York LX series Technical Guide

5581700-YTG-F-1021
180 Johnson Controls Ducted Systems
TM8E080C20MP11 XAHC48F 0.99 0.94 0.97
TM8E080C20MP11 XAHC60G 1.01 0.97 0.93
TM8E080C20MP11 XAHD48F 0.98 0.94 0.94
TM8E080C20MP11 XAHD60G 1.01 0.96 0.93
TM8E100C16MP11 CF/CM/CU48C 1.01 0.99 0.95
TM8E100C16MP11 CF/CM/CU48D 1.01 0.99 0.95
TM8E100C16MP11 CF/CM/CU60C 1.01 1.06 0.97
TM8E100C16MP11 CF/CM64D 1.01 1.00 0.93
TM8E100C16MP11 XAF/XAUC48F 1.00 0.98 0.97
TM8E100C16MP11 XAF/XAUC60G 1.01 1.00 0.99
TM8E100C16MP11 XAF/XAUD60G 1.00 1.00 0.98
TM8E100C16MP11 XAFD48F 0.99 0.98 0.97
TM8E100C16MP11 XAHC48F 1.00 0.98 0.97
TM8E100C16MP11 XAHC60G 1.01 1.00 0.99
TM8E100C16MP11 XAHD48F 0.99 0.98 0.97
TM8E100C16MP11 XAHD60G 1.01 1.00 1.01
TM8E100C20MP11 CF/CM/CU48C 1.01 1.03 0.95
TM8E100C20MP11 CF/CM/CU48D 1.01 1.04 0.95
TM8E100C20MP11 CF/CM/CU60C 1.01 1.02 0.95
TM8E100C20MP11 CF/CM64D 1.01 1.03 0.93
TM8E100C20MP11 XAF/XAUC48F 0.99 0.93 0.95
TM8E100C20MP11 XAF/XAUC60G 1.01 0.96 0.93
TM8E100C20MP11 XAF/XAUD60G 1.00 0.96 0.93
TM8E100C20MP11 XAFD48F 0.98 0.93 0.94
TM8E100C20MP11 XAHC48F 0.99 0.93 0.97
TM8E100C20MP11 XAHC60G 1.01 0.96 0.93
TM8E100C20MP11 XAHD48F 0.98 0.93 0.94
TM8E100C20MP11 XAHD60G 1.01 0.95 0.93
TM8E120C16MP11 CF/CM/CU48C 1.01 0.99 0.95
TM8E120C16MP11 CF/CM/CU48D 1.01 0.99 0.95
TM8E120C16MP11 CF/CM/CU60C 1.01 0.99 0.95
TM8E120C16MP11 CF/CM64D 1.01 1.00 0.93
TM8E120C16MP11 XAF/XAUC48F 1.00 0.98 0.97
TM8E120C16MP11 XAF/XAUC60G 1.01 1.00 0.99
TM8E120C16MP11 XAF/XAUD60G 1.00 1.00 0.98
TM8E120C16MP11 XAFD48F 0.99 0.98 0.97
TM8E120C16MP11 XAHC48F 1.00 0.98 0.97
TM8E120C16MP11 XAHC60G 1.01 1.00 0.99
TM8E120C16MP11 XAHD48F 0.99 0.98 0.97
TM8E120C16MP11 XAHD60G 1.01 1.00 0.99
TM8E120C20MP11 CF/CM/CU48C 1.01 1.03 0.95
TM8E120C20MP11 CF/CM/CU48D 1.01 1.04 0.95
TM8E120C20MP11 CF/CM/CU60C 1.01 1.02 0.95
TM8E120C20MP11 CF/CM64D 1.01 1.03 0.93
TM8E120C20MP11 XAF/XAUC48F 0.99 0.93 0.95
TM8E120C20MP11 XAF/XAUC60G 1.01 0.96 0.93
TM8E120C20MP11 XAF/XAUD60G 1.00 0.96 0.93
TM8E120C20MP11 XAFD48F 0.98 0.94 0.93
TM8E120C20MP11 XAHC48F 0.99 0.93 0.97
TM8E120C20MP11 XAHC60G 1.01 0.96 0.93
TM8E120C20MP11 XAHD48F 0.98 0.93 0.93
TM8E120C20MP11 XAHD60G 1.01 0.95 0.93
TM8E130D20MP11 CF/CM/CU48D 1.01 1.03 0.93
TM8E130D20MP11 CF/CM64D 1.01 1.03 0.91
TM8E130D20MP11 XAF/XAUD60G 1.01 0.96 0.92
TM8E130D20MP11 XAFD48F 0.99 0.93 0.92
TM8E130D20MP11 XAHD48F 0.99 0.93 0.92
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW
