York LX series Technical Guide

5581700-YTG-F-1021
28 Johnson Controls Ducted Systems
YCE24B22S TM9V080B12MP11C 17.5 CF/CM/CU30B 800 24.0 18.8 16.00 13.00
YCE24B22S TM9V080B12MP11C 17.5 CF/CM/CU36B 675 24.0 17.6 16.00 13.00
YCE24B22S TM9V080B12MP11C 17.5 CF/CM/CU36C 850 24.0 18.8 16.00 13.00
YCE24B22S TM9V080B12MP11C 17.5 CF/CM/CU42C 850 24.0 18.9 16.00 13.00
YCE24B22S TM9V080B12MP11C 17.5 CF/CM24C 725 24.0 18.1 16.00 13.00
YCE24B22S TM9V080B12MP11C 17.5 CF/CM30C 775 24.0 18.3 16.00 13.00
YCE24B22S TM9V080B12MP11C 17.5 CF42B 800 24.0 18.5 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF/CM/CU24B 725 24.0 18.2 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF/CM/CU30B 800 24.0 18.8 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF/CM/CU36B 675 24.0 17.6 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF/CM/CU36C 850 24.0 18.8 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF/CM/CU42C 850 24.0 18.9 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF/CM24C 725 24.0 18.1 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF/CM30C 775 24.0 18.3 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 CF42B 800 24.0 18.5 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 XAF/XAUB30C 800 24.0 18.3 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 XAFB24B 750 24.0 17.3 15.75 13.00
YCE24B22S TM9V080B12MP12C 21.0 XAFC30C 800 24.0 18.3 16.00 13.00
YCE24B22S TM9V080B12MP12C 17.5 XAHB24B 750 24.0 17.3 15.75 13.00
YCE24B22S TM9V080B12MP12C 17.5 XAHB30C 750 24.0 17.8 16.00 13.00
YCE24B22S TM9V080B12MP12C 21.0 XAHC30C 750 24.0 17.8 16.00 13.00
YCE24B22S TM9V080C16MP11C 21.0 CF/CM/CU36C 950 24.0 20.0 16.00 13.00
YCE24B22S TM9V080C16MP11C 21.0 CF/CM/CU42C 950 24.0 19.5 16.00 13.00
YCE24B22S TM9V080C16MP11C 21.0 CF/CM24C 950 24.0 19.1 15.25 12.50
YCE24B22S TM9V080C16MP11C 21.0 CF/CM30C 950 24.0 19.8 16.00 13.00
YCE24B22S TM9V080C16MP11C 21.0 CF/CM36D 950 24.0 20.0 16.00 13.00
YCE24B22S TM9V080C16MP11C 21.0 CF/CM42D 950 24.0 19.5 16.00 13.00
YCE24B22S TM9V080C16MP12C 21.0 CF/CM/CU36C 950 24.0 20.0 16.00 13.00
YCE24B22S TM9V080C16MP12C 21.0 CF/CM/CU42C 950 24.0 19.5 16.00 13.00
YCE24B22S TM9V080C16MP12C 21.0 CF/CM24C 950 24.0 19.1 15.25 12.50
YCE24B22S TM9V080C16MP12C 21.0 CF/CM30C 950 24.0 19.8 16.00 13.00
YCE24B22S TM9V080C16MP12C 21.0 CF/CM36D 950 24.0 20.0 16.00 13.00
YCE24B22S TM9V080C16MP12C 21.0 CF/CM42D 950 24.0 19.5 16.00 13.00
YCE24B22S TM9V080C16MP12C 21.0 XAFC30C 950 24.0 20.0 16.00 13.00
YCE24B22S TM9V080C16MP12C 21.0 XAHC30C 950 24.0 20.0 16.00 13.00
YCE24B22S TM9V100C16MP11C 21.0 CF/CM/CU36C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP11C 21.0 CF/CM/CU42C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP11C 21.0 CF/CM24C 900 24.0 18.8 15.75 13.00
YCE24B22S TM9V100C16MP11C 21.0 CF/CM30C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP11C 21.0 CF/CM36D 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP11C 21.0 CF/CM42D 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP12C 21.0 CF/CM/CU36C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP12C 21.0 CF/CM/CU42C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP12C 21.0 CF/CM24C 900 24.0 18.8 15.75 13.00
YCE24B22S TM9V100C16MP12C 21.0 CF/CM30C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP12C 21.0 CF/CM36D 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP12C 21.0 CF/CM42D 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP12C 21.0 XAFC30C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9V100C16MP12C 21.0 XAHC30C 900 24.0 19.4 16.00 13.00
YCE24B22S TM9Y040A10MP11 14.5 CF/CM/CU24A 675 23.8 17.4 14.75 12.50
YCE24B22S TM9Y040A10MP11 14.5 CF/CM/CU24B 700 24.0 17.8 15.00 12.50
YCE24B22S TM9Y040A10MP11 14.5 CF/CM/CU30A 675 24.0 17.5 15.00 12.50
YCE24B22S TM9Y040A10MP11 14.5 CF/CM/CU30B 700 24.0 17.8 15.50 12.75
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
