York LX series Technical Guide

5581700-YTG-F-1021
162 Johnson Controls Ducted Systems
TP9C060B12MP13C CF42B 0.99 1.05 0.97
TP9C060B12MP13C XAF/XAUB36D 0.99 0.94 0.99
TP9C060B12MP13C XAF/XAUC42E 0.99 0.94 0.99
TP9C060B12MP13C XAFB36E 0.99 0.95 0.99
TP9C060B12MP13C XAFC36D 0.99 0.94 0.99
TP9C060B12MP13C XAHB36D 0.99 0.95 0.99
TP9C060B12MP13C XAHC36D 0.99 0.95 0.99
TP9C060B12MP13C XAHC42E 0.99 0.95 0.99
TP9C080B12MP12C CF/CM/CU36B 0.99 1.04 0.97
TP9C080B12MP12C CF/CM/CU36C 1.00 1.07 0.98
TP9C080B12MP12C CF/CM/CU42C 1.01 1.08 0.97
TP9C080B12MP12C CF/CM/CU48C 1.01 1.09 0.97
TP9C080B12MP12C CF42B 0.99 1.03 0.97
TP9C080B12MP13C CF/CM/CU36B 0.99 1.04 0.97
TP9C080B12MP13C CF/CM/CU36C 1.00 1.07 0.98
TP9C080B12MP13C CF/CM/CU42C 1.01 1.08 0.97
TP9C080B12MP13C CF/CM/CU48C 1.01 1.09 0.97
TP9C080B12MP13C CF42B 0.99 1.03 0.97
TP9C080B12MP13C XAF/XAUB36D 1.00 0.98 0.98
TP9C080B12MP13C XAF/XAUC42E 1.01 0.98 0.98
TP9C080B12MP13C XAFB36E 1.00 0.98 0.98
TP9C080B12MP13C XAFC36D 1.00 0.98 0.98
TP9C080B12MP13C XAHB36D 0.99 0.98 0.99
TP9C080B12MP13C XAHC36D 1.00 0.98 0.98
TP9C080B12MP13C XAHC42E 1.01 0.98 0.96
TP9C080C16MP13C CF/CM/CU36C 1.00 1.07 0.96
TP9C080C16MP13C CF/CM/CU42C 1.01 1.07 0.97
TP9C080C16MP13C CF/CM/CU48C 1.01 1.07 0.97
TP9C080C16MP13C CF/CM/CU48D 1.01 1.07 0.97
TP9C080C16MP13C CF/CM36D 1.00 1.07 0.96
TP9C080C16MP13C CF/CM42D 1.01 1.07 0.97
TP9C080C16MP13C XAF/XAUC42E 1.00 0.95 0.96
TP9C080C16MP13C XAFC36D 1.00 0.95 0.98
TP9C080C16MP13C XAFD42E 1.00 0.95 0.96
TP9C080C16MP13C XAHC36D 1.00 0.95 0.98
TP9C080C16MP13C XAHC42E 1.00 0.95 0.98
TP9C080C16MP13C XAHD42E 1.00 0.95 0.98
TP9C100C16MP12C CF/CM/CU36C 1.00 1.06 0.94
TP9C100C16MP12C CF/CM/CU42C 1.01 1.07 0.95
TP9C100C16MP12C CF/CM/CU48C 1.02 1.11 0.96
TP9C100C16MP12C CF/CM/CU48D 1.01 1.05 0.95
TP9C100C16MP12C CF/CM36D 1.01 1.11 0.95
TP9C100C16MP12C CF/CM42D 1.02 1.11 0.96
TP9C100C16MP13C CF/CM/CU36C 1.00 1.06 0.94
TP9C100C16MP13C CF/CM/CU42C 1.01 1.07 0.95
TP9C100C16MP13C CF/CM/CU48C 1.02 1.11 0.96
TP9C100C16MP13C CF/CM/CU48D 1.01 1.05 0.95
TP9C100C16MP13C CF/CM36D 1.01 1.11 0.95
TP9C100C16MP13C CF/CM42D 1.02 1.11 0.96
TP9C100C16MP13C XAF/XAUC42E 1.00 0.94 0.96
TP9C100C16MP13C XAFC36D 1.00 0.94 0.96
TP9C100C16MP13C XAFD42E 1.02 0.99 0.98
TP9C100C16MP13C XAHC36D 1.00 0.94 0.96
TP9C100C16MP13C XAHC42E 1.00 0.94 0.96
TP9C100C16MP13C XAHD42E 1.00 0.94 0.96
