York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 17
YCE18B22S TM9Y060B12MP11 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TM9Y060B12MP11 17.5 XAFB24B 675 17.9 13.9 16.00 13.00
YCE18B22S TM9Y060B12MP11 17.5 XAHB24B 650 18.0 13.7 15.75 13.00
YCE18B22S TM9Y080B12MP11 17.5 XAFB24B 700 18.0 14.2 16.00 13.00
YCE18B22S TM9Y080B12MP11 17.5 XAHB24B 700 18.0 14.2 16.00 13.00
YCE18B22S TM9Y080C16MP11 21.0 CF/CM/CU36C 600 18.0 14.2 16.00 13.25
YCE18B22S TM9Y080C16MP11 21.0 CF/CM24C 600 18.0 14.4 16.00 13.25
YCE18B22S TM9Y080C16MP11 21.0 CF/CM30C 600 18.0 14.3 16.00 13.25
YCE18B22S TM9Y080C16MP11 21.0 CF/CM36D 600 18.0 14.2 16.00 13.25
YCE18B22S TM9Y100C16MP11 21.0 CF/CM/CU36C 650 18.0 14.6 16.00 13.25
YCE18B22S TM9Y100C16MP11 21.0 CF/CM24C 625 18.0 14.6 16.00 13.25
YCE18B22S TM9Y100C16MP11 21.0 CF/CM30C 625 18.0 14.6 16.00 13.25
YCE18B22S TM9Y100C16MP11 21.0 CF/CM36D 650 18.0 14.6 16.00 13.25
YCE18B22S TMLE040A12MP11 14.5 XAF/XAUA24B 625 17.7 13.4 16.00 13.00
YCE18B22S TMLE040A12MP11 17.5 XAFB24B 675 17.7 13.9 16.00 13.00
YCE18B22S TMLE040A12MP11 14.5 XAHA24B 625 17.7 13.4 16.00 13.00
YCE18B22S TMLE040A12MP11 17.5 XAHB24B 650 17.7 13.7 16.00 13.00
YCE18B22S TMLE060A12MP11 14.5 XAF/XAUA24B 725 18.0 14.4 16.00 13.00
YCE18B22S TMLE060A12MP11 14.5 XAHA24B 725 18.0 14.4 16.00 13.00
YCE18B22S TMLE080B12MP11 17.5 CF/CM24B 725 18.0 13.7 16.00 13.00
YCE18B22S TMLE080B12MP11 17.5 XAFB24B 725 18.0 14.4 16.00 13.00
YCE18B22S TMLE080B12MP11 17.5 XAHB24B 700 18.0 14.2 16.00 13.00
YCE18B22S TMLE100B12MP11 17.5 CF/CM24B 725 18.0 13.7 16.00 13.00
YCE18B22S TMLE100B12MP11 17.5 XAFB24B 700 18.0 14.1 16.00 13.00
YCE18B22S TMLE100B12MP11 17.5 XAHB24B 700 18.0 14.1 16.00 13.00
YCE18B22S TMLV060A12MP11C 14.5 CF/CM/CU18A 625 17.9 14.5 15.75 13.25
YCE18B22S TMLV060A12MP11C 14.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TMLV060A12MP11C 14.5 CF/CM/CU24A 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV060A12MP11C 14.5 CF/CM/CU24B 625 18.0 14.6 16.00 13.25
YCE18B22S TMLV060A12MP11C 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TMLV060A12MP11C 14.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TMLV060A12MP11C 14.5 CF/CM/CU36B 625 18.0 14.8 16.00 13.25
YCE18B22S TMLV060A12MP11C 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM/CU18A 625 17.9 14.5 15.75 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM/CU24A 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM/CU24B 625 18.0 14.6 16.00 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM/CU36B 625 18.0 14.8 16.00 13.25
YCE18B22S TMLV060A12MP12C 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV060A12MP12C 14.5 XAF/XAUA24B 625 18.0 13.4 16.00 13.00
YCE18B22S TMLV060A12MP12C 17.5 XAFB24B 700 18.0 14.2 16.00 13.00
YCE18B22S TMLV060A12MP12C 14.5 XAHA24B 625 18.0 13.4 16.00 13.00
YCE18B22S TMLV060A12MP12C 17.5 XAHB24B 625 18.0 13.4 16.00 13.00
YCE18B22S TMLV080B12MP11C 17.5 CF/CM/CU18B 625 17.8 14.4 15.50 13.25
YCE18B22S TMLV080B12MP11C 17.5 CF/CM/CU24B 625 18.0 14.7 15.75 13.25
YCE18B22S TMLV080B12MP11C 17.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TMLV080B12MP11C 17.5 CF/CM/CU36B 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV080B12MP11C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TMLV080B12MP11C 17.5 CF/CM24C 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV080B12MP11C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TMLV080B12MP12C 17.5 CF/CM/CU18B 625 17.8 14.4 15.50 13.25
YCE18B22S TMLV080B12MP12C 17.5 CF/CM/CU24B 625 18.0 14.7 15.75 13.25
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
