York LX series Technical Guide

5581700-YTG-F-1021
164 Johnson Controls Ducted Systems
YP9C100C16MP12C CF/CM/CU36C 1.00 1.06 0.94
YP9C100C16MP12C CF/CM/CU42C 1.01 1.07 0.95
YP9C100C16MP12C CF/CM/CU48C 1.02 1.11 0.96
YP9C100C16MP12C CF/CM/CU48D 1.01 1.05 0.95
YP9C100C16MP12C CF/CM36D 1.01 1.11 0.95
YP9C100C16MP12C CF/CM42D 1.02 1.11 0.96
YP9C100C16MP13C CF/CM/CU36C 1.00 1.06 0.94
YP9C100C16MP13C CF/CM/CU42C 1.01 1.07 0.95
YP9C100C16MP13C CF/CM/CU48C 1.02 1.11 0.96
YP9C100C16MP13C CF/CM/CU48D 1.01 1.05 0.95
YP9C100C16MP13C CF/CM36D 1.01 1.11 0.95
YP9C100C16MP13C CF/CM42D 1.02 1.11 0.96
YP9C100C16MP13C XAF/XAUC42E 1.00 0.94 0.96
YP9C100C16MP13C XAFC36D 1.00 0.94 0.96
YP9C100C16MP13C XAFD42E 1.02 0.99 0.98
YP9C100C16MP13C XAHC36D 1.00 0.94 0.96
YP9C100C16MP13C XAHC42E 1.00 0.94 0.96
YP9C100C16MP13C XAHD42E 1.00 0.94 0.96
YP9C100C20MP12C CF/CM/CU36C 1.01 1.11 0.97
YP9C100C20MP12C CF/CM/CU42C 1.02 1.11 0.98
YP9C100C20MP12C CF/CM/CU48C 1.02 1.11 0.96
YP9C100C20MP12C CF/CM/CU48D 1.02 1.12 0.96
YP9C100C20MP12C CF/CM36D 1.01 1.11 0.97
YP9C100C20MP12C CF/CM42D 1.02 1.11 0.96
YP9C100C20MP13C CF/CM/CU36C 1.01 1.11 0.97
YP9C100C20MP13C CF/CM/CU42C 1.02 1.11 0.98
YP9C100C20MP13C CF/CM/CU48C 1.02 1.11 0.96
YP9C100C20MP13C CF/CM/CU48D 1.02 1.12 0.96
YP9C100C20MP13C CF/CM36D 1.01 1.11 0.97
YP9C100C20MP13C CF/CM42D 1.02 1.11 0.96
YP9C100C20MP13C XAF/XAUC42E 1.01 0.98 0.97
YP9C100C20MP13C XAFC36D 1.01 0.98 0.97
YP9C100C20MP13C XAFD42E 1.02 0.99 0.98
YP9C100C20MP13C XAHC36D 1.01 0.99 0.97
YP9C100C20MP13C XAHC42E 1.02 1.00 0.98
YP9C100C20MP13C XAHD42E 1.01 0.98 0.97
YP9C120D20MP12C CF/CM/CU48D 1.02 1.10 0.94
YP9C120D20MP12C CF/CM36D 1.01 1.09 0.95
YP9C120D20MP12C CF/CM42D 1.02 1.08 0.94
YP9C120D20MP13C CF/CM/CU48D 1.02 1.10 0.94
YP9C120D20MP13C CF/CM36D 1.01 1.09 0.95
YP9C120D20MP13C CF/CM42D 1.02 1.08 0.94
YP9C120D20MP13C XAFD42E 1.01 0.97 0.95
YP9C120D20MP13C XAHD42E 1.01 0.97 0.97
YPLC060A12MP12C CF/CM/CU36B 0.99 1.04 0.97
YPLC060A12MP12C CF/CM36A 0.98 1.03 0.98
YPLC060A12MP12C CF42B 0.99 1.03 0.97
YPLC060A12MP13C CF/CM/CU36B 0.99 1.04 0.97
YPLC060A12MP13C CF/CM36A 0.98 1.03 0.98
YPLC060A12MP13C CF42B 0.99 1.03 0.97
YPLC060A12MP13C XAF/XAUB36D 0.99 0.96 0.97
YPLC060A12MP13C XAFB36E 0.99 0.97 0.97
YPLC060A12MP13C XAHB36D 0.99 0.97 0.99
YPLC080B12MP12C CF/CM/CU36B 0.99 1.05 0.99
YPLC080B12MP12C CF/CM/CU36C 0.99 1.05 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW
