York LX series Technical Guide

5581700-YTG-F-1021
18 Johnson Controls Ducted Systems
YCE18B22S TMLV080B12MP12C 17.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TMLV080B12MP12C 17.5 CF/CM/CU36B 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV080B12MP12C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TMLV080B12MP12C 17.5 CF/CM24C 625 18.0 14.7 16.00 13.25
YCE18B22S TMLV080B12MP12C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM/CU18A 625 17.9 14.5 15.50 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM/CU18B 650 17.9 14.8 15.75 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM/CU24A 625 18.0 14.7 15.75 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM/CU24B 650 18.0 14.9 16.00 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM/CU30B 650 18.0 14.8 16.00 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM/CU36B 650 18.0 14.6 16.00 13.25
YCE18B22S TMLX060A12MP11 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TMLX080B12MP11 17.5 CF/CM/CU18B 675 18.0 15.1 16.00 13.25
YCE18B22S TMLX080B12MP11 17.5 CF/CM/CU24B 675 18.0 15.2 16.00 13.25
YCE18B22S TMLX080B12MP11 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TMLX080B12MP11 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TMLX080B12MP11 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
YCE18B22S TMLX080B12MP11 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TP9C060B12MP13C 17.5 CF/CM/CU18B 600 17.7 14.3 15.75 13.00
YCE18B22S TP9C060B12MP13C 17.5 CF/CM/CU24B 600 17.9 14.3 15.75 13.25
YCE18B22S TP9C060B12MP13C 17.5 CF/CM/CU30B 600 18.0 14.3 16.00 13.25
YCE18B22S TP9C060B12MP13C 17.5 CF/CM/CU36B 600 18.0 14.1 16.00 13.25
YCE18B22S TP9C060B12MP13C 17.5 CF/CM/CU36C 600 18.0 14.2 16.00 13.25
YCE18B22S TP9C060B12MP13C 17.5 CF/CM24C 600 17.9 14.3 16.00 13.25
YCE18B22S TP9C060B12MP13C 17.5 CF/CM30C 600 18.0 14.3 16.00 13.25
YCE18B22S TP9C060B12MP13C 17.5 XAFB24B 600 17.9 13.1 15.75 13.00
YCE18B22S TP9C060B12MP13C 17.5 XAHB24B 600 17.9 13.1 15.75 13.00
YCE18B22S TP9C080B12MP12C 17.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TP9C080B12MP12C 17.5 CF/CM/CU24B 675 18.0 15.2 16.00 13.25
YCE18B22S TP9C080B12MP12C 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TP9C080B12MP12C 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TP9C080B12MP12C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TP9C080B12MP12C 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
YCE18B22S TP9C080B12MP12C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TP9C080B12MP13C 17.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TP9C080B12MP13C 17.5 CF/CM/CU24B 675 18.0 15.2 16.00 13.25
YCE18B22S TP9C080B12MP13C 17.5 CF/CM/CU30B 675 18.0 14.9 16.00 13.25
YCE18B22S TP9C080B12MP13C 17.5 CF/CM/CU36B 675 18.0 15.0 16.00 13.25
YCE18B22S TP9C080B12MP13C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S TP9C080B12MP13C 17.5 CF/CM24C 675 18.0 15.2 16.00 13.25
YCE18B22S TP9C080B12MP13C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S TP9C080B12MP13C 17.5 XAFB24B 625 18.0 13.4 16.00 13.00
YCE18B22S TP9C080B12MP13C 17.5 XAHB24B 625 18.0 13.4 16.00 13.00
YCE18B22S TPLC060A12MP12C 14.5 CF/CM/CU18A 625 17.9 14.5 15.75 13.25
YCE18B22S TPLC060A12MP12C 14.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S TPLC060A12MP12C 14.5 CF/CM/CU24A 625 18.0 14.7 16.00 13.25
YCE18B22S TPLC060A12MP12C 14.5 CF/CM/CU24B 625 18.0 14.6 16.00 13.25
YCE18B22S TPLC060A12MP12C 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S TPLC060A12MP12C 14.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S TPLC060A12MP12C 14.5 CF/CM/CU36B 625 18.0 14.8 16.00 13.25
YCE18B22S TPLC060A12MP12C 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S TPLC060A12MP13C 14.5 CF/CM/CU18A 625 17.9 14.5 15.75 13.25
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
