York LX series Technical Guide

5581700-YTG-F-1021
182 Johnson Controls Ducted Systems
TM9E100C20MP11 CF/CM/CU60C 1.00 0.99 0.94
TM9E100C20MP11 CF/CM/CU60D 1.00 1.02 0.92
TM9E100C20MP11 CF/CM64D 1.00 1.00 0.92
TM9E100C20MP12 CF/CM/CU48C 1.01 1.02 0.95
TM9E100C20MP12 CF/CM/CU48D 1.01 1.03 0.95
TM9E100C20MP12 CF/CM/CU60C 1.01 1.02 0.95
TM9E100C20MP12 CF/CM64D 1.01 1.03 0.93
TM9E100C20MP12 XAF/XAUC48F 1.00 0.95 0.98
TM9E100C20MP12 XAF/XAUC60G 1.01 0.96 0.92
TM9E100C20MP12 XAF/XAUD60G 1.00 0.96 0.92
TM9E100C20MP12 XAFD48F 0.99 0.96 0.97
TM9E100C20MP12 XAHC48F 0.99 0.95 0.99
TM9E100C20MP12 XAHC60G 1.01 0.96 0.92
TM9E100C20MP12 XAHD48F 0.99 0.96 0.97
TM9E100C20MP12 XAHD60G 1.01 0.98 0.97
TM9E120D20MP11 CF/CM/CU48D 0.99 0.98 0.93
TM9E120D20MP11 CF/CM/CU60D 0.99 0.99 0.91
TM9E120D20MP11 CF/CM64D 1.01 1.01 0.93
TM9E120D20MP12 CF/CM/CU48D 1.01 1.04 0.95
TM9E120D20MP12 CF/CM64D 1.01 1.04 0.93
TM9E120D20MP12 XAF/XAUD60G 1.01 0.96 0.93
TM9E120D20MP12 XAFD48F 0.99 0.94 0.97
TM9E120D20MP12 XAHD48F 0.99 0.93 0.97
TM9E120D20MP12 XAHD60G 1.01 0.95 0.97
TM9V080C16MP11C CF/CM/CU48C 0.99 0.97 0.93
TM9V080C16MP11C CF/CM/CU48D 0.99 0.96 0.91
TM9V080C16MP11C CF/CM/CU60C 0.99 0.97 0.93
TM9V080C16MP11C CF/CM/CU60D 0.99 0.97 0.93
TM9V080C16MP11C CF/CM64D 0.99 0.98 0.91
TM9V080C16MP12C CF/CM/CU48C 0.99 0.97 0.93
TM9V080C16MP12C CF/CM/CU48D 0.99 0.96 0.91
TM9V080C16MP12C CF/CM/CU60C 0.99 0.97 0.93
TM9V080C16MP12C CF/CM/CU60D 0.99 0.97 0.93
TM9V080C16MP12C CF/CM64D 0.99 0.98 0.91
TM9V080C16MP12C XAF/XAUC60G 0.99 0.98 0.99
TM9V080C16MP12C XAF/XAUD60G 0.99 0.98 0.99
TM9V080C16MP12C XAFD48F 0.98 0.95 0.97
TM9V080C16MP12C XAHC60G 0.99 0.98 0.99
TM9V100C16MP11C CF/CM/CU48C 1.01 1.01 0.95
TM9V100C16MP11C CF/CM/CU48D 0.99 0.98 0.91
TM9V100C16MP11C CF/CM/CU60C 0.98 1.01 0.92
TM9V100C16MP11C CF/CM/CU60D 0.99 0.99 0.93
TM9V100C16MP11C CF/CM64D 0.98 0.95 0.90
TM9V100C16MP12C CF/CM/CU48C 0.99 1.02 0.93
TM9V100C16MP12C CF/CM/CU48D 0.99 1.02 0.93
TM9V100C16MP12C CF/CM/CU60C 0.98 1.01 0.92
TM9V100C16MP12C CF/CM/CU60D 0.99 1.02 0.93
TM9V100C16MP12C CF/CM64D 0.98 1.02 0.90
TM9V100C16MP12C XAF/XAUC48F 0.99 0.94 0.97
TM9V100C16MP12C XAF/XAUC60G 0.99 0.96 0.95
TM9V100C16MP12C XAF/XAUD60G 0.99 0.96 0.95
TM9V100C16MP12C XAFD48F 0.98 0.94 0.96
TM9V100C16MP12C XAHC48F 0.99 0.94 0.99
TM9V100C16MP12C XAHC60G 0.99 0.96 0.95
TM9V100C16MP12C XAHD48F 0.98 0.94 0.96
TM9V100C16MP12C XAHD60G 0.99 0.96 0.95
TM9V100C20MP11C CF/CM/CU48C 1.01 1.01 0.97
