York LX series Technical Guide

5581700-YTG-F-1021
184 Johnson Controls Ducted Systems
TMLX080C16MP11 CF/CM/CU60D 1.00 1.00 0.94
TMLX080C16MP11 CF/CM64D 1.00 1.00 0.92
TMLX100C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TMLX100C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TMLX100C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TMLX100C16MP11 CF/CM/CU60D 1.00 1.00 0.94
TMLX100C16MP11 CF/CM64D 1.00 1.00 0.92
TMLX100C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TMLX100C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TMLX100C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TMLX100C20MP11 CF/CM/CU60D 1.01 1.03 0.93
TMLX100C20MP11 CF/CM64D 1.00 1.01 0.92
TMLX120C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TMLX120C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TMLX120C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TMLX120C20MP11 CF/CM/CU60D 1.01 1.03 0.93
TMLX120C20MP11 CF/CM64D 1.00 1.01 0.92
TP9C080C16MP12C CF/CM/CU48C 1.01 1.01 0.95
TP9C080C16MP12C CF/CM/CU48D 0.99 0.98 0.91
TP9C080C16MP12C CF/CM/CU60C 0.98 0.96 0.92
TP9C080C16MP12C CF/CM/CU60D 0.99 0.99 0.93
TP9C080C16MP12C CF/CM64D 0.98 0.95 0.90
TP9C080C16MP13C CF/CM/CU48C 0.99 0.97 0.93
TP9C080C16MP13C CF/CM/CU48D 0.99 0.96 0.91
TP9C080C16MP13C CF/CM/CU60C 0.99 0.97 0.93
TP9C080C16MP13C CF/CM/CU60D 0.99 0.97 0.93
TP9C080C16MP13C CF/CM64D 0.99 0.98 0.91
TP9C080C16MP13C XAF/XAUC60G 0.99 0.98 0.99
TP9C080C16MP13C XAF/XAUD60G 0.99 0.98 0.99
TP9C080C16MP13C XAFD48F 0.98 0.95 0.97
TP9C080C16MP13C XAHC60G 0.99 0.98 0.99
TP9C100C16MP12C CF/CM/CU48C 0.99 1.02 0.93
TP9C100C16MP12C CF/CM/CU48D 0.99 1.02 0.93
TP9C100C16MP12C CF/CM/CU60C 0.98 1.01 0.92
TP9C100C16MP12C CF/CM/CU60D 0.99 1.02 0.93
TP9C100C16MP12C CF/CM64D 0.98 1.02 0.90
TP9C100C16MP13C CF/CM/CU48C 0.99 1.02 0.93
TP9C100C16MP13C CF/CM/CU48D 0.99 1.02 0.93
TP9C100C16MP13C CF/CM/CU60C 0.98 1.01 0.92
TP9C100C16MP13C CF/CM/CU60D 0.99 1.02 0.93
TP9C100C16MP13C CF/CM64D 0.98 1.02 0.90
TP9C100C16MP13C XAF/XAUC48F 0.99 0.94 0.97
TP9C100C16MP13C XAF/XAUC60G 0.99 0.96 0.95
TP9C100C16MP13C XAF/XAUD60G 0.99 0.96 0.95
TP9C100C16MP13C XAFD48F 0.98 0.94 0.96
TP9C100C16MP13C XAHC48F 0.99 0.94 0.99
TP9C100C16MP13C XAHC60G 0.99 0.96 0.95
TP9C100C16MP13C XAHD48F 0.98 0.94 0.96
TP9C100C16MP13C XAHD60G 0.99 0.96 0.95
TP9C100C20MP12C CF/CM/CU48C 1.00 1.04 0.96
TP9C100C20MP12C CF/CM/CU48D 1.00 1.03 0.94
TP9C100C20MP12C CF/CM/CU60C 1.00 1.08 0.96
TP9C100C20MP12C CF/CM/CU60D 0.98 1.05 0.92
TP9C100C20MP12C CF/CM64D 0.98 1.05 0.90
TP9C100C20MP13C CF/CM/CU48C 1.00 1.04 0.96
