York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 25
YCE24B22S TM8Y080B12MP11 17.5 XAHB24B 825 24.0 18.1 15.75 13.00
YCE24B22S TM8Y080B12MP11 17.5 XAHB30C 825 24.0 18.7 16.00 13.00
YCE24B22S TM8Y080B12MP11 21.0 XAHC30C 825 24.0 18.7 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 CF/CM/CU36C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 CF/CM24C 700 24.0 17.8 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 CF/CM30C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 CF/CM36D 725 24.0 18.2 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 CF/CM42D 725 24.0 17.6 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 XAFC30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM8Y080C16MP11 21.0 XAHC30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 CF/CM/CU36C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 CF/CM24C 700 24.0 17.8 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 CF/CM30C 700 24.0 17.7 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 CF/CM36D 725 24.0 18.2 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 CF/CM42D 725 24.0 17.6 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 XAFC30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM8Y100C16MP11 21.0 XAHC30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM9E026A08MP12 14.5 CF/CM/CU24A 675 24.0 17.6 15.00 12.50
YCE24B22S TM9E026A08MP12 14.5 CF/CM/CU24B 600 23.4 16.5 15.25 12.50
YCE24B22S TM9E026A08MP12 14.5 CF/CM/CU30A 675 24.0 17.8 15.50 12.75
YCE24B22S TM9E026A08MP12 14.5 CF/CM/CU30B 700 24.0 18.1 15.50 12.75
YCE24B22S TM9E026A08MP12 14.5 CF/CM/CU36B 700 24.0 18.2 15.50 12.75
YCE24B22S TM9E026A08MP12 14.5 CF/CM36A 675 24.0 17.8 15.50 12.75
YCE24B22S TM9E026A08MP12 14.5 CF42B 600 24.0 16.9 15.75 13.00
YCE24B22S TM9E026A08MP12 14.5 XAF/XAUA24B 675 23.6 16.5 15.00 12.50
YCE24B22S TM9E026A08MP12 17.5 XAF/XAUB30C 700 24.0 17.2 15.50 12.75
YCE24B22S TM9E026A08MP12 17.5 XAFB24B 675 23.4 16.5 15.25 12.50
YCE24B22S TM9E026A08MP12 17.5 XAHB24B 675 23.4 16.5 15.25 12.50
YCE24B22S TM9E026A08MP12 17.5 XAHB30C 675 24.0 16.9 15.50 12.75
YCE24B22S TM9E040A10MP11 14.5 CF/CM/CU24A 675 23.8 17.4 14.75 12.50
YCE24B22S TM9E040A10MP11 14.5 CF/CM/CU24B 700 24.0 17.8 15.00 12.50
YCE24B22S TM9E040A10MP11 14.5 CF/CM/CU30A 675 24.0 17.5 15.00 12.50
YCE24B22S TM9E040A10MP11 14.5 CF/CM/CU30B 700 24.0 17.8 15.50 12.75
YCE24B22S TM9E040A10MP11 14.5 CF/CM/CU36B 700 24.0 17.7 15.50 12.75
YCE24B22S TM9E040A10MP11 14.5 CF/CM36A 675 24.0 17.5 15.00 12.50
YCE24B22S TM9E040A10MP11 14.5 CF42B 675 24.0 17.5 15.25 12.75
YCE24B22S TM9E040A10MP12 14.5 CF/CM/CU24A 600 23.4 16.5 15.25 12.50
YCE24B22S TM9E040A10MP12 14.5 CF/CM/CU24B 625 23.6 16.8 15.25 12.50
YCE24B22S TM9E040A10MP12 14.5 CF/CM/CU30A 600 24.0 16.8 15.50 12.75
YCE24B22S TM9E040A10MP12 14.5 CF/CM/CU30B 625 24.0 17.0 15.50 12.75
YCE24B22S TM9E040A10MP12 14.5 CF/CM/CU36B 675 24.0 17.6 15.50 13.00
YCE24B22S TM9E040A10MP12 14.5 CF/CM36A 675 24.0 17.6 15.50 12.75
YCE24B22S TM9E040A10MP12 14.5 CF42B 625 24.0 17.1 15.75 13.00
YCE24B22S TM9E040A10MP12 14.5 XAF/XAUA24B 600 23.2 15.7 15.25 12.50
YCE24B22S TM9E040A10MP12 17.5 XAF/XAUB30C 625 23.8 16.3 15.50 12.75
YCE24B22S TM9E040A10MP12 17.5 XAFB24B 675 23.4 16.4 15.25 12.50
YCE24B22S TM9E040A10MP12 17.5 XAHB24B 675 23.4 16.4 15.25 12.50
YCE24B22S TM9E040A10MP12 17.5 XAHB30C 625 23.8 16.4 15.50 12.75
YCE24B22S TM9E060A10MP12 14.5 CF/CM/CU24A 675 24.0 17.5 15.50 12.75
YCE24B22S TM9E060A10MP12 14.5 CF/CM/CU24B 700 24.0 17.8 15.50 12.75
YCE24B22S TM9E060A10MP12 14.5 CF/CM/CU30A 675 24.0 17.5 15.75 13.00
YCE24B22S TM9E060A10MP12 14.5 CF/CM/CU30B 700 24.0 17.7 15.75 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
