York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 181
TM8V120C20MP11C CF/CM/CU60C 1.00 0.99 0.92
TM8V120C20MP11C CF/CM/CU60D 0.99 0.97 0.93
TM8V120C20MP11C CF/CM64D 1.00 1.01 0.94
TM8V120C20MP12C CF/CM/CU48C 0.99 1.05 0.93
TM8V120C20MP12C CF/CM/CU48D 1.01 1.07 0.93
TM8V120C20MP12C CF/CM/CU60C 1.00 1.06 0.92
TM8V120C20MP12C CF/CM/CU60D 1.01 1.09 0.95
TM8V120C20MP12C CF/CM64D 1.00 1.07 0.94
TM8V120C20MP12C XAF/XAUC48F 0.99 0.94 0.97
TM8V120C20MP12C XAF/XAUC60G 1.00 0.96 0.94
TM8V120C20MP12C XAF/XAUD60G 1.00 0.96 0.93
TM8V120C20MP12C XAFD48F 0.98 0.94 0.93
TM8V120C20MP12C XAHC48F 0.99 0.94 0.97
TM8V120C20MP12C XAHC60G 1.00 0.96 0.94
TM8V120C20MP12C XAHD48F 0.98 0.94 0.93
TM8V120C20MP12C XAHD60G 1.01 0.96 0.93
TM8X080C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8X080C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8X080C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8X080C16MP11 CF/CM/CU60D 1.00 1.00 0.94
TM8X080C16MP11 CF/CM64D 1.00 1.00 0.92
TM8X100C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8X100C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8X100C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8X100C16MP11 CF/CM/CU60D 1.00 1.00 0.94
TM8X100C16MP11 CF/CM64D 1.00 1.00 0.92
TM8X100C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8X100C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8X100C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8X100C20MP11 CF/CM/CU60D 1.01 1.03 0.93
TM8X100C20MP11 CF/CM64D 1.00 1.01 0.92
TM8X120C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8X120C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8X120C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8X120C20MP11 CF/CM/CU60D 1.01 1.03 0.93
TM8X120C20MP11 CF/CM64D 1.00 1.01 0.92
TM8Y080C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8Y080C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8Y080C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8Y080C16MP11 CF/CM/CU60D 1.00 1.00 0.94
TM8Y080C16MP11 CF/CM64D 1.00 1.00 0.92
TM8Y080C16MP11 XAF/XAUC48F 0.99 0.96 0.97
TM8Y080C16MP11 XAF/XAUC60G 1.01 0.99 0.99
TM8Y080C16MP11 XAF/XAUD60G 1.00 1.00 0.98
TM8Y080C16MP11 XAFD48F 0.98 0.96 0.96
TM8Y080C16MP11 XAHC48F 0.99 0.96 0.97
TM8Y080C16MP11 XAHC60G 1.01 1.00 0.99
TM8Y080C16MP11 XAHD48F 0.98 0.96 0.97
TM8Y080C16MP11 XAHD60G 1.01 0.99 1.01
TM8Y100C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8Y100C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8Y100C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8Y100C16MP11 CF/CM/CU60D 1.00 1.00 0.94
TM8Y100C16MP11 CF/CM64D 1.00 1.00 0.92
TM8Y100C16MP11 XAF/XAUC48F 0.99 0.96 0.97
