York LX series Technical Guide

5581700-YTG-F-1021
8 Johnson Controls Ducted Systems
YCE36B22S AE48DX21 24.5 — 1050 35.8 27.0 16.00 13.00
YCE36B22S AP36BX21 17.5 — 1150 35.2 27.4 14.00 12.00
YCE36B22S AP36CX21 21.0 — 1125 35.4 27.2 14.00 12.00
YCE36B22S AP37CX21 21.0 — 1125 35.4 27.2 14.00 12.00
YCE36B22S AP48CX21 21.0 — 1300 36.0 29.8 14.00 12.00
YCE36B22S AVC36BX21 17.5 — 1000 34.8 25.8 15.00 12.50
YCE36B22S AVC36CX21 21.0 — 1025 35.2 26.0 15.50 12.75
YCE36B22S AVC42CX21 21.0 — 1050 35.6 26.8 15.50 13.00
YCE36B22S AVC48CX21 21.0 — 1025 35.6 26.4 15.50 13.00
YCE36B22S AVC48DX21 24.5 — 1050 35.6 26.8 15.75 13.00
YCE36B22S ME12BN21 17.5 CF/CM36B 1050 35.2 26.6 15.25 12.75
YCE36B22S ME12BN21 17.5 CF42B 1050 35.6 26.6 15.25 12.75
YCE36B22S ME12CN21 21.0 CF/CM36C 1000 35.0 26.0 15.50 12.75
YCE36B22S ME12CN21 21.0 CF/CM42C 1000 35.4 26.0 15.50 13.00
YCE36B22S ME12CN21 21.0 CF/CM48C 1000 35.4 26.0 15.50 13.00
YCE36B22S ME14DN21 24.5 CF/CM36D 1025 35.4 26.2 15.50 13.00
YCE36B22S ME14DN21 24.5 CF/CM42D 1025 35.6 26.4 15.75 13.00
YCE36B22S ME14DN21 24.5 CF/CM48D 1025 35.6 26.4 15.75 13.00
YCE36B22S ME16CN21 21.0 CF/CM36C 1100 35.4 27.2 15.50 12.75
YCE36B22S ME16CN21 21.0 CF/CM42C 1100 35.8 27.4 15.50 13.00
YCE36B22S ME16CN21 21.0 CF/CM48C 1100 36.0 27.4 15.50 13.00
YCE36B22S ME20DN21 24.5 CF/CM36D 1275 36.0 29.6 15.75 13.00
YCE36B22S ME20DN21 24.5 CF/CM42D 1275 36.0 28.8 15.75 13.00
YCE36B22S ME20DN21 24.5 CF/CM48D 1275 36.0 29.4 15.75 13.00
YCE36B22S MVC08BN21 17.5 CF/CM36B 1000 34.8 25.8 15.00 12.50
YCE36B22S MVC08BN21 17.5 CF42B 1000 35.2 25.8 15.00 12.50
YCE36B22S MVC12BN21 17.5 CF/CM36B 975 34.8 25.6 15.25 12.75
YCE36B22S MVC12BN21 17.5 CF42B 975 34.8 25.6 15.25 12.75
YCE36B22S MVC12CN21 21.0 CF/CM36C 1000 35.0 26.0 15.50 13.00
YCE36B22S MVC12CN21 21.0 CF/CM42C 1050 35.6 26.4 15.75 13.00
YCE36B22S MVC12CN21 21.0 CF/CM48C 1050 35.6 26.8 15.75 13.00
YCE36B22S MVC14DN21 24.5 CF/CM36D 1100 35.6 27.4 15.75 13.00
YCE36B22S MVC14DN21 24.5 CF/CM42D 1250 36.0 28.8 15.75 13.00
YCE36B22S MVC14DN21 24.5 CF/CM48D 1100 36.0 27.4 16.00 13.00
YCE36B22S MVC16CN21 21.0 CF/CM36C 1125 35.6 27.6 15.50 13.00
YCE36B22S MVC16CN21 21.0 CF/CM42C 1150 36.0 28.0 15.75 13.00
YCE36B22S MVC16CN21 21.0 CF/CM48C 1125 36.0 28.0 15.75 13.00
YCE36B22S MVC20DN21 24.5 CF/CM36D 1175 36.0 28.4 15.75 13.00
YCE36B22S MVC20DN21 24.5 CF/CM42D 1275 36.0 28.8 16.00 13.00
YCE36B22S MVC20DN21 24.5 CF/CM48D 1175 36.0 28.2 16.00 13.00
YCE42B22S AE42CX21 21.0 — 1350 41.5 32.4 15.00 12.50
YCE42B22S AE48CX21 21.0 — 1200 41.5 31.0 15.50 12.75
YCE42B22S AE48DX21 24.5 — 1250 42.0 31.6 15.75 12.75
YCE42B22S AE60CX21 21.0 — 1200 42.0 31.2 15.25 12.75
YCE42B22S AE60CX22 21.0 — 1200 41.5 30.4 15.25 12.75
YCE42B22S AP42CX21 21.0 — 1275 40.5 31.1 14.00 11.50
YCE42B22S AP48CX21 21.0 — 1300 41.5 32.0 14.00 12.00
YCE42B22S AP48DX21 24.5 — 1475 41.5 33.6 14.25 12.00
YCE42B22S AVC42CX21 21.0 — 1250 41.5 31.2 15.00 12.50
YCE42B22S AVC48CX21 21.0 — 1200 41.5 31.0 15.25 12.75
YCE42B22S AVC48DX21 24.5 — 1225 42.0 31.6 15.50 12.75
YCE42B22S AVC60DX21 24.5 — 1200 42.0 31.0 15.75 12.75
YCE42B22S ME12BN21 17.5 CF42B 1225 41.0 30.6 14.75 12.50
SYSTEM CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