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW
TM9V100C20MP11C CF/CM/CU48D 1.01 0.98 0.93
TM9V100C20MP11C CF/CM/CU60C 1.01 1.04 0.97
TM9V100C20MP11C CF/CM/CU60D 0.98 0.95 0.92
TM9V100C20MP11C CF/CM64D 0.98 0.95 0.90
TM9V100C20MP12C CF/CM/CU48C 1.00 1.04 0.96
TM9V100C20MP12C CF/CM/CU48D 1.00 1.03 0.94
TM9V100C20MP12C CF/CM/CU60C 1.00 1.08 0.96
TM9V100C20MP12C CF/CM/CU60D 0.98 1.05 0.92
TM9V100C20MP12C CF/CM64D 0.98 1.05 0.90
TM9V100C20MP12C XAF/XAUC48F 0.99 0.95 0.99
TM9V100C20MP12C XAF/XAUC60G 1.00 0.98 0.98
TM9V100C20MP12C XAF/XAUD60G 0.98 0.98 0.94
TM9V100C20MP12C XAFD48F 0.98 0.95 0.96
TM9V100C20MP12C XAHC48F 0.99 0.95 0.99
TM9V100C20MP12C XAHC60G 1.00 0.98 0.98
TM9V100C20MP12C XAHD48F 0.98 0.95 0.96
TM9V100C20MP12C XAHD60G 0.99 0.97 0.97
TM9V120D20MP11C CF/CM/CU48D 0.98 0.95 0.92
TM9V120D20MP11C CF/CM/CU60D 0.98 0.95 0.90
TM9V120D20MP11C CF/CM64D 1.01 1.04 0.95
TM9V120D20MP12C CF/CM/CU48D 0.98 1.04 0.92
TM9V120D20MP12C CF/CM/CU60D 1.01 1.08 0.93
TM9V120D20MP12C CF/CM64D 1.01 1.09 0.95
TM9V120D20MP12C XAF/XAUD60G 1.01 0.96 0.92
TM9V120D20MP12C XAFD48F 0.98 0.93 0.94
TM9V120D20MP12C XAHD48F 0.98 0.93 0.94
TM9V120D20MP12C XAHD60G 1.01 0.95 0.93
TM9Y080C16MP11 CF/CM/CU48C 0.98 0.95 0.94
TM9Y080C16MP11 CF/CM/CU48D 0.98 0.95 0.94
TM9Y080C16MP11 CF/CM/CU60C 1.00 0.98 0.94
TM9Y080C16MP11 CF/CM/CU60D 0.99 0.97 0.93
TM9Y080C16MP11 CF/CM64D 0.99 0.95 0.93
TM9Y100C16MP11 CF/CM/CU48C 0.98 0.95 0.94
TM9Y100C16MP11 CF/CM/CU48D 0.98 0.95 0.94
TM9Y100C16MP11 CF/CM/CU60C 1.00 0.98 0.94
TM9Y100C16MP11 CF/CM/CU60D 0.99 0.97 0.93
TM9Y100C16MP11 CF/CM64D 0.99 0.95 0.93
TM9Y100C16MP11 XAF/XAUC60G 1.00 0.96 0.98
TM9Y100C16MP11 XAF/XAUD60G 0.99 0.96 0.97
TM9Y100C16MP11 XAHC60G 1.00 0.96 0.98
TM9Y100C20MP11 CF/CM/CU48C 0.99 1.00 0.93
TM9Y100C20MP11 CF/CM/CU48D 1.00 0.99 0.94
TM9Y100C20MP11 CF/CM/CU60C 1.00 0.99 0.94
TM9Y100C20MP11 CF/CM/CU60D 1.00 1.02 0.92
TM9Y100C20MP11 CF/CM64D 1.00 1.00 0.92
TM9Y100C20MP11 XAF/XAUC48F 1.00 0.97 0.96
TM9Y100C20MP11 XAF/XAUC60G 1.01 0.99 0.99
TM9Y100C20MP11 XAF/XAUD60G 1.00 0.99 0.98
TM9Y100C20MP11 XAFD48F 0.99 0.97 0.96
TM9Y100C20MP11 XAHC48F 0.99 0.97 0.99
TM9Y100C20MP11 XAHC60G 1.01 0.99 0.99
TM9Y100C20MP11 XAHD48F 0.99 0.97 0.96
TM9Y100C20MP11 XAHD60G 1.01 0.99 0.99
TM9Y120D20MP11 CF/CM/CU48D 0.99 0.98 0.93
TM9Y120D20MP11 CF/CM/CU60D 0.99 0.99 0.91
TM9Y120D20MP11 CF/CM64D 1.01 1.01 0.93
TM9Y120D20MP11 XAF/XAUD60G 1.01 1.00 0.99
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
