York PS8 - Filter Performance - Pressure Drop Inches W.C; Applying Filter Pressure Drop to Determine System Airflow; Unit Clearances to Combustibles

036-21610-001 Rev. A (0804)
Unitary Products Group 5
* Washable Fiber are the type supplied with furnace (if supplied).
APPLYING FILTER PRESSURE DROP TO
DETERMINE SYSTEM AIRFLOW
To determine the approximate airflow of the unit with a filter in
place, follow the steps below:
1. Select the filter type.
2. Select the number of return air openings or calculate the
return opening size in square inches to determine the
proper filter pressure drop.
3. Determine the External System Static Pressure (ESP)
without the filter.
4. Select a filter pressure drop from the table based upon
the number of return air openings or return air opening
size and add to the ESP from Step 3 to determine the
total system static.
5. If total system static matches a ESP value in the airflow
table (i.e. 0.20, 0.60, etc,) the system airflow corre-
sponds to the intersection of the ESP column and Model/
Blower Speed row.
6. If the total system static falls between ESP values in the
table (i.e. 0.58, 0.75, etc.), the static pressure may be
rounded to the nearest value in the table determining the
airflow using Step 5 or calculate the airflow by using the
following example.
Example: For a 130,000 Btuh furnace with 2 return openings
and operating on high speed blower, it is found that total sys-
tem static is 0.58" w.c. To determine the system airflow, com-
plete the following steps:
1. Obtain the airflow values at 0.50" & 0.60" ESP.
Airflow @ 0.50": 2120 CFM
Airflow @ 0.60": 2040 CFM
2. Subtract the airflow @ 0.50" from the airflow @ 0.60" to
obtain airflow difference.
2040 - 2120 = -80 CFM
3. Subtract the total system static from 0.50" and divide this
difference by the difference in ESP values in the table,
0.60" - 0.50", to obtain a percentage.
(0.58 - 0.50) / (0.60 - 0.50) = 0.8
4. Multiply percentage by airflow difference to obtain airflow
reduction.
(0.8)x(-80) = -64
5. Subract airflow reduction value to airflow @ 0.50" to
obtain actual airflow @ 0.58" ESP.
2120 - 64 = 2056
FILTER PERFORMANCE - PRESSURE DROP INCHES W.C.
Airflow
Range
Minimum Opening Size
Filter Type
Disposable WASHABLE FIBER* Pleated
1 Opening 2 Openings 1 Opening 2 Openings 1 Opening 2 Openings 1 Opening 2 Openings
CFM In³ In³ inwc inwc inwc inwc inwc inwc
0 - 750 230
0.01 0.01 0.15
751 - 1000 330 0.05 0.05 0.2
1001 - 1250 330 0.1 0.1 0.2
1251 - 1500 330 0.1 0.1 0.25
1501 - 1750 380 658 0.15 0.09 0.14 0.08 0.3 0.17
1751 - 2000 380 658 0.19 0.11 0.18 0.1 0.3 0.17
2001 & Above 463 658 0.19 0.11 0.18 0.1 0.3 0.17
UNIT CLEARANCES TO COMBUSTIBLES
APPLICATION
TOP FRONT REAR LEFT SIDE RIGHT SIDE FLUE
FLOOR/
BOTTOM
CLOSET ALCOVE ATTIC
LINE
CONTACT
In. In. In. In. In. In.
DOWNFLOW 1 6 0 0 3 6
1
1
YES YES YES NO
DOWNFLOW B-VENT 1 3 0 0 0 1
1
1
YES YES YES NO
1 Special floor base or air conditioning coil required for use on combustible floor.