TM8Y100C16MP11 XAF/XAUC60G 1.01 0.99 0.99
TM8Y100C16MP11 XAF/XAUD60G 1.00 1.00 0.98
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW
TM8Y100C16MP11 XAFD48F 0.98 0.96 0.96
TM8Y100C16MP11 XAHC48F 0.99 0.96 0.97
TM8Y100C16MP11 XAHC60G 1.01 1.00 0.99
TM8Y100C16MP11 XAHD48F 0.98 0.96 0.97
TM8Y100C16MP11 XAHD60G 1.01 0.99 1.01
TM8Y100C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8Y100C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8Y100C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8Y100C20MP11 CF/CM/CU60D 1.01 1.03 0.93
TM8Y100C20MP11 CF/CM64D 1.00 1.01 0.92
TM8Y100C20MP11 XAF/XAUC48F 1.00 0.96 0.98
TM8Y100C20MP11 XAF/XAUC60G 1.01 0.99 0.95
TM8Y100C20MP11 XAF/XAUD60G 1.00 0.99 0.95
TM8Y100C20MP11 XAFD48F 0.99 0.97 0.97
TM8Y100C20MP11 XAHC48F 0.99 0.96 0.99
TM8Y100C20MP11 XAHC60G 1.01 0.99 0.95
TM8Y100C20MP11 XAHD48F 0.99 0.96 0.97
TM8Y100C20MP11 XAHD60G 1.01 0.99 0.97
TM8Y120C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8Y120C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8Y120C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8Y120C20MP11 CF/CM/CU60D 1.01 1.03 0.93
TM8Y120C20MP11 CF/CM64D 1.00 1.01 0.92
TM8Y120C20MP11 XAF/XAUC48F 1.00 0.96 0.98
TM8Y120C20MP11 XAF/XAUC60G 1.01 0.99 0.95
TM8Y120C20MP11 XAF/XAUD60G 1.00 0.99 0.95
TM8Y120C20MP11 XAFD48F 0.99 0.97 0.97
TM8Y120C20MP11 XAHC48F 0.99 0.96 0.99
TM8Y120C20MP11 XAHC60G 1.01 0.99 0.95
TM8Y120C20MP11 XAHD48F 0.99 0.96 0.97
TM8Y120C20MP11 XAHD60G 1.01 0.99 0.97
TM9E080B12MP12 CF/CM/CU48C 1.01 1.01 0.99
TM9E080B12MP12 CF/CM/CU60C 1.00 0.99 1.00
TM9E080C16MP11 CF/CM/CU48C 0.98 0.95 0.94
TM9E080C16MP11 CF/CM/CU48D 0.98 0.95 0.94
TM9E080C16MP11 CF/CM/CU60C 1.00 0.98 0.94
TM9E080C16MP11 CF/CM/CU60D 0.99 0.97 0.93
TM9E080C16MP11 CF/CM64D 0.99 0.95 0.93
TM9E080C20MP12 CF/CM/CU48C 1.01 1.02 0.95
TM9E080C20MP12 CF/CM/CU48D 1.01 1.03 0.95
TM9E080C20MP12 CF/CM/CU60C 1.01 1.02 0.95
TM9E080C20MP12 CF/CM64D 1.01 1.03 0.93
TM9E080C20MP12 XAF/XAUC48F 1.00 0.95 0.98
TM9E080C20MP12 XAF/XAUC60G 1.01 0.95 0.93
TM9E080C20MP12 XAF/XAUD60G 1.00 0.95 0.93
TM9E080C20MP12 XAFD48F 0.98 0.93 0.92
TM9E080C20MP12 XAHC48F 0.99 0.95 0.99
TM9E080C20MP12 XAHC60G 1.01 0.95 0.92
TM9E080C20MP12 XAHD48F 0.99 0.95 0.97
TM9E080C20MP12 XAHD60G 1.01 0.98 0.94
TM9E100C16MP11 CF/CM/CU48C 0.98 0.95 0.94
TM9E100C16MP11 CF/CM/CU48D 0.98 0.95 0.94
TM9E100C16MP11 CF/CM/CU60C 1.00 0.98 0.94
TM9E100C16MP11 CF/CM/CU60D 0.99 0.97 0.93
TM9E100C16MP11 CF/CM64D 0.99 0.95 0.93
TM9E100C20MP11 CF/CM/CU48C 0.99 1.00 0.93
TM9E100C20MP11 CF/CM/CU48D 1.00 0.99 0.94
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
