York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 163
TPLC080C16MP12C CF/CM/CU48D 1.01 1.09 0.95
TPLC080C16MP12C CF/CM36D 1.01 1.09 0.95
TPLC080C16MP12C CF/CM42D 1.02 1.09 0.96
TPLC080C16MP13C CF/CM/CU36C 1.01 1.09 0.97
TPLC080C16MP13C CF/CM/CU42C 1.01 1.08 0.95
TPLC080C16MP13C CF/CM/CU48C 1.01 1.09 0.95
TPLC080C16MP13C CF/CM/CU48D 1.01 1.09 0.95
TPLC080C16MP13C CF/CM36D 1.01 1.09 0.95
TPLC080C16MP13C CF/CM42D 1.02 1.09 0.96
TPLC080C16MP13C XAF/XAUC42E 1.01 0.97 0.97
TPLC080C16MP13C XAFC36D 1.01 0.97 0.97
TPLC080C16MP13C XAFD42E 1.01 0.97 0.97
TPLC080C16MP13C XAHC36D 1.01 0.97 0.97
TPLC080C16MP13C XAHC42E 1.01 0.97 0.97
TPLC080C16MP13C XAHD42E 1.01 0.97 0.97
TPLC100C16MP12C CF/CM/CU36C 1.01 1.09 0.97
TPLC100C16MP12C CF/CM/CU42C 1.01 1.08 0.95
TPLC100C16MP12C CF/CM/CU48C 1.01 1.09 0.95
TPLC100C16MP12C CF/CM/CU48D 1.01 1.09 0.95
TPLC100C16MP12C CF/CM36D 1.01 1.09 0.95
TPLC100C16MP12C CF/CM42D 1.02 1.09 0.96
TPLC100C16MP13C CF/CM/CU36C 1.01 1.09 0.97
TPLC100C16MP13C CF/CM/CU42C 1.01 1.08 0.95
TPLC100C16MP13C CF/CM/CU48C 1.01 1.09 0.95
TPLC100C16MP13C CF/CM/CU48D 1.01 1.09 0.95
TPLC100C16MP13C CF/CM36D 1.01 1.09 0.95
TPLC100C16MP13C CF/CM42D 1.02 1.09 0.96
TPLC100C16MP13C XAF/XAUC42E 1.01 0.97 0.97
TPLC100C16MP13C XAFC36D 1.01 0.97 0.97
TPLC100C16MP13C XAFD42E 1.01 0.97 0.97
TPLC100C16MP13C XAHC36D 1.01 0.97 0.97
TPLC100C16MP13C XAHC42E 1.01 0.97 0.97
TPLC100C16MP13C XAHD42E 1.01 0.97 0.97
TPLC100C20MP12C CF/CM/CU36C 1.02 1.15 0.96
TPLC100C20MP12C CF/CM/CU42C 1.03 1.15 0.97
TPLC100C20MP12C CF/CM/CU48C 1.03 1.16 0.97
TPLC100C20MP12C CF/CM/CU48D 1.03 1.16 0.95
TPLC100C20MP12C CF/CM36D 1.02 1.15 0.96
TPLC100C20MP12C CF/CM42D 1.03 1.15 0.95
TPLC100C20MP13C CF/CM/CU36C 1.02 1.15 0.96
TPLC100C20MP13C CF/CM/CU42C 1.03 1.15 0.97
TPLC100C20MP13C CF/CM/CU48C 1.03 1.16 0.97
TPLC100C20MP13C CF/CM/CU48D 1.03 1.16 0.95
TPLC100C20MP13C CF/CM36D 1.02 1.15 0.96
TPLC100C20MP13C CF/CM42D 1.03 1.15 0.95
TPLC100C20MP13C XAF/XAUC42E 1.02 1.01 0.98
TPLC100C20MP13C XAFC36D 1.02 1.01 0.98
TPLC100C20MP13C XAFD42E 1.02 1.01 0.96
TPLC100C20MP13C XAHC36D 1.02 1.00 0.98
TPLC100C20MP13C XAHC42E 1.02 1.00 0.98
TPLC100C20MP13C XAHD42E 1.02 1.00 0.98
TPLC120C20MP12C CF/CM/CU36C 1.02 1.15 0.96
TPLC120C20MP12C CF/CM/CU42C 1.03 1.15 0.97
TPLC120C20MP12C CF/CM/CU48C 1.03 1.16 0.97
TPLC120C20MP12C CF/CM/CU48D 1.03 1.16 0.95
