York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 23
YCE24B22S TM8V060A12MP12C 14.5 CF/CM36A 725 24.0 18.2 16.00 13.00
YCE24B22S TM8V060A12MP12C 14.5 CF42B 800 24.0 18.5 16.00 13.00
YCE24B22S TM8V060A12MP12C 14.5 XAF/XAUA24B 725 24.0 17.0 15.75 12.75
YCE24B22S TM8V060A12MP12C 17.5 XAF/XAUB30C 700 24.0 17.2 16.00 13.00
YCE24B22S TM8V060A12MP12C 17.5 XAFB24B 700 23.8 16.8 15.75 13.00
YCE24B22S TM8V060A12MP12C 17.5 XAHB24B 800 24.0 17.8 15.75 12.75
YCE24B22S TM8V060A12MP12C 17.5 XAHB30C 800 24.0 18.3 16.00 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF/CM/CU24B 725 24.0 18.1 15.75 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF/CM/CU30B 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF/CM/CU36B 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF/CM/CU36C 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF/CM/CU42C 725 24.0 17.7 16.00 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF/CM24C 725 24.0 18.2 15.75 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF/CM30C 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP11C 17.5 CF42B 675 24.0 17.5 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF/CM/CU24B 725 24.0 18.1 15.75 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF/CM/CU30B 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF/CM/CU36B 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF/CM/CU36C 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF/CM/CU42C 725 24.0 17.7 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF/CM24C 725 24.0 18.2 15.75 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF/CM30C 675 24.0 17.6 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 CF42B 675 24.0 17.5 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 XAF/XAUB30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 XAFB24B 725 24.0 17.0 15.75 12.75
YCE24B22S TM8V080B12MP12C 21.0 XAFC30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM8V080B12MP12C 17.5 XAHB24B 675 23.8 16.5 15.75 12.75
YCE24B22S TM8V080B12MP12C 17.5 XAHB30C 675 24.0 17.0 15.75 13.00
YCE24B22S TM8V080B12MP12C 21.0 XAHC30C 675 24.0 17.0 15.75 13.00
YCE24B22S TM8V080C16MP11C 21.0 CF/CM/CU36C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V080C16MP11C 21.0 CF/CM/CU42C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V080C16MP11C 21.0 CF/CM24C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V080C16MP11C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V080C16MP11C 21.0 CF/CM36D 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V080C16MP11C 21.0 CF/CM42D 875 24.0 19.1 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 CF/CM/CU42C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 CF/CM24C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 CF/CM36D 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 CF/CM42D 875 24.0 19.1 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 XAFC30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V080C16MP12C 21.0 XAHC30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V100C16MP11C 21.0 CF/CM/CU36C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V100C16MP11C 21.0 CF/CM/CU42C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V100C16MP11C 21.0 CF/CM24C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V100C16MP11C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V100C16MP11C 21.0 CF/CM36D 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V100C16MP11C 21.0 CF/CM42D 875 24.0 19.1 16.00 13.00
YCE24B22S TM8V100C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V100C16MP12C 21.0 CF/CM/CU42C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V100C16MP12C 21.0 CF/CM24C 875 24.0 19.5 16.00 13.00
YCE24B22S TM8V100C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V100C16MP12C 21.0 CF/CM36D 875 24.0 19.5 16.00 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
