Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COIL MULTIPLIERS - 4 TON
Air Handler Coil T.C. S.C. kW
— CF/CM/CU48C 1.00 1.00 1.00
— CF/CM/CU48D 1.00 1.00 1.00
— CF/CM60C 1.01 1.01 0.98
— CF/CM60D 1.01 1.01 0.98
— CF/CM64D 1.01 1.05 0.97
— XAF/XAUC48F 0.99 0.96 0.99
— XAF/XAUC60G 1.01 1.01 1.01
— XAF/XAUD60G 1.01 1.01 1.01
— XAFD48F 0.99 0.99 0.99
— XAHC48F 0.99 0.96 0.99
— XAHC60G 1.01 1.01 1.01
— XAHD48F 0.99 0.99 0.99
— XAHD60G 1.01 1.01 1.01
AE48CX21 — 0.99 0.98 0.91
AE48DX21 — 0.99 0.99 0.91
AE60CX21 — 1.00 1.01 0.92
AE60DX21 — 1.01 1.01 0.91
AP48CX21 — 1.01 0.98 1.01
AP48DX21 — 1.00 0.99 1.00
AP60CX21 — 1.01 1.07 0.99
AP60DX22 — 1.01 1.03 0.99
AP60DX23 — 1.01 1.03 0.99
AVC48CX21 — 1.01 0.99 0.95
AVC48DX21 — 1.01 1.01 0.93
AVC60CX21 — 1.01 1.01 0.93
AVC60DX21 — 1.01 1.02 0.93
ME14DN21 CF/CM60D 1.01 1.01 0.93
ME14DN21 CF/CM64D 1.01 0.99 0.91
ME16CN21 CF/CM48C 1.01 1.04 0.93
ME16CN21 CF/CM60C 1.01 1.02 0.93
ME20DN21 CF/CM48D 1.01 1.04 0.93
ME20DN21 CF/CM60D 1.01 1.01 0.93
ME20DN21 CF/CM64D 1.01 1.02 0.91
MVC14DN21 CF/CM48D 1.01 0.98 0.93
MVC14DN21 CF/CM60D 1.01 0.98 0.93
MVC14DN21 CF/CM64D 1.01 0.98 0.91
MVC16CN21 CF/CM48C 1.01 1.01 0.93
MVC16CN21 CF/CM60C 1.01 1.08 0.91
MVC20DN21 CF/CM48D 1.01 1.02 0.93
MVC20DN21 CF/CM60D 1.01 1.04 0.93
MVC20DN21 CF/CM64D 1.01 0.99 0.91
FURNACE MULTIPLIERS - 4 TON
Furnaces Coil
T.C. S.C. kW
TL8E080C16UH11 CF/CM/CU48C 1.01 1.02 0.95
TL8E080C16UH11 CF/CM/CU48D 1.01 1.02 0.97
TL8E080C16UH11 CF/CM/CU60C 1.01 1.02 0.97
TL8E080C16UH11 CF/CM64D 1.01 1.02 0.95
TL8E080C16UH11 XAF/XAUC48F 0.99 0.96 0.97
TL8E080C16UH11 XAF/XAUC60G 1.01 1.00 1.01
TL8E080C16UH11 XAF/XAUD60G 1.00 1.00 1.00
TL8E080C16UH11 XAFD48F 0.99 0.98 0.97
TL8E080C16UH11 XAHC48F 0.99 0.96 0.97
TL8E080C16UH11 XAHC60G 1.01 0.95 0.94
TL8E080C16UH11 XAHD48F 0.98 0.96 0.97
TL8E080C16UH11 XAHD60G 1.01 0.99 1.01
TL8E100C20UH11 CF/CM/CU48C 1.01 1.02 0.95
TL8E100C20UH11 CF/CM/CU48D 1.01 1.03 0.95
TL8E100C20UH11 CF/CM/CU60C 1.01 1.02 0.95
TL8E100C20UH11 CF/CM64D 1.01 1.03 0.93
