York LX series Technical Guide

5581700-YTG-F-1021
158 Johnson Controls Ducted Systems
TM9E060A10MP12 XAF/XAUB36D 0.99 0.95 0.99
TM9E060A10MP12 XAFB36E 0.99 0.94 0.99
TM9E060A10MP12 XAHB36D 0.99 0.94 0.99
TM9E060B12MP11 CF/CM/CU36B 0.99 1.10 0.99
TM9E060B12MP11 CF/CM/CU36C 0.99 1.04 0.97
TM9E060B12MP11 CF/CM/CU42C 0.99 1.03 0.97
TM9E060B12MP11 CF/CM/CU48C 1.00 1.05 0.96
TM9E060B12MP11 CF42B 1.01 1.10 1.01
TM9E060B12MP12 CF/CM/CU36B 0.99 1.09 0.99
TM9E060B12MP12 CF/CM/CU36C 1.00 1.11 1.02
TM9E060B12MP12 CF/CM/CU42C 1.01 1.10 1.01
TM9E060B12MP12 CF/CM/CU48C 1.01 1.11 1.01
TM9E060B12MP12 CF42B 1.00 1.07 1.00
TM9E060B12MP12 XAF/XAUB36D 0.99 0.97 0.99
TM9E060B12MP12 XAF/XAUC42E 1.01 0.98 1.01
TM9E060B12MP12 XAFB36E 1.00 0.97 1.00
TM9E060B12MP12 XAFC36D 1.00 0.97 1.00
TM9E060B12MP12 XAHB36D 0.99 0.96 0.99
TM9E060B12MP12 XAHC36D 1.00 0.97 1.00
TM9E060B12MP12 XAHC42E 1.00 0.97 1.00
TM9E080B12MP11 CF/CM/CU36B 0.99 1.04 0.97
TM9E080B12MP11 CF/CM/CU36C 1.01 1.14 0.99
TM9E080B12MP11 CF/CM/CU42C 1.00 1.06 0.96
TM9E080B12MP11 CF/CM/CU48C 1.01 1.07 0.97
TM9E080B12MP11 CF42B 0.99 1.03 0.97
TM9E080B12MP12 CF/CM/CU36B 1.00 1.07 0.98
TM9E080B12MP12 CF/CM/CU36C 1.01 1.11 0.99
TM9E080B12MP12 CF/CM/CU42C 1.01 1.10 0.99
TM9E080B12MP12 CF/CM/CU48C 1.02 1.11 1.00
TM9E080B12MP12 CF42B 1.00 1.07 0.98
TM9E080B12MP12 XAF/XAUB36D 1.00 0.95 0.98
TM9E080B12MP12 XAF/XAUC42E 1.01 0.97 0.98
TM9E080B12MP12 XAFB36E 1.00 0.96 0.98
TM9E080B12MP12 XAFC36D 1.00 0.95 0.98
TM9E080B12MP12 XAHB36D 0.99 0.94 0.97
TM9E080B12MP12 XAHC36D 1.00 0.95 0.98
TM9E080B12MP12 XAHC42E 1.00 0.96 0.98
TM9E080C16MP11 CF/CM/CU36C 0.99 1.05 0.95
TM9E080C16MP11 CF/CM/CU42C 0.99 1.05 0.95
TM9E080C16MP11 CF/CM/CU48C 1.01 1.05 0.95
TM9E080C16MP11 CF/CM/CU48D 1.01 1.05 0.95
TM9E080C16MP11 CF/CM36D 0.99 1.05 0.95
TM9E080C16MP11 CF/CM42D 0.99 1.05 0.95
TM9E080C16MP12 CF/CM/CU36C 1.01 1.11 0.97
TM9E080C16MP12 CF/CM/CU42C 1.02 1.11 0.98
TM9E080C16MP12 CF/CM/CU48C 1.02 1.11 0.98
TM9E080C16MP12 CF/CM/CU48D 1.02 1.11 0.98
TM9E080C16MP12 CF/CM36D 1.01 1.11 0.99
TM9E080C16MP12 CF/CM42D 1.02 1.11 0.98
TM9E080C16MP12 XAF/XAUC42E 1.01 0.97 0.97
TM9E080C16MP12 XAFC36D 1.01 0.97 0.97
TM9E080C16MP12 XAFD42E 1.01 0.97 0.97
TM9E080C16MP12 XAHC36D 1.00 0.95 0.96
TM9E080C16MP12 XAHC42E 1.00 0.95 0.96
