York PREDATOR DM090 User Manual

035-17311-000 REV A (1200))
Unitary Products Group 5
D M 120 C 00 A 3 A AA 1 A
TABLE 1: PRODUCT NOMENCLATURE
Model #
Model Number
Description
Options
D
Product Category
D = Air Conditioner, Single Package
M
Product Identifier
M = Standard Efficiency
120
Nominal Cooling Capacity
MBH
090 = 7-1/2 Ton 120= 10 Ton 150 = 12-1/2 Ton
C
Heat Type
C = Cooling Only
00
Nominal Heating
Capacity
00 = No Heat Installed
A
Airflow
A = SM
B = SM/EC/BR
C = SM/EC/PE
D = SM/MD
N = High Static Motor
P = High Static Motor/EC/BR
Q = High Static Motor/EC/PE
R = High Static Motor/MD
3
Voltage
3= 380-3-60
A
Installation Options
A= None
B = 1
C = 2
D = 1 & 2E = 3
F = 4
G = 1 & 3
H = 1 & 4
J = 1, 2 & 3
K = 1, 2 & 4
L = 1, 3 & 4
M = 1, 2, 3 & 4
N = 2 & 3
P = 2 & 4
Q = 2, 3 & 4
R = 3 & 4
AA
Additional Options
AA = None
AB = PM
AC = CG
AD = DFS
AE = PM & CG
AF = PM & DFS
AG = CG & DFS
AH = PM, CG & DFS
TA = TCC
TB = TCC & PM
TC = TCC & CG
TD = TCC & DFS
TE = TCC, PM & CG
TF = TCC, PM & DFS
TG = TCC, CG & DFS
TH = TCC, PM, CG & DFS
1
Product Generation
1 = First Generation
A
Product Style
A = Style A
TABLE 2: AIRFLOW ABBREVIATIONS
ABBREVIATION MEANING
BR
Barometric Relief
EC
Economizer
MD
Motorized Damper
PE
Power Exhaust
SM
Standard Motor
TABLE 3: INSTALLATION ABBREVIATIONS
ABBREVIATION MEANING
1
Disconnect
2
Convenience Outlet
3
Smoke Detector Supply Air
4
Smoke Detector Return Air
TABLE 4: ADDITIONAL OPTIONS ABBREVIATIONS
ABBREVIATION MEANING
CG
Coil Guard
DFS
Dirty Filter Switch
PM
Phase Monitor
TCC
Technicoat Condenser Coil

York PREDATOR DM090 Specifications

General

Brand	York
Model	PREDATOR DM090
Category	Air Conditioner
Language	English
