York LX series Technical Guide

5581700-YTG-F-1021
24 Johnson Controls Ducted Systems
YCE24B22S TM8V100C16MP12C 21.0 CF/CM42D 875 24.0 19.1 16.00 13.00
YCE24B22S TM8V100C16MP12C 21.0 XAFC30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8V100C16MP12C 21.0 XAHC30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM8X060A12MP11 14.5 CF/CM/CU24A 625 23.8 16.9 15.75 13.00
YCE24B22S TM8X060A12MP11 14.5 CF/CM/CU24B 650 24.0 17.3 15.75 13.00
YCE24B22S TM8X060A12MP11 14.5 CF/CM/CU30A 625 24.0 17.0 16.00 13.00
YCE24B22S TM8X060A12MP11 14.5 CF/CM/CU30B 650 24.0 17.2 16.00 13.00
YCE24B22S TM8X060A12MP11 14.5 CF/CM/CU36B 650 24.0 17.4 16.00 13.00
YCE24B22S TM8X060A12MP11 14.5 CF/CM36A 700 24.0 17.8 16.00 13.00
YCE24B22S TM8X060A12MP11 14.5 CF42B 800 24.0 18.5 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF/CM/CU24B 775 24.0 18.5 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF/CM/CU30B 775 24.0 18.3 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF/CM/CU36B 825 24.0 18.6 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF/CM/CU36C 850 24.0 18.8 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF/CM/CU42C 850 24.0 18.9 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF/CM24C 775 24.0 18.5 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF/CM30C 775 24.0 18.3 16.00 13.00
YCE24B22S TM8X080B12MP11 17.5 CF42B 675 24.0 17.5 16.00 13.00
YCE24B22S TM8X080C16MP11 21.0 CF/CM/CU36C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8X080C16MP11 21.0 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TM8X080C16MP11 21.0 CF/CM24C 700 24.0 17.8 16.00 13.00
YCE24B22S TM8X080C16MP11 21.0 CF/CM30C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8X080C16MP11 21.0 CF/CM36D 725 24.0 18.2 16.00 13.00
YCE24B22S TM8X080C16MP11 21.0 CF/CM42D 725 24.0 17.6 16.00 13.00
YCE24B22S TM8X100C16MP11 21.0 CF/CM/CU36C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8X100C16MP11 21.0 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TM8X100C16MP11 21.0 CF/CM24C 700 24.0 17.8 16.00 13.00
YCE24B22S TM8X100C16MP11 21.0 CF/CM30C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8X100C16MP11 21.0 CF/CM36D 725 24.0 18.2 16.00 13.00
YCE24B22S TM8X100C16MP11 21.0 CF/CM42D 725 24.0 17.6 16.00 13.00
YCE24B22S TM8Y060A12MP11 14.5 CF/CM/CU24A 625 23.8 16.9 15.75 13.00
YCE24B22S TM8Y060A12MP11 14.5 CF/CM/CU24B 650 24.0 17.3 15.75 13.00
YCE24B22S TM8Y060A12MP11 14.5 CF/CM/CU30A 625 24.0 17.0 16.00 13.00
YCE24B22S TM8Y060A12MP11 14.5 CF/CM/CU30B 650 24.0 17.2 16.00 13.00
YCE24B22S TM8Y060A12MP11 14.5 CF/CM/CU36B 650 24.0 17.4 16.00 13.00
YCE24B22S TM8Y060A12MP11 14.5 CF/CM36A 700 24.0 17.8 16.00 13.00
YCE24B22S TM8Y060A12MP11 14.5 CF42B 800 24.0 18.5 16.00 13.00
YCE24B22S TM8Y060A12MP11 14.5 XAF/XAUA24B 775 24.0 17.5 15.75 12.75
YCE24B22S TM8Y060A12MP11 17.5 XAF/XAUB30C 725 24.0 17.6 16.00 13.00
YCE24B22S TM8Y060A12MP11 17.5 XAFB24B 650 23.4 16.2 15.75 13.00
YCE24B22S TM8Y060A12MP11 17.5 XAHB24B 700 23.8 16.8 15.75 12.75
YCE24B22S TM8Y060A12MP11 17.5 XAHB30C 700 24.0 17.3 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF/CM/CU24B 775 24.0 18.5 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF/CM/CU30B 775 24.0 18.3 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF/CM/CU36B 825 24.0 18.6 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF/CM/CU36C 850 24.0 18.8 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF/CM/CU42C 850 24.0 18.9 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF/CM24C 775 24.0 18.5 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF/CM30C 775 24.0 18.3 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 CF42B 675 24.0 17.5 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 XAF/XAUB30C 775 24.0 18.1 16.00 13.00
YCE24B22S TM8Y080B12MP11 17.5 XAFB24B 825 24.0 18.1 15.75 13.00
YCE24B22S TM8Y080B12MP11 21.0 XAFC30C 775 24.0 18.1 16.00 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