TM9E080C16MP12 XAHD42E 1.01 0.97 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM9E080C20MP12 CF/CM/CU36C 1.02 1.18 0.98
TM9E080C20MP12 CF/CM/CU42C 1.03 1.17 0.99
TM9E080C20MP12 CF/CM/CU48C 1.03 1.17 0.99
TM9E080C20MP12 CF/CM/CU48D 1.03 1.20 0.99
TM9E080C20MP12 CF/CM36D 1.03 1.19 0.99
TM9E080C20MP12 CF/CM42D 1.03 1.18 0.99
TM9E080C20MP12 XAF/XAUC42E 1.03 1.02 0.99
TM9E080C20MP12 XAFC36D 1.02 1.02 0.98
TM9E080C20MP12 XAFD42E 1.03 1.03 0.99
TM9E080C20MP12 XAHC36D 1.02 1.01 0.98
TM9E080C20MP12 XAHC42E 1.02 1.01 0.98
TM9E080C20MP12 XAHD42E 1.03 1.02 0.99
TM9E100C16MP11 CF/CM/CU36C 0.99 1.05 0.95
TM9E100C16MP11 CF/CM/CU42C 0.99 1.05 0.95
TM9E100C16MP11 CF/CM/CU48C 1.01 1.07 0.95
TM9E100C16MP11 CF/CM/CU48D 1.01 1.07 0.95
TM9E100C16MP11 CF/CM36D 1.00 1.06 0.94
TM9E100C16MP11 CF/CM42D 1.01 1.07 0.95
TM9E100C16MP12 CF/CM/CU36C 1.01 1.11 0.97
TM9E100C16MP12 CF/CM/CU42C 1.02 1.11 0.98
TM9E100C16MP12 CF/CM/CU48C 1.02 1.11 0.98
TM9E100C16MP12 CF/CM/CU48D 1.02 1.11 0.98
TM9E100C16MP12 CF/CM36D 1.01 1.11 0.97
TM9E100C16MP12 CF/CM42D 1.02 1.11 0.98
TM9E100C16MP12 XAF/XAUC42E 1.01 0.96 0.97
TM9E100C16MP12 XAFC36D 1.01 0.96 0.97
TM9E100C16MP12 XAFD42E 1.01 0.97 0.97
TM9E100C16MP12 XAHC36D 1.01 0.96 0.97
TM9E100C16MP12 XAHC42E 1.01 0.96 0.97
TM9E100C16MP12 XAHD42E 1.01 0.96 0.97
TM9E100C20MP11 CF/CM/CU36C 1.02 1.15 0.98
TM9E100C20MP11 CF/CM/CU42C 1.02 1.16 0.98
TM9E100C20MP11 CF/CM/CU48C 1.03 1.16 0.97
TM9E100C20MP11 CF/CM/CU48D 1.03 1.18 0.97
TM9E100C20MP11 CF/CM36D 1.02 1.16 0.98
TM9E100C20MP11 CF/CM42D 1.03 1.17 0.97
TM9E100C20MP12 CF/CM/CU36C 1.03 1.17 0.99
TM9E100C20MP12 CF/CM/CU42C 1.03 1.17 0.99
TM9E100C20MP12 CF/CM/CU48C 1.03 1.17 0.99
TM9E100C20MP12 CF/CM/CU48D 1.03 1.17 0.99
TM9E100C20MP12 CF/CM36D 1.03 1.19 0.99
TM9E100C20MP12 CF/CM42D 1.03 1.17 0.99
TM9E100C20MP12 XAF/XAUC42E 1.03 1.02 0.99
TM9E100C20MP12 XAFC36D 1.02 1.01 0.98
TM9E100C20MP12 XAFD42E 1.03 1.02 0.99
TM9E100C20MP12 XAHC36D 1.02 1.01 0.98
TM9E100C20MP12 XAHC42E 1.02 1.01 0.98
TM9E100C20MP12 XAHD42E 1.02 1.01 0.98
TM9E120D20MP11 CF/CM/CU48D 1.03 1.20 0.97
TM9E120D20MP11 CF/CM36D 1.03 1.19 0.97
TM9E120D20MP11 CF/CM42D 1.03 1.18 0.97
TM9E120D20MP12 CF/CM/CU48D 1.03 1.20 0.99
TM9E120D20MP12 CF/CM36D 1.02 1.18 0.98
TM9E120D20MP12 CF/CM42D 1.03 1.18 0.99
TM9E120D20MP12 XAFD42E 1.03 1.03 0.99
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
