York PREDATOR 102 - FIELD INSTALLED HORIZONTAL ECONOMIZER W;POWER EXHAUST; Illustration of Horizontal Economizer Installation; SLAB ECONOMIZER DOWNFLOW W;POWER EXHAUST; Illustration of Slab Economizer Installation

246646-YTG-C-0606
Unitary Products Group 41
FIGURE 13 - FIELD INSTALLED HORIZONTAL ECONOMIZER W/POWER EXHAUST
FIGURE 14 - SLAB ECONOMIZER DOWNFLOW W/POWER EXHAUST
1EH0408
Barometric
Relief Hood
1EH0408
Barometric
Relief Damper
2PE047032XX
Power Exhaust
2EE04705524
Fresh Air Hood
2EE04705524
Fresh Air Damper
2EE04705524
Return Air Damper
Field Installed
Duct Work
2EE04705X24
Slab Economizer
2PE047032XX
Power Exhaust
1EH0409 Barometric
Relief Damper
1EH0409 Barometric
Relief Hood
1EH0409
Fresh Air Hood
