York LX series Technical Guide

5581700-YTG-F-1021
20 Johnson Controls Ducted Systems
YCE18B22S YPLC060A12MP12C 14.5 CF/CM/CU24A 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC060A12MP12C 14.5 CF/CM/CU24B 625 18.0 14.6 16.00 13.25
YCE18B22S YPLC060A12MP12C 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S YPLC060A12MP12C 14.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S YPLC060A12MP12C 14.5 CF/CM/CU36B 625 18.0 14.8 16.00 13.25
YCE18B22S YPLC060A12MP12C 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM/CU18A 625 17.9 14.5 15.75 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM/CU18B 625 17.9 14.5 15.75 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM/CU24A 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM/CU24B 625 18.0 14.6 16.00 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM/CU30A 625 18.0 14.5 16.00 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM/CU36B 625 18.0 14.8 16.00 13.25
YCE18B22S YPLC060A12MP13C 14.5 CF/CM36A 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC060A12MP13C 14.5 XAF/XAUA24B 625 18.0 13.4 16.00 13.00
YCE18B22S YPLC060A12MP13C 17.5 XAFB24B 700 18.0 14.2 16.00 13.00
YCE18B22S YPLC060A12MP13C 14.5 XAHA24B 625 18.0 13.4 16.00 13.00
YCE18B22S YPLC060A12MP13C 17.5 XAHB24B 625 18.0 13.4 16.00 13.00
YCE18B22S YPLC080B12MP12C 17.5 CF/CM/CU18B 625 17.8 14.4 15.50 13.25
YCE18B22S YPLC080B12MP12C 17.5 CF/CM/CU24B 625 18.0 14.7 15.75 13.25
YCE18B22S YPLC080B12MP12C 17.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S YPLC080B12MP12C 17.5 CF/CM/CU36B 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC080B12MP12C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S YPLC080B12MP12C 17.5 CF/CM24C 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC080B12MP12C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S YPLC080B12MP13C 17.5 CF/CM/CU18B 625 17.8 14.4 15.50 13.25
YCE18B22S YPLC080B12MP13C 17.5 CF/CM/CU24B 625 18.0 14.7 15.75 13.25
YCE18B22S YPLC080B12MP13C 17.5 CF/CM/CU30B 625 18.0 14.5 16.00 13.25
YCE18B22S YPLC080B12MP13C 17.5 CF/CM/CU36B 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC080B12MP13C 17.5 CF/CM/CU36C 675 18.0 15.0 16.00 13.25
YCE18B22S YPLC080B12MP13C 17.5 CF/CM24C 625 18.0 14.7 16.00 13.25
YCE18B22S YPLC080B12MP13C 17.5 CF/CM30C 675 18.0 14.9 16.00 13.25
YCE18B22S YPLC080B12MP13C 17.5 XAFB24B 625 18.0 13.4 15.75 13.00
YCE18B22S YPLC080B12MP13C 17.5 XAHB24B 625 18.0 13.4 15.75 13.00
YCE24B22S TL8E060A12UH11 14.5 CF/CM/CU24A 650 24.0 17.3 15.75 13.00
YCE24B22S TL8E060A12UH11 14.5 CF/CM/CU24B 700 24.0 17.8 15.75 13.00
YCE24B22S TL8E060A12UH11 14.5 CF/CM/CU30A 650 24.0 17.2 16.00 13.00
YCE24B22S TL8E060A12UH11 14.5 CF/CM/CU30B 700 24.0 17.7 16.00 13.00
YCE24B22S TL8E060A12UH11 14.5 CF/CM/CU36B 650 24.0 17.4 16.00 13.00
YCE24B22S TL8E060A12UH11 14.5 CF/CM36A 650 24.0 17.3 16.00 13.00
YCE24B22S TL8E060A12UH11 14.5 CF42B 875 24.0 19.2 16.00 13.00
YCE24B22S TL8E060A12UH11 14.5 XAF/XAUA24B 650 23.6 16.2 15.75 12.75
YCE24B22S TL8E060A12UH11 17.5 XAF/XAUB30C 700 24.0 17.2 16.00 13.00
YCE24B22S TL8E060A12UH11 17.5 XAFB24B 675 23.8 16.5 15.75 13.00
YCE24B22S TL8E060A12UH11 17.5 XAHB24B 675 23.8 16.5 15.75 13.00
YCE24B22S TL8E060A12UH11 17.5 XAHB30C 675 24.0 16.9 16.00 13.00
YCE24B22S TL8E080C16UH11 21.0 CF/CM24C 950 24.0 19.1 15.50 12.75
YCE24B22S TL8E080C16UH11 21.0 CF/CM30C 950 24.0 19.8 16.00 13.00
YCE24B22S TL8E080C16UH11 21.0 XAFC30C 950 24.0 19.9 16.00 13.00
YCE24B22S TL8E080C16UH11 21.0 XAHC30C 925 24.0 19.7 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 CF/CM/CU24B 650 24.0 17.3 15.75 13.00
YCE24B22S TL9E060B12UH11 17.5 CF/CM/CU30B 675 24.0 17.6 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 CF/CM/CU36B 650 24.0 17.3 16.00 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
