York LX series Technical Guide

5581700-YTG-F-1021
26 Johnson Controls Ducted Systems
YCE24B22S TM9E060A10MP12 14.5 CF/CM/CU36B 700 24.0 17.8 15.75 13.00
YCE24B22S TM9E060A10MP12 14.5 CF/CM36A 675 24.0 17.6 15.75 13.00
YCE24B22S TM9E060A10MP12 14.5 CF42B 700 24.0 17.6 16.00 13.00
YCE24B22S TM9E060A10MP12 14.5 XAF/XAUA24B 675 23.8 16.5 15.50 12.75
YCE24B22S TM9E060A10MP12 17.5 XAF/XAUB30C 700 24.0 17.3 15.75 13.00
YCE24B22S TM9E060A10MP12 17.5 XAFB24B 700 23.8 16.8 15.50 12.75
YCE24B22S TM9E060A10MP12 17.5 XAHB24B 675 23.8 16.5 15.50 12.75
YCE24B22S TM9E060A10MP12 17.5 XAHB30C 675 24.0 17.0 15.75 13.00
YCE24B22S TM9E060B12MP11 17.5 CF/CM/CU24B 675 24.0 17.5 15.75 13.00
YCE24B22S TM9E060B12MP11 17.5 CF/CM/CU30B 675 24.0 17.6 16.00 13.00
YCE24B22S TM9E060B12MP11 17.5 CF/CM/CU36B 675 24.0 17.6 16.00 13.00
YCE24B22S TM9E060B12MP11 17.5 CF/CM/CU36C 700 24.0 17.7 16.00 13.00
YCE24B22S TM9E060B12MP11 17.5 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TM9E060B12MP11 17.5 CF/CM24C 675 24.0 17.5 15.75 13.00
YCE24B22S TM9E060B12MP11 17.5 CF/CM30C 675 24.0 17.6 16.00 13.00
YCE24B22S TM9E060B12MP11 17.5 CF42B 675 24.0 17.5 16.00 13.00
YCE24B22S TM9E060B12MP12 17.5 CF/CM/CU24B 750 24.0 18.3 15.75 13.00
YCE24B22S TM9E060B12MP12 17.5 CF/CM/CU30B 750 24.0 18.0 16.00 13.00
YCE24B22S TM9E060B12MP12 17.5 CF/CM/CU36B 750 24.0 18.3 16.00 13.00
YCE24B22S TM9E060B12MP12 17.5 CF/CM/CU36C 750 24.0 18.3 16.00 13.00
YCE24B22S TM9E060B12MP12 17.5 CF/CM/CU42C 750 24.0 17.9 16.00 13.00
YCE24B22S TM9E060B12MP12 17.5 CF/CM24C 750 24.0 18.3 15.50 13.00
YCE24B22S TM9E060B12MP12 17.5 CF/CM30C 750 24.0 18.0 15.75 13.00
YCE24B22S TM9E060B12MP12 17.5 CF42B 725 24.0 17.7 16.00 13.00
YCE24B22S TM9E060B12MP12 17.5 XAF/XAUB30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM9E060B12MP12 17.5 XAFB24B 725 24.0 17.0 15.75 12.75
YCE24B22S TM9E060B12MP12 21.0 XAFC30C 725 24.0 17.5 15.75 13.00
YCE24B22S TM9E060B12MP12 17.5 XAHB24B 725 24.0 17.0 15.75 12.75
YCE24B22S TM9E060B12MP12 17.5 XAHB30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM9E060B12MP12 21.0 XAHC30C 725 24.0 17.5 15.75 13.00
YCE24B22S TM9E080B12MP11 17.5 CF/CM/CU24B 700 24.0 17.8 16.00 13.00
YCE24B22S TM9E080B12MP11 17.5 CF/CM/CU30B 700 24.0 17.7 16.00 13.00
YCE24B22S TM9E080B12MP11 17.5 CF/CM/CU36B 700 24.0 17.7 16.00 13.00
YCE24B22S TM9E080B12MP11 17.5 CF/CM/CU36C 700 24.0 17.7 16.00 13.00
YCE24B22S TM9E080B12MP11 17.5 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TM9E080B12MP11 17.5 CF/CM24C 700 24.0 17.8 16.00 13.00
YCE24B22S TM9E080B12MP11 17.5 CF/CM30C 700 24.0 17.7 16.00 13.00
YCE24B22S TM9E080B12MP11 17.5 CF42B 675 24.0 17.5 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 CF/CM/CU24B 800 24.0 18.7 15.75 13.00
YCE24B22S TM9E080B12MP12 17.5 CF/CM/CU30B 800 24.0 18.8 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 CF/CM/CU36B 800 24.0 18.8 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 CF/CM/CU36C 825 24.0 18.6 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 CF/CM/CU42C 825 24.0 18.6 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 CF/CM24C 800 24.0 18.7 15.75 13.00
YCE24B22S TM9E080B12MP12 17.5 CF/CM30C 825 24.0 18.5 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 CF42B 775 24.0 18.4 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 XAF/XAUB30C 800 24.0 18.3 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 XAFB24B 775 24.0 17.6 15.75 13.00
YCE24B22S TM9E080B12MP12 21.0 XAFC30C 800 24.0 18.3 16.00 13.00
YCE24B22S TM9E080B12MP12 17.5 XAHB24B 775 24.0 17.5 15.75 13.00
YCE24B22S TM9E080B12MP12 17.5 XAHB30C 775 24.0 18.1 16.00 13.00
YCE24B22S TM9E080B12MP12 21.0 XAHC30C 775 24.0 18.1 16.00 13.00
YCE24B22S TM9E080C16MP11 21.0 CF/CM/CU36C 600 24.0 17.1 16.00 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
