York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 159
TM9E120D20MP12 XAHD42E 1.02 1.02 0.98
TM9V060B12MP12C CF/CM/CU36B 0.99 1.05 0.99
TM9V060B12MP12C CF/CM/CU36C 0.99 1.05 0.97
TM9V060B12MP12C CF/CM/CU42C 1.00 1.06 0.98
TM9V060B12MP12C CF/CM/CU48C 1.00 1.06 0.98
TM9V060B12MP12C CF42B 0.99 1.05 0.97
TM9V060B12MP12C XAF/XAUB36D 0.99 0.94 0.99
TM9V060B12MP12C XAF/XAUC42E 0.99 0.94 0.99
TM9V060B12MP12C XAFB36E 0.99 0.95 0.99
TM9V060B12MP12C XAFC36D 0.99 0.94 0.99
TM9V060B12MP12C XAHB36D 0.99 0.95 0.99
TM9V060B12MP12C XAHC36D 0.99 0.95 0.99
TM9V060B12MP12C XAHC42E 0.99 0.95 0.99
TM9V080B12MP11C CF/CM/CU36B 0.99 1.04 0.97
TM9V080B12MP11C CF/CM/CU36C 1.00 1.07 0.98
TM9V080B12MP11C CF/CM/CU42C 1.01 1.08 0.97
TM9V080B12MP11C CF/CM/CU48C 1.01 1.09 0.97
TM9V080B12MP11C CF42B 0.99 1.03 0.97
TM9V080B12MP12C CF/CM/CU36B 0.99 1.04 0.97
TM9V080B12MP12C CF/CM/CU36C 1.00 1.07 0.98
TM9V080B12MP12C CF/CM/CU42C 1.01 1.08 0.97
TM9V080B12MP12C CF/CM/CU48C 1.01 1.09 0.97
TM9V080B12MP12C CF42B 0.99 1.03 0.97
TM9V080B12MP12C XAF/XAUB36D 1.00 0.98 0.98
TM9V080B12MP12C XAF/XAUC42E 1.01 0.98 0.98
TM9V080B12MP12C XAFB36E 1.00 0.98 0.98
TM9V080B12MP12C XAFC36D 1.00 0.98 0.98
TM9V080B12MP12C XAHB36D 0.99 0.98 0.99
TM9V080B12MP12C XAHC36D 1.00 0.98 0.98
TM9V080B12MP12C XAHC42E 1.01 0.98 0.96
TM9V080C16MP11C CF/CM/CU36C 1.00 1.07 0.96
TM9V080C16MP11C CF/CM/CU42C 1.01 1.07 0.97
TM9V080C16MP11C CF/CM/CU48C 1.01 1.07 0.97
TM9V080C16MP11C CF/CM/CU48D 1.01 1.07 0.97
TM9V080C16MP11C CF/CM36D 1.00 1.07 0.96
TM9V080C16MP11C CF/CM42D 1.01 1.07 0.97
TM9V080C16MP12C CF/CM/CU36C 1.00 1.07 0.96
TM9V080C16MP12C CF/CM/CU42C 1.01 1.07 0.97
TM9V080C16MP12C CF/CM/CU48C 1.01 1.07 0.97
TM9V080C16MP12C CF/CM/CU48D 1.01 1.07 0.97
TM9V080C16MP12C CF/CM36D 1.00 1.07 0.96
TM9V080C16MP12C CF/CM42D 1.01 1.07 0.97
TM9V080C16MP12C XAF/XAUC42E 1.00 0.95 0.96
TM9V080C16MP12C XAFC36D 1.00 0.95 0.98
TM9V080C16MP12C XAFD42E 1.00 0.95 0.96
TM9V080C16MP12C XAHC36D 1.00 0.95 0.98
TM9V080C16MP12C XAHC42E 1.00 0.95 0.98
TM9V080C16MP12C XAHD42E 1.00 0.95 0.98
TM9V100C16MP11C CF/CM/CU36C 1.00 1.06 0.94
TM9V100C16MP11C CF/CM/CU42C 1.01 1.07 0.95
TM9V100C16MP11C CF/CM/CU48C 1.02 1.11 0.96
TM9V100C16MP11C CF/CM/CU48D 1.01 1.05 0.95
TM9V100C16MP11C CF/CM36D 1.01 1.11 0.95
TM9V100C16MP11C CF/CM42D 1.02 1.11 0.96
TM9V100C16MP12C CF/CM/CU36C 1.00 1.06 0.94
