York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 185
TPLC100C20MP12C CF/CM/CU48D 1.01 1.03 0.93
TPLC100C20MP12C CF/CM/CU60C 1.00 0.99 0.92
TPLC100C20MP12C CF/CM/CU60D 0.99 0.97 0.93
TPLC100C20MP12C CF/CM64D 1.00 1.01 0.94
TPLC100C20MP13C CF/CM/CU48C 0.99 1.05 0.93
TPLC100C20MP13C CF/CM/CU48D 1.01 1.07 0.93
TPLC100C20MP13C CF/CM/CU60C 1.00 1.06 0.92
TPLC100C20MP13C CF/CM/CU60D 1.01 1.09 0.95
TPLC100C20MP13C CF/CM64D 1.00 1.07 0.94
TPLC100C20MP13C XAF/XAUC48F 0.99 0.94 0.97
TPLC100C20MP13C XAF/XAUC60G 1.00 0.96 0.94
TPLC100C20MP13C XAF/XAUD60G 1.00 0.96 0.93
TPLC100C20MP13C XAFD48F 0.98 0.94 0.93
TPLC100C20MP13C XAHC48F 0.99 0.94 0.97
TPLC100C20MP13C XAHC60G 1.00 0.96 0.94
TPLC100C20MP13C XAHD48F 0.98 0.94 0.93
TPLC100C20MP13C XAHD60G 1.01 0.96 0.93
TPLC120C20MP12C CF/CM/CU48C 0.99 0.96 0.93
TPLC120C20MP12C CF/CM/CU48D 1.01 1.03 0.93
TPLC120C20MP12C CF/CM/CU60C 1.00 0.99 0.92
TPLC120C20MP12C CF/CM/CU60D 0.99 0.97 0.93
TPLC120C20MP12C CF/CM64D 1.00 1.01 0.94
TPLC120C20MP13C CF/CM/CU48C 0.99 1.05 0.93
TPLC120C20MP13C CF/CM/CU48D 1.01 1.07 0.93
TPLC120C20MP13C CF/CM/CU60C 1.00 1.06 0.92
TPLC120C20MP13C CF/CM/CU60D 1.01 1.09 0.95
TPLC120C20MP13C CF/CM64D 1.00 1.07 0.94
TPLC120C20MP13C XAF/XAUC48F 0.99 0.94 0.97
TPLC120C20MP13C XAF/XAUC60G 1.00 0.96 0.94
TPLC120C20MP13C XAF/XAUD60G 1.00 0.96 0.93
TPLC120C20MP13C XAFD48F 0.98 0.94 0.93
TPLC120C20MP13C XAHC48F 0.99 0.94 0.97
TPLC120C20MP13C XAHC60G 1.00 0.96 0.94
TPLC120C20MP13C XAHD48F 0.98 0.94 0.93
TPLC120C20MP13C XAHD60G 1.01 0.96 0.93
YP9C080C16MP12C CF/CM/CU48C 1.01 1.01 0.95
YP9C080C16MP12C CF/CM/CU48D 0.99 0.98 0.91
YP9C080C16MP12C CF/CM/CU60C 0.98 0.96 0.92
YP9C080C16MP12C CF/CM/CU60D 0.99 0.99 0.93
YP9C080C16MP12C CF/CM64D 0.98 0.95 0.90
YP9C080C16MP13C CF/CM/CU48C 0.99 0.97 0.93
YP9C080C16MP13C CF/CM/CU48D 0.99 0.96 0.91
YP9C080C16MP13C CF/CM/CU60C 0.99 0.97 0.93
YP9C080C16MP13C CF/CM/CU60D 0.99 0.97 0.93
YP9C080C16MP13C CF/CM64D 0.99 0.98 0.91
YP9C080C16MP13C XAF/XAUC60G 0.99 0.98 0.99
YP9C080C16MP13C XAF/XAUD60G 0.99 0.98 0.99
YP9C080C16MP13C XAFD48F 0.98 0.95 0.97
YP9C080C16MP13C XAHC60G 0.99 0.98 0.99
YP9C100C16MP12C CF/CM/CU48C 0.99 1.02 0.93
YP9C100C16MP12C CF/CM/CU48D 0.99 1.02 0.93
YP9C100C16MP12C CF/CM/CU60C 0.98 1.01 0.92
YP9C100C16MP12C CF/CM/CU60D 0.99 1.02 0.93
YP9C100C16MP12C CF/CM64D 0.98 1.02 0.90
YP9C100C16MP13C CF/CM/CU48C 0.99 1.02 0.93
YP9C100C16MP13C CF/CM/CU48D 0.99 1.02 0.93
YP9C100C16MP13C CF/CM/CU60C 0.98 1.01 0.92
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW
