C CF/CM/CU36B 0.99 1.05 0.99
TM8V080B12MP11C CF/CM/CU36C 0.99 1.05 0.97
TM8V080B12MP11C CF/CM/CU42C 1.00 1.06 0.98
TM8V080B12MP11C CF/CM/CU48C 1.00 1.06 0.98
TM8V080B12MP11C CF42B 0.99 1.05 0.99
TM8V080B12MP12C CF/CM/CU36B 0.99 1.05 0.99
TM8V080B12MP12C CF/CM/CU36C 0.99 1.05 0.97
TM8V080B12MP12C CF/CM/CU42C 1.00 1.06 0.98
TM8V080B12MP12C CF/CM/CU48C 1.00 1.06 0.98
TM8V080B12MP12C CF42B 0.99 1.05 0.99
TM8V080B12MP12C XAF/XAUB36D 0.99 0.94 0.99
TM8V080B12MP12C XAF/XAUC42E 0.99 0.94 0.99
TM8V080B12MP12C XAFB36E 0.99 0.94 0.99
TM8V080B12MP12C XAFC36D 0.99 0.94 0.99
TM8V080B12MP12C XAHB36D 0.99 0.94 0.99
TM8V080B12MP12C XAHC36D 0.99 0.94 0.99
TM8V080B12MP12C XAHC42E 0.99 0.94 0.99
TM8V080C16MP11C CF/CM/CU36C 1.01 1.09 0.97
TM8V080C16MP11C CF/CM/CU42C 1.01 1.08 0.95
TM8V080C16MP11C CF/CM/CU48C 1.01 1.09 0.95
TM8V080C16MP11C CF/CM/CU48D 1.01 1.09 0.95
TM8V080C16MP11C CF/CM36D 1.01 1.09 0.95
TM8V080C16MP11C CF/CM42D 1.02 1.09 0.96
TM8V080C16MP12C CF/CM/CU36C 1.01 1.09 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM8V080C16MP12C CF/CM/CU42C 1.01 1.08 0.95
TM8V080C16MP12C CF/CM/CU48C 1.01 1.09 0.95
TM8V080C16MP12C CF/CM/CU48D 1.01 1.09 0.95
TM8V080C16MP12C CF/CM36D 1.01 1.09 0.95
TM8V080C16MP12C CF/CM42D 1.02 1.09 0.96
TM8V080C16MP12C XAF/XAUC42E 1.01 0.97 0.97
TM8V080C16MP12C XAFC36D 1.01 0.97 0.97
TM8V080C16MP12C XAFD42E 1.01 0.97 0.97
TM8V080C16MP12C XAHC36D 1.01 0.97 0.97
TM8V080C16MP12C XAHC42E 1.01 0.97 0.97
TM8V080C16MP12C XAHD42E 1.01 0.97 0.97
TM8V100C16MP11C CF/CM/CU36C 1.01 1.09 0.97
TM8V100C16MP11C CF/CM/CU42C 1.01 1.08 0.95
TM8V100C16MP11C CF/CM/CU48C 1.01 1.09 0.95
TM8V100C16MP11C CF/CM/CU48D 1.01 1.09 0.95
TM8V100C16MP11C CF/CM36D 1.01 1.09 0.95
TM8V100C16MP11C CF/CM42D 1.02 1.09 0.96
TM8V100C16MP12C CF/CM/CU36C 1.01 1.09 0.97
TM8V100C16MP12C CF/CM/CU42C 1.01 1.08 0.95
TM8V100C16MP12C CF/CM/CU48C 1.01 1.09 0.95
TM8V100C16MP12C CF/CM/CU48D 1.01 1.09 0.95
TM8V100C16MP12C CF/CM36D 1.01 1.09 0.95
TM8V100C16MP12C CF/CM42D 1.02 1.09 0.96
TM8V100C16MP12C XAF/XAUC42E 1.01 0.97 0.97
TM8V100C16MP12C XAFC36D 1.01 0.97 0.97
TM8V100C16MP12C XAFD42E 1.01 0.97 0.97
TM8V100C16MP12C XAHC36D 1.01 0.97 0.97
TM8V100C16MP12C XAHC42E 1.01 0.97 0.97
TM8V100C16MP12C XAHD42E 1.01 0.97 0.97
TM8V100C20MP11C CF/CM/CU36C 1.02 1.15 0.96
TM8V100C20MP11C CF/CM/CU42C 1.03 1.15 0.97
TM8V100C20MP11C CF/CM/CU48C 1.03 1.16 0.97
TM8V100C20MP11C CF/CM/CU48D 1.03 1.16 0.95
TM8V100C20MP11C CF/CM36D 1.02 1.15 0.96
TM8V100C20MP11C CF/CM42D 1.03 1.15 0.95
TM8V100C20MP12C CF/CM/CU36C 1.02 1.15 0.96
TM8V100C20MP12C CF/CM/CU42C 1.03 1.15 0.97
TM8V100C20MP12C CF/CM/CU48C 1.03 1.16 0.97
TM8V100C20MP12C CF/CM/CU48D 1.03 1.16 0.95
TM8V100C20MP12C CF/CM36D 1.02 1.15 0.96
TM8V100C20MP12C CF/CM42D 1.03 1.15 0.95
TM8V100C20MP12C XAF/XAUC42E 1.02 1.01 0.98
TM8V100C20MP12C XAFC36D 1.02 1.01 0.98
TM8V100C20MP12C XAFD42E 1.02 1.01 0.96
TM8V100C20MP12C XAHC36D 1.02 1.00 0.98
TM8V100C20MP12C XAHC42E 1.02 1.00 0.98
TM8V100C20MP12C XAHD42E 1.02 1.00 0.98
TM8V120C20MP11C CF/CM/CU36C 1.02 1.15 0.96
TM8V120C20MP11C CF/CM/CU42C 1.03 1.15 0.97
TM8V120C20MP11C CF/CM/CU48C 1.03 1.16 0.97
TM8V120C20MP11C CF/CM/CU48D 1.03 1.16 0.95
TM8V120C20MP11C CF/CM36D 1.02 1.15 0.96
TM8V120C20MP11C CF/CM42D 1.03 1.15 0.95
TM8V120C20MP12C CF/CM/CU36C 1.02 1.15 0.96
TM8V120C20MP12C CF/CM/CU42C 1.03 1.15 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