YPLC080B12MP12C CF/CM/CU42C 1.00 1.06 0.98
YPLC080B12MP12C CF/CM/CU48C 1.00 1.06 0.98
YPLC080B12MP12C CF42B 0.99 1.05 0.99
YPLC080B12MP13C CF/CM/CU36B 0.99 1.05 0.99
YPLC080B12MP13C CF/CM/CU36C 0.99 1.05 0.97
YPLC080B12MP13C CF/CM/CU42C 1.00 1.06 0.98
YPLC080B12MP13C CF/CM/CU48C 1.00 1.06 0.98
YPLC080B12MP13C CF42B 0.99 1.05 0.99
YPLC080B12MP13C XAF/XAUB36D 0.99 0.94 0.99
YPLC080B12MP13C XAF/XAUC42E 0.99 0.94 0.99
YPLC080B12MP13C XAFB36E 0.99 0.94 0.99
YPLC080B12MP13C XAFC36D 0.99 0.94 0.99
YPLC080B12MP13C XAHB36D 0.99 0.94 0.99
YPLC080B12MP13C XAHC36D 0.99 0.94 0.99
YPLC080B12MP13C XAHC42E 0.99 0.94 0.99
YPLC080C16MP12C CF/CM/CU36C 1.01 1.09 0.97
YPLC080C16MP12C CF/CM/CU42C 1.01 1.08 0.95
YPLC080C16MP12C CF/CM/CU48C 1.01 1.09 0.95
YPLC080C16MP12C CF/CM/CU48D 1.01 1.09 0.95
YPLC080C16MP12C CF/CM36D 1.01 1.09 0.95
YPLC080C16MP12C CF/CM42D 1.02 1.09 0.96
YPLC080C16MP13C CF/CM/CU36C 1.01 1.09 0.97
YPLC080C16MP13C CF/CM/CU42C 1.01 1.08 0.95
YPLC080C16MP13C CF/CM/CU48C 1.01 1.09 0.95
YPLC080C16MP13C CF/CM/CU48D 1.01 1.09 0.95
YPLC080C16MP13C CF/CM36D 1.01 1.09 0.95
YPLC080C16MP13C CF/CM42D 1.02 1.09 0.96
YPLC080C16MP13C XAF/XAUC42E 1.01 0.97 0.97
YPLC080C16MP13C XAFC36D 1.01 0.97 0.97
YPLC080C16MP13C XAFD42E 1.01 0.97 0.97
YPLC080C16MP13C XAHC36D 1.01 0.97 0.97
YPLC080C16MP13C XAHC42E 1.01 0.97 0.97
YPLC080C16MP13C XAHD42E 1.01 0.97 0.97
YPLC100C16MP12C CF/CM/CU36C 1.01 1.09 0.97
YPLC100C16MP12C CF/CM/CU42C 1.01 1.08 0.95
YPLC100C16MP12C CF/CM/CU48C 1.01 1.09 0.95
YPLC100C16MP12C CF/CM/CU48D 1.01 1.09 0.95
YPLC100C16MP12C CF/CM36D 1.01 1.09 0.95
YPLC100C16MP12C CF/CM42D 1.02 1.09 0.96
YPLC100C16MP13C CF/CM/CU36C 1.01 1.09 0.97
YPLC100C16MP13C CF/CM/CU42C 1.01 1.08 0.95
YPLC100C16MP13C CF/CM/CU48C 1.01 1.09 0.95
YPLC100C16MP13C CF/CM/CU48D 1.01 1.09 0.95
YPLC100C16MP13C CF/CM36D 1.01 1.09 0.95
YPLC100C16MP13C CF/CM42D 1.02 1.09 0.96
YPLC100C16MP13C XAF/XAUC42E 1.01 0.97 0.97
YPLC100C16MP13C XAFC36D 1.01 0.97 0.97
YPLC100C16MP13C XAFD42E 1.01 0.97 0.97
YPLC100C16MP13C XAHC36D 1.01 0.97 0.97
YPLC100C16MP13C XAHC42E 1.01 0.97 0.97
YPLC100C16MP13C XAHD42E 1.01 0.97 0.97
YPLC100C20MP12C CF/CM/CU36C 1.02 1.15 0.96
YPLC100C20MP12C CF/CM/CU42C 1.03 1.15 0.97
YPLC100C20MP12C CF/CM/CU48C 1.03 1.16 0.97
YPLC100C20MP12C CF/CM/CU48D 1.03 1.16 0.95
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