TL8E100C20UH11 XAF/XAUC48F 1.00 0.98 0.98
TL8E100C20UH11 XAF/XAUC60G 1.01 0.96 0.92
TL8E100C20UH11 XAF/XAUD60G 1.00 0.96 0.92
TL8E100C20UH11 XAFD48F 0.99 0.98 0.97
TL8E100C20UH11 XAHC48F 1.00 0.98 1.00
TL8E100C20UH11 XAHC60G 1.01 0.96 0.92
TL8E100C20UH11 XAHD48F 0.99 0.98 0.97
TL8E100C20UH11 XAHD60G 1.01 1.00 0.96
TL9E080C16UH11 CF/CM/CU48C 1.01 1.02 0.97
TL9E080C16UH11 CF/CM/CU48D 1.01 1.02 0.97
TL9E080C16UH11 CF/CM/CU60C 1.01 1.02 0.97
TL9E080C16UH11 CF/CM64D 1.01 1.03 0.95
TL9E080C16UH11 XAF/XAUC60G 1.01 0.96 0.99
TL9E080C16UH11 XAF/XAUD60G 1.00 0.96 0.98
TL9E080C16UH11 XAHC60G 1.01 0.96 0.99
TL9E100C20UH11 CF/CM/CU48C 1.01 1.02 0.95
TL9E100C20UH11 CF/CM/CU48D 1.01 1.03 0.95
TL9E100C20UH11 CF/CM/CU60C 1.01 1.02 0.95
TL9E100C20UH11 CF/CM64D 1.01 1.03 0.93
TL9E100C20UH11 XAF/XAUC48F 1.00 0.98 0.96
TL9E100C20UH11 XAF/XAUC60G 1.01 0.95 0.93
TL9E100C20UH11 XAF/XAUD60G 1.00 0.95 0.93
TL9E100C20UH11 XAFD48F 0.98 0.93 0.94
TL9E100C20UH11 XAHC48F 1.00 0.98 1.00
TL9E100C20UH11 XAHC60G 1.01 0.95 0.93
TL9E100C20UH11 XAHD48F 0.99 0.98 0.96
TL9E100C20UH11 XAHD60G 1.01 1.00 0.99
TM8E080B12MP11 CF/CM/CU48C 1.01 1.01 0.99
TM8E080C16MP11 CF/CM/CU48C 1.00 1.02 1.00
TM8E080C16MP11 CF/CM/CU48D 1.01 1.04 1.01
TM8E080C16MP11 CF/CM/CU60C 1.01 1.06 0.97
TM8E080C16MP11 CF/CM64D 1.01 1.07 0.97
TM8E080C16MP11 XAF/XAUC48F 1.00 0.98 0.97
TM8E080C16MP11 XAF/XAUC60G 1.01 1.00 0.99
TM8E080C16MP11 XAF/XAUD60G 1.00 1.00 0.98
TM8E080C16MP11 XAFD48F 0.99 0.98 0.97
TM8E080C16MP11 XAHC48F 1.00 0.98 0.97
TM8E080C16MP11 XAHC60G 1.01 1.00 0.99
TM8E080C16MP11 XAHD48F 0.99 0.98 0.97
TM8E080C16MP11 XAHD60G 1.01 1.00 1.01
TM8E080C20MP11 CF/CM/CU48C 1.01 1.04 0.95
TM8E080C20MP11 CF/CM/CU48D 1.01 1.04 0.95
TM8E080C20MP11 CF/CM/CU60C 1.01 1.04 0.95
TM8E080C20MP11 CF/CM64D 1.01 1.04 0.93
TM8E080C20MP11 XAF/XAUC48F 0.99 0.94 0.95
TM8E080C20MP11 XAF/XAUC60G 1.01 0.97 0.93
TM8E080C20MP11 XAF/XAUD60G 1.00 0.97 0.93
TM8E080C20MP11 XAFD48F 0.98 0.94 0.93
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