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
TP9C100C20MP12C CF/CM/CU36C 1.01 1.11 0.97
TP9C100C20MP12C CF/CM/CU42C 1.02 1.11 0.98
TP9C100C20MP12C CF/CM/CU48C 1.02 1.11 0.96
TP9C100C20MP12C CF/CM/CU48D 1.02 1.12 0.96
TP9C100C20MP12C CF/CM36D 1.01 1.11 0.97
TP9C100C20MP12C CF/CM42D 1.02 1.11 0.96
TP9C100C20MP13C CF/CM/CU36C 1.01 1.11 0.97
TP9C100C20MP13C CF/CM/CU42C 1.02 1.11 0.98
TP9C100C20MP13C CF/CM/CU48C 1.02 1.11 0.96
TP9C100C20MP13C CF/CM/CU48D 1.02 1.12 0.96
TP9C100C20MP13C CF/CM36D 1.01 1.11 0.97
TP9C100C20MP13C CF/CM42D 1.02 1.11 0.96
TP9C100C20MP13C XAF/XAUC42E 1.01 0.98 0.97
TP9C100C20MP13C XAFC36D 1.01 0.98 0.97
TP9C100C20MP13C XAFD42E 1.02 0.99 0.98
TP9C100C20MP13C XAHC36D 1.01 0.99 0.97
TP9C100C20MP13C XAHC42E 1.02 1.00 0.98
TP9C100C20MP13C XAHD42E 1.01 0.98 0.97
TP9C120D20MP12C CF/CM/CU48D 1.02 1.10 0.94
TP9C120D20MP12C CF/CM36D 1.01 1.09 0.95
TP9C120D20MP12C CF/CM42D 1.02 1.08 0.94
TP9C120D20MP13C CF/CM/CU48D 1.02 1.10 0.94
TP9C120D20MP13C CF/CM36D 1.01 1.09 0.95
TP9C120D20MP13C CF/CM42D 1.02 1.08 0.94
TP9C120D20MP13C XAFD42E 1.01 0.97 0.95
TP9C120D20MP13C XAHD42E 1.01 0.97 0.97
TPLC060A12MP12C CF/CM/CU36B 0.99 1.04 0.97
TPLC060A12MP12C CF/CM36A 0.98 1.03 0.98
TPLC060A12MP12C CF42B 0.99 1.03 0.97
TPLC060A12MP13C CF/CM/CU36B 0.99 1.04 0.97
TPLC060A12MP13C CF/CM36A 0.98 1.03 0.98
TPLC060A12MP13C CF42B 0.99 1.03 0.97
TPLC060A12MP13C XAF/XAUB36D 0.99 0.96 0.97
TPLC060A12MP13C XAFB36E 0.99 0.97 0.97
TPLC060A12MP13C XAHB36D 0.99 0.97 0.99
TPLC080B12MP12C CF/CM/CU36B 0.99 1.05 0.99
TPLC080B12MP12C CF/CM/CU36C 0.99 1.05 0.97
TPLC080B12MP12C CF/CM/CU42C 1.00 1.06 0.98
TPLC080B12MP12C CF/CM/CU48C 1.00 1.06 0.98
TPLC080B12MP12C CF42B 0.99 1.05 0.99
TPLC080B12MP13C CF/CM/CU36B 0.99 1.05 0.99
TPLC080B12MP13C CF/CM/CU36C 0.99 1.05 0.97
TPLC080B12MP13C CF/CM/CU42C 1.00 1.06 0.98
TPLC080B12MP13C CF/CM/CU48C 1.00 1.06 0.98
TPLC080B12MP13C CF42B 0.99 1.05 0.99
TPLC080B12MP13C XAF/XAUB36D 0.99 0.94 0.99
TPLC080B12MP13C XAF/XAUC42E 0.99 0.94 0.99
TPLC080B12MP13C XAFB36E 0.99 0.94 0.99
TPLC080B12MP13C XAFC36D 0.99 0.94 0.99
TPLC080B12MP13C XAHB36D 0.99 0.94 0.99
TPLC080B12MP13C XAHC36D 0.99 0.94 0.99
TPLC080B12MP13C XAHC42E 0.99 0.94 0.99
TPLC080C16MP12C CF/CM/CU36C 1.01 1.09 0.97
TPLC080C16MP12C CF/CM/CU42C 1.01 1.08 0.95
TPLC080C16MP12C CF/CM/CU48C 1.01 1.09 0.95
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