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
TPLC120C20MP12C CF/CM36D 1.02 1.15 0.96
TPLC120C20MP12C CF/CM42D 1.03 1.15 0.95
TPLC120C20MP13C CF/CM/CU36C 1.02 1.15 0.96
TPLC120C20MP13C CF/CM/CU42C 1.03 1.15 0.97
TPLC120C20MP13C CF/CM/CU48C 1.03 1.16 0.97
TPLC120C20MP13C CF/CM/CU48D 1.03 1.16 0.95
TPLC120C20MP13C CF/CM36D 1.02 1.15 0.96
TPLC120C20MP13C CF/CM42D 1.03 1.15 0.95
TPLC120C20MP13C XAF/XAUC42E 1.02 1.01 0.98
TPLC120C20MP13C XAFC36D 1.02 1.01 0.98
TPLC120C20MP13C XAFD42E 1.02 1.01 0.96
TPLC120C20MP13C XAHC36D 1.02 1.00 0.98
TPLC120C20MP13C XAHC42E 1.02 1.00 0.98
TPLC120C20MP13C XAHD42E 1.02 1.00 0.98
YP9C060B12MP13C CF/CM/CU36B 0.99 1.05 0.99
YP9C060B12MP13C CF/CM/CU36C 0.99 1.05 0.97
YP9C060B12MP13C CF/CM/CU42C 1.00 1.06 0.98
YP9C060B12MP13C CF/CM/CU48C 1.00 1.06 0.98
YP9C060B12MP13C CF42B 0.99 1.05 0.97
YP9C060B12MP13C XAF/XAUB36D 0.99 0.94 0.99
YP9C060B12MP13C XAF/XAUC42E 0.99 0.94 0.99
YP9C060B12MP13C XAFB36E 0.99 0.95 0.99
YP9C060B12MP13C XAFC36D 0.99 0.94 0.99
YP9C060B12MP13C XAHB36D 0.99 0.95 0.99
YP9C060B12MP13C XAHC36D 0.99 0.95 0.99
YP9C060B12MP13C XAHC42E 0.99 0.95 0.99
YP9C080B12MP12C CF/CM/CU36B 0.99 1.04 0.97
YP9C080B12MP12C CF/CM/CU36C 1.00 1.07 0.98
YP9C080B12MP12C CF/CM/CU42C 1.01 1.08 0.97
YP9C080B12MP12C CF/CM/CU48C 1.01 1.09 0.97
YP9C080B12MP12C CF42B 0.99 1.03 0.97
YP9C080B12MP13C CF/CM/CU36B 0.99 1.04 0.97
YP9C080B12MP13C CF/CM/CU36C 1.00 1.07 0.98
YP9C080B12MP13C CF/CM/CU42C 1.01 1.08 0.97
YP9C080B12MP13C CF/CM/CU48C 1.01 1.09 0.97
YP9C080B12MP13C CF42B 0.99 1.03 0.97
YP9C080B12MP13C XAF/XAUB36D 1.00 0.98 0.98
YP9C080B12MP13C XAF/XAUC42E 1.01 0.98 0.98
YP9C080B12MP13C XAFB36E 1.00 0.98 0.98
YP9C080B12MP13C XAFC36D 1.00 0.98 0.98
YP9C080B12MP13C XAHB36D 0.99 0.98 0.99
YP9C080B12MP13C XAHC36D 1.00 0.98 0.98
YP9C080B12MP13C XAHC42E 1.01 0.98 0.96
YP9C080C16MP13C CF/CM/CU36C 1.00 1.07 0.96
YP9C080C16MP13C CF/CM/CU42C 1.01 1.07 0.97
YP9C080C16MP13C CF/CM/CU48C 1.01 1.07 0.97
YP9C080C16MP13C CF/CM/CU48D 1.01 1.07 0.97
YP9C080C16MP13C CF/CM36D 1.00 1.07 0.96
YP9C080C16MP13C CF/CM42D 1.01 1.07 0.97
YP9C080C16MP13C XAF/XAUC42E 1.00 0.95 0.96
YP9C080C16MP13C XAFC36D 1.00 0.95 0.98
YP9C080C16MP13C XAFD42E 1.00 0.95 0.96
YP9C080C16MP13C XAHC36D 1.00 0.95 0.98
YP9C080C16MP13C XAHC42E 1.00 0.95 0.98
YP9C080C16MP13C XAHD42E 1.00 0.95 0.98
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