YP9C100C16MP13C CF/CM/CU60D 0.99 1.02 0.93
YP9C100C16MP13C CF/CM64D 0.98 1.02 0.90
YP9C100C16MP13C XAF/XAUC48F 0.99 0.94 0.97
YP9C100C16MP13C XAF/XAUC60G 0.99 0.96 0.95
YP9C100C16MP13C XAF/XAUD60G 0.99 0.96 0.95
YP9C100C16MP13C XAFD48F 0.98 0.94 0.96
YP9C100C16MP13C XAHC48F 0.99 0.94 0.99
YP9C100C16MP13C XAHC60G 0.99 0.96 0.95
YP9C100C16MP13C XAHD48F 0.98 0.94 0.96
YP9C100C16MP13C XAHD60G 0.99 0.96 0.95
YP9C100C20MP12C CF/CM/CU48C 1.00 1.04 0.96
YP9C100C20MP12C CF/CM/CU48D 1.00 1.03 0.94
YP9C100C20MP12C CF/CM/CU60C 1.00 1.08 0.96
YP9C100C20MP12C CF/CM/CU60D 0.98 1.05 0.92
YP9C100C20MP12C CF/CM64D 0.98 1.05 0.90
YP9C100C20MP13C CF/CM/CU48C 1.00 1.04 0.96
YP9C100C20MP13C CF/CM/CU48D 1.00 1.03 0.94
YP9C100C20MP13C CF/CM/CU60C 1.00 1.08 0.96
YP9C100C20MP13C CF/CM/CU60D 0.98 1.05 0.92
YP9C100C20MP13C CF/CM64D 0.98 1.05 0.90
YP9C100C20MP13C XAF/XAUC48F 0.99 0.95 0.99
YP9C100C20MP13C XAF/XAUC60G 1.00 0.98 0.98
YP9C100C20MP13C XAF/XAUD60G 0.98 0.98 0.94
YP9C100C20MP13C XAFD48F 0.98 0.95 0.96
YP9C100C20MP13C XAHC48F 0.99 0.95 0.99
YP9C100C20MP13C XAHC60G 1.00 0.98 0.98
YP9C100C20MP13C XAHD48F 0.98 0.95 0.96
YP9C100C20MP13C XAHD60G 0.99 0.97 0.97
YP9C120D20MP12C CF/CM/CU48D 0.98 1.04 0.92
YP9C120D20MP12C CF/CM/CU60D 1.01 1.08 0.93
YP9C120D20MP12C CF/CM64D 1.01 1.09 0.95
YP9C120D20MP13C CF/CM/CU48D 0.98 1.04 0.92
YP9C120D20MP13C CF/CM/CU60D 1.01 1.08 0.93
YP9C120D20MP13C CF/CM64D 1.01 1.09 0.95
YP9C120D20MP13C XAF/XAUD60G 1.01 0.96 0.92
YP9C120D20MP13C XAFD48F 0.98 0.93 0.94
YP9C120D20MP13C XAHD48F 0.98 0.93 0.94
YP9C120D20MP13C XAHD60G 1.01 0.95 0.93
YPLC080C16MP12C CF/CM/CU48C 0.99 1.01 0.93
YPLC080C16MP12C CF/CM/CU48D 1.01 1.03 0.95
YPLC080C16MP12C CF/CM/CU60C 0.99 1.02 0.93
YPLC080C16MP12C CF/CM/CU60D 0.99 1.02 0.91
YPLC080C16MP12C CF/CM64D 1.01 1.04 0.93
YPLC080C16MP13C CF/CM/CU48C 0.99 1.01 0.93
YPLC080C16MP13C CF/CM/CU48D 1.01 1.03 0.95
YPLC080C16MP13C CF/CM/CU60C 0.99 1.02 0.93
YPLC080C16MP13C CF/CM/CU60D 0.99 1.02 0.91
YPLC080C16MP13C CF/CM64D 1.01 1.04 0.93
YPLC080C16MP13C XAF/XAUC48F 0.99 0.94 0.99
YPLC080C16MP13C XAF/XAUC60G 0.99 0.96 0.95
YPLC080C16MP13C XAF/XAUD60G 0.99 0.96 0.95
YPLC080C16MP13C XAFD48F 0.98 0.94 0.96
YPLC080C16MP13C XAHC48F 0.99 0.94 0.99
YPLC080C16MP13C XAHC60G 0.99 0.96 0.95
YPLC080C16MP13C XAHD48F 0.98 0.94 0.96
YPLC080C16MP13C XAHD60G 0.99 0.96 0.95
YPLC100C16MP12C CF/CM/CU48C 0.99 1.01 0.93
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil
T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
