York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 157
TM8V120C20MP12C CF/CM/CU48C 1.03 1.16 0.97
TM8V120C20MP12C CF/CM/CU48D 1.03 1.16 0.95
TM8V120C20MP12C CF/CM36D 1.02 1.15 0.96
TM8V120C20MP12C CF/CM42D 1.03 1.15 0.95
TM8V120C20MP12C XAF/XAUC42E 1.02 1.01 0.98
TM8V120C20MP12C XAFC36D 1.02 1.01 0.98
TM8V120C20MP12C XAFD42E 1.02 1.01 0.96
TM8V120C20MP12C XAHC36D 1.02 1.00 0.98
TM8V120C20MP12C XAHC42E 1.02 1.00 0.98
TM8V120C20MP12C XAHD42E 1.02 1.00 0.98
TM8X060A12MP11 CF/CM/CU36B 1.00 1.11 1.00
TM8X060A12MP11 CF/CM36A 0.99 1.09 0.99
TM8X060A12MP11 CF42B 1.01 1.11 0.99
TM8X080B12MP11 CF/CM/CU36B 0.99 1.04 0.95
TM8X080B12MP11 CF/CM/CU36C 0.99 1.06 0.95
TM8X080B12MP11 CF/CM/CU42C 1.01 1.06 0.97
TM8X080B12MP11 CF/CM/CU48C 1.01 1.07 0.95
TM8X080B12MP11 CF42B 1.02 1.13 1.00
TM8X080C16MP11 CF/CM/CU36C 1.02 1.14 0.98
TM8X080C16MP11 CF/CM/CU42C 1.02 1.14 0.96
TM8X080C16MP11 CF/CM/CU48C 1.03 1.15 0.97
TM8X080C16MP11 CF/CM/CU48D 1.01 1.05 0.95
TM8X080C16MP11 CF/CM36D 0.99 1.05 0.94
TM8X080C16MP11 CF/CM42D 0.99 1.05 0.94
TM8X100C16MP11 CF/CM/CU36C 1.02 1.14 0.98
TM8X100C16MP11 CF/CM/CU42C 1.02 1.14 0.96
TM8X100C16MP11 CF/CM/CU48C 1.03 1.15 0.97
TM8X100C16MP11 CF/CM/CU48D 1.01 1.05 0.95
TM8X100C16MP11 CF/CM36D 0.99 1.05 0.94
TM8X100C16MP11 CF/CM42D 0.99 1.05 0.94
TM8X100C20MP11 CF/CM/CU36C 1.00 1.07 0.94
TM8X100C20MP11 CF/CM/CU42C 1.01 1.07 0.93
TM8X100C20MP11 CF/CM/CU48C 1.01 1.07 0.93
TM8X100C20MP11 CF/CM/CU48D 1.01 1.07 0.93
TM8X100C20MP11 CF/CM36D 1.00 1.07 0.94
TM8X100C20MP11 CF/CM42D 1.01 1.07 0.93
TM8X120C20MP11 CF/CM/CU36C 1.00 1.07 0.94
TM8X120C20MP11 CF/CM/CU42C 1.01 1.07 0.93
TM8X120C20MP11 CF/CM/CU48C 1.01 1.07 0.93
TM8X120C20MP11 CF/CM/CU48D 1.01 1.07 0.93
TM8X120C20MP11 CF/CM36D 1.00 1.07 0.94
TM8X120C20MP11 CF/CM42D 1.01 1.07 0.93
TM8Y060A12MP11 CF/CM/CU36B 1.00 1.11 1.00
TM8Y060A12MP11 CF/CM36A 0.99 1.09 0.99
TM8Y060A12MP11 CF42B 1.01 1.11 0.99
TM8Y060A12MP11 XAF/XAUB36D 1.00 0.98 1.00
TM8Y060A12MP11 XAFB36E 1.00 0.99 1.00
TM8Y060A12MP11 XAHB36D 0.99 0.98 0.99
TM8Y080B12MP11 CF/CM/CU36B 0.99 1.04 0.95
TM8Y080B12MP11 CF/CM/CU36C 0.99 1.06 0.95
TM8Y080B12MP11 CF/CM/CU42C 1.01 1.06 0.97
TM8Y080B12MP11 CF/CM/CU48C 1.01 1.07 0.95
TM8Y080B12MP11 CF42B 1.02 1.13 1.00
TM8Y080B12MP11 XAF/XAUB36D 1.01 1.01 1.01
TM8Y080B12MP11 XAF/XAUC42E 1.01 1.02 0.99