TM8E130D20MP11 XAHD60G 1.01 1.02 0.96
TM8V080C16MP11C CF/CM/CU48C 0.99 1.01 0.93
TM8V080C16MP11C CF/CM/CU48D 1.01 1.03 0.95
TM8V080C16MP11C CF/CM/CU60C 0.99 1.02 0.93
TM8V080C16MP11C CF/CM/CU60D 0.99 1.02 0.91
TM8V080C16MP11C CF/CM64D 1.01 1.04 0.93
TM8V080C16MP12C CF/CM/CU48C 0.99 1.01 0.93
TM8V080C16MP12C CF/CM/CU48D 1.01 1.03 0.95
TM8V080C16MP12C CF/CM/CU60C 0.99 1.02 0.93
TM8V080C16MP12C CF/CM/CU60D 0.99 1.02 0.91
TM8V080C16MP12C CF/CM64D 1.01 1.04 0.93
TM8V080C16MP12C XAF/XAUC48F 0.99 0.94 0.99
TM8V080C16MP12C XAF/XAUC60G 0.99 0.96 0.95
TM8V080C16MP12C XAF/XAUD60G 0.99 0.96 0.95
TM8V080C16MP12C XAFD48F 0.98 0.94 0.96
TM8V080C16MP12C XAHC48F 0.99 0.94 0.99
TM8V080C16MP12C XAHC60G 0.99 0.96 0.95
TM8V080C16MP12C XAHD48F 0.98 0.94 0.96
TM8V080C16MP12C XAHD60G 0.99 0.96 0.95
TM8V100C16MP11C CF/CM/CU48C 0.99 0.96 0.93
TM8V100C16MP11C CF/CM/CU48D 1.01 0.98 0.95
TM8V100C16MP11C CF/CM/CU60C 0.99 0.96 0.91
TM8V100C16MP11C CF/CM/CU60D 0.99 0.96 0.91
TM8V100C16MP11C CF/CM64D 1.01 1.01 0.93
TM8V100C16MP12C CF/CM/CU48C 0.99 1.01 0.93
TM8V100C16MP12C CF/CM/CU48D 1.01 1.03 0.95
TM8V100C16MP12C CF/CM/CU60C 0.99 1.02 0.93
TM8V100C16MP12C CF/CM/CU60D 0.99 1.02 0.91
TM8V100C16MP12C CF/CM64D 1.01 1.04 0.93
TM8V100C16MP12C XAF/XAUC48F 0.99 0.94 0.99
TM8V100C16MP12C XAF/XAUC60G 0.99 0.96 0.95
TM8V100C16MP12C XAF/XAUD60G 0.99 0.96 0.95
TM8V100C16MP12C XAFD48F 0.98 0.94 0.96
TM8V100C16MP12C XAHC48F 0.99 0.94 0.99
TM8V100C16MP12C XAHC60G 0.99 0.96 0.95
TM8V100C16MP12C XAHD48F 0.98 0.94 0.96
TM8V100C16MP12C XAHD60G 0.99 0.96 0.95
TM8V100C20MP11C CF/CM/CU48C 0.99 1.05 0.93
TM8V100C20MP11C CF/CM/CU48D 1.01 1.07 0.93
TM8V100C20MP11C CF/CM/CU60C 1.00 1.06 0.92
TM8V100C20MP11C CF/CM/CU60D 1.01 1.09 0.95
TM8V100C20MP11C CF/CM64D 1.00 1.07 0.94
TM8V100C20MP12C CF/CM/CU48C 0.99 1.05 0.93
TM8V100C20MP12C CF/CM/CU48D 1.01 1.07 0.93
TM8V100C20MP12C CF/CM/CU60C 1.00 1.06 0.92
TM8V100C20MP12C CF/CM/CU60D 1.01 1.09 0.95
TM8V100C20MP12C CF/CM64D 1.00 1.07 0.94
TM8V100C20MP12C XAF/XAUC48F 0.99 0.94 0.97
TM8V100C20MP12C XAF/XAUC60G 1.00 0.96 0.94
TM8V100C20MP12C XAF/XAUD60G 1.00 0.96 0.93
TM8V100C20MP12C XAFD48F 0.98 0.94 0.93
TM8V100C20MP12C XAHC48F 0.99 0.94 0.97
TM8V100C20MP12C XAHC60G 1.00 0.96 0.94
TM8V100C20MP12C XAHD48F 0.98 0.94 0.93
TM8V100C20MP12C XAHD60G 1.01 0.96 0.93
TM8V120C20MP11C CF/CM/CU48C 0.99 0.96 0.93
TM8V120C20MP11C CF/CM/CU48D 1.01 1.03 0.93
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
