York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 21
YCE24B22S TL9E060B12UH11 17.5 CF/CM/CU36C 650 24.0 17.3 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 CF/CM24C 700 24.0 17.8 15.50 12.75
YCE24B22S TL9E060B12UH11 17.5 CF/CM30C 700 24.0 17.7 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 CF42B 675 24.0 17.5 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 XAF/XAUB30C 675 24.0 17.0 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 XAFB24B 675 23.8 16.5 15.75 12.75
YCE24B22S TL9E060B12UH11 21.0 XAFC30C 675 24.0 17.0 16.00 13.00
YCE24B22S TL9E060B12UH11 17.5 XAHB24B 675 23.8 16.5 15.75 12.75
YCE24B22S TL9E060B12UH11 17.5 XAHB30C 675 24.0 17.0 16.00 13.00
YCE24B22S TL9E060B12UH11 21.0 XAHC30C 675 24.0 17.0 16.00 13.00
YCE24B22S TL9E080C16UH11 21.0 CF/CM/CU36C 925 24.0 19.4 16.00 13.00
YCE24B22S TL9E080C16UH11 21.0 CF/CM/CU42C 925 24.0 19.6 16.00 13.00
YCE24B22S TL9E080C16UH11 21.0 CF/CM24C 900 24.0 18.8 15.50 12.75
YCE24B22S TL9E080C16UH11 21.0 CF/CM30C 925 24.0 19.5 16.00 13.00
YCE24B22S TL9E080C16UH11 21.0 CF/CM36D 925 24.0 19.4 16.00 13.00
YCE24B22S TL9E080C16UH11 21.0 CF/CM42D 925 24.0 19.6 16.00 13.00
YCE24B22S TL9E080C16UH11 21.0 XAFC30C 900 24.0 19.4 16.00 13.00
YCE24B22S TL9E080C16UH11 21.0 XAHC30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8E040A12MP11 14.5 CF/CM/CU24A 725 24.0 18.2 15.75 13.00
YCE24B22S TM8E040A12MP11 14.5 CF/CM/CU24B 775 24.0 18.5 16.00 13.00
YCE24B22S TM8E040A12MP11 14.5 CF/CM/CU30A 725 24.0 18.0 16.00 13.00
YCE24B22S TM8E040A12MP11 14.5 CF/CM/CU30B 775 24.0 18.3 16.00 13.00
YCE24B22S TM8E040A12MP11 14.5 CF/CM/CU36B 700 24.0 17.7 16.00 13.00
YCE24B22S TM8E040A12MP11 14.5 CF/CM36A 650 24.0 17.4 16.00 13.00
YCE24B22S TM8E040A12MP11 14.5 CF42B 775 24.0 18.4 16.00 13.00
YCE24B22S TM8E040A12MP11 14.5 XAF/XAUA24B 725 24.0 17.0 15.75 13.00
YCE24B22S TM8E040A12MP11 17.5 XAF/XAUB30C 775 24.0 18.1 16.00 13.00
YCE24B22S TM8E040A12MP11 17.5 XAFB24B 750 24.0 17.2 16.00 13.00
YCE24B22S TM8E040A12MP11 17.5 XAHB24B 750 24.0 17.2 16.00 13.00
YCE24B22S TM8E040A12MP11 17.5 XAHB30C 750 24.0 17.8 16.00 13.00
YCE24B22S TM8E060A12MP11 14.5 CF/CM/CU24A 725 24.0 18.2 15.75 13.00
YCE24B22S TM8E060A12MP11 14.5 CF/CM/CU24B 750 24.0 18.2 15.75 13.00
YCE24B22S TM8E060A12MP11 14.5 CF/CM/CU30A 725 24.0 18.0 16.00 13.00
YCE24B22S TM8E060A12MP11 14.5 CF/CM/CU30B 750 24.0 18.0 16.00 13.00
YCE24B22S TM8E060A12MP11 14.5 CF/CM/CU36B 825 24.0 18.6 16.00 13.00
YCE24B22S TM8E060A12MP11 14.5 CF/CM36A 725 24.0 18.2 16.00 13.00
YCE24B22S TM8E060A12MP11 14.5 CF42B 750 24.0 17.9 16.00 13.00
YCE24B22S TM8E060A12MP11 14.5 XAF/XAUA24B 725 24.0 17.0 15.75 13.00
YCE24B22S TM8E060A12MP11 17.5 XAF/XAUB30C 825 24.0 18.6 16.00 13.00
YCE24B22S TM8E060A12MP11 17.5 XAFB24B 750 24.0 17.2 15.75 13.00
YCE24B22S TM8E060A12MP11 17.5 XAHB24B 750 24.0 17.3 15.75 13.00
YCE24B22S TM8E060A12MP11 17.5 XAHB30C 750 24.0 17.8 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF/CM/CU24B 725 24.0 18.1 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF/CM/CU30B 725 24.0 18.0 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF/CM/CU36B 725 24.0 18.2 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF/CM/CU36C 750 24.0 18.3 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF/CM/CU42C 750 24.0 18.0 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF/CM24C 750 24.0 18.2 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF/CM30C 750 24.0 18.0 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 CF42B 725 24.0 17.7 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 XAF/XAUB30C 725 24.0 17.6 16.00 13.00
YCE24B22S TM8E080B12MP11 17.5 XAFB24B 725 24.0 17.1 16.00 13.00
YCE24B22S TM8E080B12MP11 21.0 XAFC30C 725 24.0 17.6 16.00 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
