York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 27
YCE24B22S TM9E080C16MP11 21.0 CF/CM/CU42C 600 24.0 16.8 16.00 13.00
YCE24B22S TM9E080C16MP11 21.0 CF/CM24C 600 23.6 16.6 15.75 13.00
YCE24B22S TM9E080C16MP11 21.0 CF/CM30C 600 24.0 16.8 16.00 13.00
YCE24B22S TM9E080C16MP11 21.0 CF/CM36D 600 24.0 17.1 16.00 13.00
YCE24B22S TM9E080C16MP11 21.0 CF/CM42D 600 24.0 16.8 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 CF/CM/CU36C 750 24.0 18.3 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 CF/CM/CU42C 750 24.0 18.0 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 CF/CM24C 750 24.0 18.2 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 CF/CM30C 750 24.0 18.0 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 CF/CM36D 925 24.0 19.4 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 CF/CM42D 925 24.0 19.6 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 XAFC30C 725 24.0 17.5 16.00 13.00
YCE24B22S TM9E080C16MP12 21.0 XAHC30C 875 24.0 19.2 16.00 13.00
YCE24B22S TM9E100C16MP11 21.0 CF/CM/CU36C 650 24.0 17.3 16.00 13.00
YCE24B22S TM9E100C16MP11 21.0 CF/CM/CU42C 650 24.0 17.2 16.00 13.00
YCE24B22S TM9E100C16MP11 21.0 CF/CM24C 625 23.8 16.9 16.00 13.00
YCE24B22S TM9E100C16MP11 21.0 CF/CM30C 625 24.0 17.0 16.00 13.00
YCE24B22S TM9E100C16MP11 21.0 CF/CM36D 650 24.0 17.3 16.00 13.00
YCE24B22S TM9E100C16MP11 21.0 CF/CM42D 650 24.0 17.2 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 CF/CM/CU36C 800 24.0 18.7 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 CF/CM/CU42C 800 24.0 18.6 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 CF/CM24C 775 24.0 18.5 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 CF/CM30C 800 24.0 18.7 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 CF/CM36D 800 24.0 18.7 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 CF/CM42D 800 24.0 18.6 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 XAFC30C 750 24.0 17.7 16.00 13.00
YCE24B22S TM9E100C16MP12 21.0 XAHC30C 750 24.0 17.7 16.00 13.00
YCE24B22S TM9V040A10MP12C 14.5 CF/CM/CU24A 625 23.6 16.7 15.25 12.50
YCE24B22S TM9V040A10MP12C 14.5 CF/CM/CU24B 625 23.6 16.8 15.25 12.75
YCE24B22S TM9V040A10MP12C 14.5 CF/CM/CU30A 900 24.0 19.4 14.00 12.00
YCE24B22S TM9V040A10MP12C 14.5 CF/CM/CU30B 625 24.0 17.0 15.50 13.00
YCE24B22S TM9V040A10MP12C 14.5 CF/CM/CU36B 650 24.0 17.3 15.75 13.00
YCE24B22S TM9V040A10MP12C 14.5 CF/CM36A 650 24.0 17.3 15.50 13.00
YCE24B22S TM9V040A10MP12C 14.5 CF42B 650 24.0 17.1 15.75 13.00
YCE24B22S TM9V040A10MP12C 14.5 XAF/XAUA24B 650 23.4 16.2 15.25 12.50
YCE24B22S TM9V040A10MP12C 17.5 XAF/XAUB30C 725 24.0 17.5 15.50 12.75
YCE24B22S TM9V040A10MP12C 17.5 XAFB24B 650 23.4 16.3 15.25 12.75
YCE24B22S TM9V040A10MP12C 17.5 XAHB24B 650 23.4 16.3 15.25 12.75
YCE24B22S TM9V040A10MP12C 17.5 XAHB30C 650 24.0 16.7 15.50 12.75
YCE24B22S TM9V060B12MP12C 17.5 CF/CM/CU24B 700 24.0 17.8 15.75 13.00
YCE24B22S TM9V060B12MP12C 17.5 CF/CM/CU30B 700 24.0 17.7 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 CF/CM/CU36B 650 24.0 17.3 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 CF/CM/CU36C 650 24.0 17.3 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 CF/CM/CU42C 700 24.0 17.6 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 CF/CM24C 700 24.0 17.8 15.75 13.00
YCE24B22S TM9V060B12MP12C 17.5 CF/CM30C 700 24.0 17.7 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 CF42B 700 24.0 17.6 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 XAF/XAUB30C 775 24.0 18.0 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 XAFB24B 700 23.8 16.7 15.75 12.75
YCE24B22S TM9V060B12MP12C 21.0 XAFC30C 775 24.0 18.0 16.00 13.00
YCE24B22S TM9V060B12MP12C 17.5 XAHB24B 700 23.8 16.7 15.75 12.75
YCE24B22S TM9V060B12MP12C 17.5 XAHB30C 700 24.0 17.3 15.75 13.00
YCE24B22S TM9V060B12MP12C 21.0 XAHC30C 775 24.0 18.0 15.75 13.00
YCE24B22S TM9V080B12MP11C 17.5 CF/CM/CU24B 725 24.0 18.2 16.00 13.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
