York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 7
YCE24B22S MVC08BN21 17.5 CF/CM30B 800 24.0 18.7 16.00 13.00
YCE24B22S MVC08BN21 17.5 CF/CM36B 800 24.0 18.7 16.00 13.00
YCE24B22S MVC08BN21 17.5 CF42B 725 24.0 17.7 16.00 13.00
YCE24B22S MVC12BN21 17.5 CF/CM24B 775 24.0 18.6 16.00 13.00
YCE24B22S MVC12BN21 17.5 CF/CM30B 875 24.0 19.2 16.00 13.00
YCE24B22S MVC12BN21 17.5 CF/CM36B 875 24.0 19.5 16.00 13.00
YCE24B22S MVC12BN21 17.5 CF42B 875 24.0 19.1 16.00 13.00
YCE24B22S MVC12CN21 21.0 CF/CM24C 875 24.0 19.5 16.00 13.00
YCE24B22S MVC12CN21 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
YCE24B22S MVC12CN21 21.0 CF/CM36C 875 24.0 19.5 16.00 13.00
YCE24B22S MVC12CN21 21.0 CF/CM42C 875 24.0 19.1 16.00 13.00
YCE24B22S MVC14DN21 24.5 CF/CM36D 875 24.0 19.5 16.00 13.00
YCE24B22S MVC14DN21 24.5 CF/CM42D 875 24.0 19.1 16.00 13.00
YCE30B22S AE30BX21 17.5 — 875 30.0 22.2 15.25 13.00
YCE30B22S AE36BX21 17.5 — 825 30.0 21.6 15.50 13.25
YCE30B22S AE36CX21 21.0 — 975 30.0 23.2 15.75 13.25
YCE30B22S AP30BX21 17.5 — 825 29.8 21.6 14.25 12.00
YCE30B22S AP36CX21 21.0 — 1125 30.0 24.4 14.00 12.00
YCE30B22S AVC30BX21 17.5 — 825 29.8 21.6 15.25 13.00
YCE30B22S AVC36BX21 17.5 — 850 30.0 21.8 15.50 13.25
YCE30B22S AVC36CX21 21.0 — 900 30.0 22.4 15.75 13.25
YCE30B22S ME08BN21 17.5 CF/CM30B 900 30.0 22.6 15.25 13.25
YCE30B22S ME08BN21 17.5 CF/CM36B 900 30.0 22.4 15.50 13.25
YCE30B22S ME08BN21 17.5 CF42B 875 30.0 22.2 15.50 13.25
YCE30B22S ME12BN21 17.5 CF/CM30B 850 30.0 22.0 15.50 13.25
YCE30B22S ME12BN21 17.5 CF/CM36B 850 30.0 21.8 15.50 13.25
YCE30B22S ME12BN21 17.5 CF42B 850 30.0 22.2 15.50 13.25
YCE30B22S ME12CN21 21.0 CF/CM30C 1000 30.0 23.6 15.50 13.25
YCE30B22S ME12CN21 21.0 CF/CM36C 825 30.0 21.6 15.75 13.25
YCE30B22S ME12CN21 21.0 CF/CM42C 1000 30.0 23.4 15.75 13.25
YCE30B22S ME14DN21 24.5 CF/CM36D 1025 30.0 23.6 16.00 13.25
YCE30B22S ME14DN21 24.5 CF/CM42D 1025 30.0 23.6 16.00 13.25
YCE30B22S ME16CN21 21.0 CF/CM30C 900 30.0 22.6 15.50 13.25
YCE30B22S ME16CN21 21.0 CF/CM36C 900 30.0 22.4 15.75 13.25
YCE30B22S ME16CN21 21.0 CF/CM42C 900 30.0 22.4 15.75 13.25
YCE30B22S MVC08BN21 17.5 CF/CM30B 825 29.8 21.6 15.25 13.00
YCE30B22S MVC08BN21 17.5 CF/CM36B 825 30.0 21.6 15.50 13.25
YCE30B22S MVC08BN21 17.5 CF42B 850 30.0 22.2 15.50 13.25
YCE30B22S MVC12BN21 17.5 CF/CM30B 875 30.0 22.4 15.25 13.25
YCE30B22S MVC12BN21 17.5 CF/CM36B 875 30.0 22.2 15.50 13.25
YCE30B22S MVC12BN21 17.5 CF42B 875 30.0 22.2 15.50 13.25
YCE30B22S MVC12CN21 21.0 CF/CM30C 1000 30.0 23.6 15.75 13.25
YCE30B22S MVC12CN21 21.0 CF/CM36C 1050 30.0 24.0 15.75 13.25
YCE30B22S MVC12CN21 21.0 CF/CM42C 975 30.0 23.2 16.00 13.25
YCE30B22S MVC14DN21 24.5 CF/CM36D 1050 30.0 24.0 16.00 13.25
YCE30B22S MVC14DN21 24.5 CF/CM42D 1000 30.0 23.4 16.00 13.25
YCE30B22S MVC16CN21 21.0 CF/CM30C 1125 30.0 24.6 15.50 13.25
YCE30B22S MVC16CN21 21.0 CF/CM36C 925 30.0 22.6 15.75 13.25
YCE30B22S MVC16CN21 21.0 CF/CM42C 1125 30.0 24.4 16.00 13.25
YCE36B22S AE36BX21 17.5 — 975 34.8 25.6 15.00 12.50
YCE36B22S AE36CX21 21.0 — 975 35.0 25.6 15.50 12.75
YCE36B22S AE42CX21 21.0 — 1150 36.0 28.2 15.25 12.75
YCE36B22S AE48CX21 21.0 — 1050 35.6 26.8 15.75 13.00
SYSTEM CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