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM9V100C16MP12C CF/CM/CU42C 1.01 1.07 0.95
TM9V100C16MP12C CF/CM/CU48C 1.02 1.11 0.96
TM9V100C16MP12C CF/CM/CU48D 1.01 1.05 0.95
TM9V100C16MP12C CF/CM36D 1.01 1.11 0.95
TM9V100C16MP12C CF/CM42D 1.02 1.11 0.96
TM9V100C16MP12C XAF/XAUC42E 1.00 0.94 0.96
TM9V100C16MP12C XAFC36D 1.00 0.94 0.96
TM9V100C16MP12C XAFD42E 1.02 0.99 0.98
TM9V100C16MP12C XAHC36D 1.00 0.94 0.96
TM9V100C16MP12C XAHC42E 1.00 0.94 0.96
TM9V100C16MP12C XAHD42E 1.00 0.94 0.96
TM9V100C20MP11C CF/CM/CU36C 1.01 1.11 0.97
TM9V100C20MP11C CF/CM/CU42C 1.02 1.11 0.98
TM9V100C20MP11C CF/CM/CU48C 1.02 1.11 0.96
TM9V100C20MP11C CF/CM/CU48D 1.02 1.12 0.96
TM9V100C20MP11C CF/CM36D 1.01 1.11 0.97
TM9V100C20MP11C CF/CM42D 1.02 1.11 0.96
TM9V100C20MP12C CF/CM/CU36C 1.01 1.11 0.97
TM9V100C20MP12C CF/CM/CU42C 1.02 1.11 0.98
TM9V100C20MP12C CF/CM/CU48C 1.02 1.11 0.96
TM9V100C20MP12C CF/CM/CU48D 1.02 1.12 0.96
TM9V100C20MP12C CF/CM36D 1.01 1.11 0.97
TM9V100C20MP12C CF/CM42D 1.02 1.11 0.96
TM9V100C20MP12C XAF/XAUC42E 1.01 0.98 0.97
TM9V100C20MP12C XAFC36D 1.01 0.98 0.97
TM9V100C20MP12C XAFD42E 1.02 0.99 0.98
TM9V100C20MP12C XAHC36D 1.01 0.99 0.97
TM9V100C20MP12C XAHC42E 1.02 1.00 0.98
TM9V100C20MP12C XAHD42E 1.01 0.98 0.97
TM9V120D20MP11C CF/CM/CU48D 1.02 1.10 0.94
TM9V120D20MP11C CF/CM36D 1.01 1.09 0.95
TM9V120D20MP11C CF/CM42D 1.02 1.08 0.94
TM9V120D20MP12C CF/CM/CU48D 1.02 1.10 0.94
TM9V120D20MP12C CF/CM36D 1.01 1.09 0.95
TM9V120D20MP12C CF/CM42D 1.02 1.08 0.94
TM9V120D20MP12C XAFD42E 1.01 0.97 0.95
TM9V120D20MP12C XAHD42E 1.01 0.97 0.97
TM9Y060B12MP11 CF/CM/CU36B 0.99 1.10 0.99
TM9Y060B12MP11 CF/CM/CU36C 0.99 1.04 0.97
TM9Y060B12MP11 CF/CM/CU42C 0.99 1.03 0.97
TM9Y060B12MP11 CF/CM/CU48C 1.00 1.05 0.96
TM9Y060B12MP11 CF42B 1.01 1.10 1.01
TM9Y060B12MP11 XAF/XAUB36D 0.99 0.98 0.99
TM9Y060B12MP11 XAF/XAUC42E 1.00 0.99 1.00
TM9Y060B12MP11 XAFB36E 1.01 0.99 1.01
TM9Y060B12MP11 XAFC36D 0.99 0.98 0.99
TM9Y060B12MP11 XAHB36D 0.99 0.97 0.99
TM9Y060B12MP11 XAHC36D 0.99 0.98 0.99
TM9Y060B12MP11 XAHC42E 1.00 0.99 1.00
TM9Y080B12MP11 CF/CM/CU36B 0.99 1.04 0.97
TM9Y080B12MP11 CF/CM/CU36C 1.01 1.14 0.99
TM9Y080B12MP11 CF/CM/CU42C 1.00 1.06 0.96
TM9Y080B12MP11 CF/CM/CU48C 1.01 1.07 0.97
TM9Y080B12MP11 CF42B 0.99 1.03 0.97
TM9Y080B12MP11 XAF/XAUB36D 1.00 0.99 1.00
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