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM8Y080B12MP11 XAFB36E 1.01 1.01 1.01
TM8Y080B12MP11 XAFC36D 1.01 1.02 0.99
TM8Y080B12MP11 XAHB36D 1.01 0.99 1.01
TM8Y080B12MP11 XAHC36D 1.01 1.01 1.01
TM8Y080B12MP11 XAHC42E 1.01 1.01 1.01
TM8Y080C16MP11 CF/CM/CU36C 1.02 1.14 0.98
TM8Y080C16MP11 CF/CM/CU42C 1.02 1.14 0.96
TM8Y080C16MP11 CF/CM/CU48C 1.03 1.15 0.97
TM8Y080C16MP11 CF/CM/CU48D 1.01 1.05 0.95
TM8Y080C16MP11 CF/CM36D 0.99 1.05 0.94
TM8Y080C16MP11 CF/CM42D 0.99 1.05 0.94
TM8Y080C16MP11 XAF/XAUC42E 1.02 1.00 0.98
TM8Y080C16MP11 XAFC36D 1.01 1.00 0.97
TM8Y080C16MP11 XAFD42E 1.02 1.01 0.98
TM8Y080C16MP11 XAHC36D 1.01 1.00 0.97
TM8Y080C16MP11 XAHC42E 1.02 0.99 0.98
TM8Y080C16MP11 XAHD42E 1.01 1.00 0.97
TM8Y100C16MP11 CF/CM/CU36C 1.02 1.14 0.98
TM8Y100C16MP11 CF/CM/CU42C 1.02 1.14 0.96
TM8Y100C16MP11 CF/CM/CU48C 1.03 1.15 0.97
TM8Y100C16MP11 CF/CM/CU48D 1.01 1.05 0.95
TM8Y100C16MP11 CF/CM36D 0.99 1.05 0.94
TM8Y100C16MP11 CF/CM42D 0.99 1.05 0.94
TM8Y100C16MP11 XAF/XAUC42E 1.02 1.00 0.98
TM8Y100C16MP11 XAFC36D 1.01 1.00 0.97
TM8Y100C16MP11 XAFD42E 1.02 1.01 0.98
TM8Y100C16MP11 XAHC36D 1.01 1.00 0.97
TM8Y100C16MP11 XAHC42E 1.02 0.99 0.98
TM8Y100C16MP11 XAHD42E 1.01 1.00 0.97
TM8Y100C20MP11 CF/CM/CU36C 1.00 1.07 0.94
TM8Y100C20MP11 CF/CM/CU42C 1.01 1.07 0.93
TM8Y100C20MP11 CF/CM/CU48C 1.01 1.07 0.93
TM8Y100C20MP11 CF/CM/CU48D 1.01 1.07 0.93
TM8Y100C20MP11 CF/CM36D 1.00 1.07 0.94
TM8Y100C20MP11 CF/CM42D 1.01 1.07 0.93
TM8Y100C20MP11 XAF/XAUC42E 1.03 1.02 0.99
TM8Y100C20MP11 XAFC36D 1.02 1.02 0.98
TM8Y100C20MP11 XAFD42E 1.02 1.02 0.98
TM8Y100C20MP11 XAHC36D 1.02 1.01 0.98
TM8Y100C20MP11 XAHC42E 1.02 1.01 0.98
TM8Y100C20MP11 XAHD42E 1.02 1.02 0.98
TM8Y120C20MP11 CF/CM/CU36C 1.00 1.07 0.94
TM8Y120C20MP11 CF/CM/CU42C 1.01 1.07 0.93
TM8Y120C20MP11 CF/CM/CU48C 1.01 1.07 0.93
TM8Y120C20MP11 CF/CM/CU48D 1.01 1.07 0.93
TM8Y120C20MP11 CF/CM36D 1.00 1.07 0.94
TM8Y120C20MP11 CF/CM42D 1.01 1.07 0.93
TM8Y120C20MP11 XAF/XAUC42E 1.03 1.02 0.99
TM8Y120C20MP11 XAFC36D 1.02 1.02 0.98
TM8Y120C20MP11 XAFD42E 1.02 1.02 0.98
TM8Y120C20MP11 XAHC36D 1.02 1.01 0.98
TM8Y120C20MP11 XAHC42E 1.02 1.01 0.98
TM8Y120C20MP11 XAHD42E 1.02 1.02 0.98
TM9E060A10MP12 CF/CM/CU36B 0.99 1.06 1.02
TM9E060A10MP12 CF42B 1.00 1.07 1.02
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