TP9C100C20MP13C CF/CM/CU48D 1.00 1.03 0.94
TP9C100C20MP13C CF/CM/CU60C 1.00 1.08 0.96
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW
TP9C100C20MP13C CF/CM/CU60D 0.98 1.05 0.92
TP9C100C20MP13C CF/CM64D 0.98 1.05 0.90
TP9C100C20MP13C XAF/XAUC48F 0.99 0.95 0.99
TP9C100C20MP13C XAF/XAUC60G 1.00 0.98 0.98
TP9C100C20MP13C XAF/XAUD60G 0.98 0.98 0.94
TP9C100C20MP13C XAFD48F 0.98 0.95 0.96
TP9C100C20MP13C XAHC48F 0.99 0.95 0.99
TP9C100C20MP13C XAHC60G 1.00 0.98 0.98
TP9C100C20MP13C XAHD48F 0.98 0.95 0.96
TP9C100C20MP13C XAHD60G 0.99 0.97 0.97
TP9C120D20MP12C CF/CM/CU48D 0.98 0.95 0.92
TP9C120D20MP12C CF/CM/CU60D 0.98 0.95 0.90
TP9C120D20MP12C CF/CM64D 1.01 1.04 0.95
TP9C120D20MP13C CF/CM/CU48D 0.98 1.04 0.92
TP9C120D20MP13C CF/CM/CU60D 1.01 1.08 0.93
TP9C120D20MP13C CF/CM64D 1.01 1.09 0.95
TP9C120D20MP13C XAF/XAUD60G 1.01 0.96 0.92
TP9C120D20MP13C XAFD48F 0.98 0.93 0.94
TP9C120D20MP13C XAHD48F 0.98 0.93 0.94
TP9C120D20MP13C XAHD60G 1.01 0.95 0.93
TPLC080C16MP12C CF/CM/CU48C 0.99 1.01 0.93
TPLC080C16MP12C CF/CM/CU48D 1.01 1.03 0.95
TPLC080C16MP12C CF/CM/CU60C 0.99 1.02 0.93
TPLC080C16MP12C CF/CM/CU60D 0.99 1.02 0.91
TPLC080C16MP12C CF/CM64D 1.01 1.04 0.93
TPLC080C16MP13C CF/CM/CU48C 0.99 1.01 0.93
TPLC080C16MP13C CF/CM/CU48D 1.01 1.03 0.95
TPLC080C16MP13C CF/CM/CU60C 0.99 1.02 0.93
TPLC080C16MP13C CF/CM/CU60D 0.99 1.02 0.91
TPLC080C16MP13C CF/CM64D 1.01 1.04 0.93
TPLC080C16MP13C XAF/XAUC48F 0.99 0.94 0.99
TPLC080C16MP13C XAF/XAUC60G 0.99 0.96 0.95
TPLC080C16MP13C XAF/XAUD60G 0.99 0.96 0.95
TPLC080C16MP13C XAFD48F 0.98 0.94 0.96
TPLC080C16MP13C XAHC48F 0.99 0.94 0.99
TPLC080C16MP13C XAHC60G 0.99 0.96 0.95
TPLC080C16MP13C XAHD48F 0.98 0.94 0.96
TPLC080C16MP13C XAHD60G 0.99 0.96 0.95
TPLC100C16MP12C CF/CM/CU48C 0.99 1.01 0.93
TPLC100C16MP12C CF/CM/CU48D 1.01 1.03 0.95
TPLC100C16MP12C CF/CM/CU60C 0.99 1.02 0.93
TPLC100C16MP12C CF/CM/CU60D 0.99 1.02 0.91
TPLC100C16MP12C CF/CM64D 1.01 1.04 0.93
TPLC100C16MP13C CF/CM/CU48C 0.99 1.01 0.93
TPLC100C16MP13C CF/CM/CU48D 1.01 1.03 0.95
TPLC100C16MP13C CF/CM/CU60C 0.99 1.02 0.93
TPLC100C16MP13C CF/CM/CU60D 0.99 1.02 0.91
TPLC100C16MP13C CF/CM64D 1.01 1.04 0.93
TPLC100C16MP13C XAF/XAUC48F 0.99 0.94 0.99
TPLC100C16MP13C XAF/XAUC60G 0.99 0.96 0.95
TPLC100C16MP13C XAF/XAUD60G 0.99 0.96 0.95
TPLC100C16MP13C XAFD48F 0.98 0.94 0.96
TPLC100C16MP13C XAHC48F 0.99 0.94 0.99
TPLC100C16MP13C XAHC60G 0.99 0.96 0.95
TPLC100C16MP13C XAHD48F 0.98 0.94 0.96
TPLC100C16MP13C XAHD60G 0.99 0.96 0.95
TPLC100C20MP12C CF/CM/CU48C 0.99 0.96 0.93
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
