York LX series Technical Guide

5581700-YTG-F-1021
16 Johnson Controls Ducted Systems
YCE18B22S TM9V040A10MP12C 14.5 CF/CM/CU18B 525 17.4 13.2 15.25 13.00
YCE18B22S TM9V040A10MP12C 14.5 CF/CM/CU24A 525 17.5 13.3 15.25 13.00
YCE18B22S TM9V040A10MP12C 14.5 CF/CM/CU24B 625 17.9 14.6 15.50 13.00
YCE18B22S TM9V040A10MP12C 14.5 CF/CM/CU30A 525 17.6 13.3 15.50 13.00
YCE18B22S TM9V040A10MP12C 14.5 CF/CM/CU30B 625 18.0 14.6 15.75 13.25
YCE18B22S TM9V040A10MP12C 14.5 CF/CM/CU36B 625 18.0 14.8 15.75 13.25
YCE18B22S TM9V040A10MP12C 14.5 CF/CM36A 625 18.0 14.8 15.50 13.00
YCE18B22S TM9V040A10MP12C 14.5 XAF/XAUA24B 525 17.5 12.3 15.25 12.75
YCE18B22S TM9V040A10MP12C 17.5 XAFB24B 525 17.6 12.4 15.50 12.75
YCE18B22S TM9V040A10MP12C 14.5 XAHA24B 525 17.5 12.3 15.25 12.75
YCE18B22S TM9V040A10MP12C 17.5 XAHB24B 525 17.6 12.4 15.50 12.75
YCE18B22S TM9V060B12MP12C 17.5 CF/CM/CU18B 600 17.7 14.3 15.75 13.00
YCE18B22S TM9V060B12MP12C 17.5 CF/CM/CU24B 600 17.9 14.3 15.75 13.25
YCE18B22S TM9V060B12MP12C 17.5 CF/CM/CU30B 600 18.0 14.3 16.00 13.25
YCE18B22S TM9V060B12MP12C 17.5 CF/CM/CU36B 600 18.0 14.1 16.00 13.25
YCE18B22S TM9V060B12MP12C 17.5 CF/CM/CU36C 600 18.0 14.2 16.00 13.25
YCE18B22S TM9V060B12MP12C 17.5 CF/CM24C 600 17.9 14.3 16.00 13.25
YCE18B22S TM9V060B12MP12C 17.5 CF/CM30C 600 18.0 14.3 16.00 13.25
YCE18B22S TM9V060B12MP12C 17.5 XAFB24B 600 17.9 13.1 15.75 13.00
YCE18B22S TM9V060B12MP12C 17.5 XAHB24B 600 17.9 13.1 15.75 13.00
YCE18B22S TM9V080B12MP11C 17.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TM9V080B12MP11C 17.5 CF/CM/CU24B 675 18.0 15.2 16.00 13.25
YCE18B22S TM9V080B12MP11C 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TM9V080B12MP11C 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TM9V080B12MP11C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TM9V080B12MP11C 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
YCE18B22S TM9V080B12MP11C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TM9V080B12MP12C 17.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TM9V080B12MP12C 17.5 CF/CM/CU24B 675 18.0 15.2 16.00 13.25
YCE18B22S TM9V080B12MP12C 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TM9V080B12MP12C 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TM9V080B12MP12C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TM9V080B12MP12C 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
YCE18B22S TM9V080B12MP12C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TM9V080B12MP12C 17.5 XAFB24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM9V080B12MP12C 17.5 XAHB24B 625 18.0 13.4 16.00 13.00
YCE18B22S TM9Y040A10MP11 14.5 CF/CM/CU18A 675 17.8 14.9 14.50 12.50
YCE18B22S TM9Y040A10MP11 14.5 CF/CM/CU18B 525 17.4 13.2 15.25 13.00
YCE18B22S TM9Y040A10MP11 14.5 CF/CM/CU24A 675 17.9 15.1 14.75 12.50
YCE18B22S TM9Y040A10MP11 14.5 CF/CM/CU24B 525 17.5 13.3 15.25 13.00
YCE18B22S TM9Y040A10MP11 14.5 CF/CM/CU30A 675 18.0 14.9 15.00 12.75
YCE18B22S TM9Y040A10MP11 14.5 CF/CM/CU30B 525 17.6 13.3 15.50 13.00
YCE18B22S TM9Y040A10MP11 14.5 CF/CM/CU36B 525 17.7 13.4 15.50 13.00
YCE18B22S TM9Y040A10MP11 14.5 CF/CM36A 675 18.0 14.9 15.25 12.75
YCE18B22S TM9Y040A10MP11 14.5 XAF/XAUA24B 500 17.5 12.1 15.25 12.75
YCE18B22S TM9Y040A10MP11 17.5 XAFB24B 500 17.4 12.1 15.25 12.75
YCE18B22S TM9Y040A10MP11 14.5 XAHA24B 500 17.5 12.1 15.25 12.75
YCE18B22S TM9Y040A10MP11 17.5 XAHB24B 500 17.4 12.1 15.25 12.75
YCE18B22S TM9Y060B12MP11 17.5 CF/CM/CU18B 675 18.0 15.1 15.50 13.25
YCE18B22S TM9Y060B12MP11 17.5 CF/CM/CU24B 675 18.0 15.2 15.75 13.25
YCE18B22S TM9Y060B12MP11 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TM9Y060B12MP11 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TM9Y060B12MP11 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
